FCC ID XBTNGW-230
Wireless Gateway
by United Integrated Services CO., LTD.
Grantee Code: XBT Product Code: NGW230
Latest application date: 2016-07-15
Device Images
FCC ID Device Details
| FCC ID | XBTNGW-230 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | XBT |
| Product Code | NGW230 |
| Applicant Business | United Integrated Services CO., LTD. 🇹🇼 |
| Related Domains |  uisco.com.tw |
| Equipment Class | Wireless Gateway |
| Test Firm | Taiwan Testing and Certification Center |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2405-2480 MHz | Original Equipment | 2016-07-15 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-07-15 | PDF 186.4 KB |
| Internal Photos | Internal Photos | 2016-07-15 | PDF 711.7 KB |
| External Photos | External Photos | 2016-07-15 | PDF 690.3 KB |
| Label | ID Label/Location Info | 2016-07-15 | PDF 73.2 KB |
| Antenna Details | Operational Description | 2016-07-15 | PDF 1.6 MB |
| Test Setup Photos | Test Setup Photos | 2016-07-15 | PDF 590.6 KB |
| Test Report | Test Report | 2016-07-15 | PDF 1.4 MB |
| Test Report II | Test Report | 2016-07-15 | PDF 966.9 KB |
| Agents Letter | Cover Letter(s) | 2016-07-15 | PDF 36.1 KB |
| Confidentiality Letter | Cover Letter(s) | 2016-07-15 | PDF 137.7 KB |
| RF Exposure Report | RF Exposure Info | 2016-07-15 | PDF 50.4 KB |
| Block Diagram Metadata only | Block Diagram | PDF 20.3 KB | |
| Schematics Metadata only | Schematics | PDF 140.1 KB | |
| Operating Description Metadata only | Operational Description | PDF 44.5 KB |
Application Information
| Application ID | I5BQ3txenGQALrxU5o+1Yg== |
|---|---|
| Final Action Date | 2016-07-15 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0018658765 |
| Model | NGW-230 |
| Frequency Range | 2405-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Wireless Gateway |
| Responsible Party | CHUNHSIUNG WANG, Director, Tahsiung_wang@uisco.com.tw , 886-2-29174060 |
| Test Firm | Anderson Ku, Taiwan Testing and Certification Center, Kuyuanfu@etc.org.tw  , 886-2-26023052 |
| TCB Email | VKerai@tuvam.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power is conducted. The antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. End users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| I5BQ3txenGQALrxU5o+1Yg== | 2016-07-15 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application I5BQ3txenGQALrxU5o+1Yg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
TUV SUD BABT Octagon House, Concorde Way, Segensworth North, Fareham, PO15 5RL United Kingdom |
Date of Grant: 07/15/2016 Application Dated: 07/15/2016 |
| United Integrated Services CO., LTD. |
| 5F No 3 Lane 7 Paokao Road Hsintien District |
| New Taipei City, 23144 Taiwan |
| Attention: CHUNHSIUNG WANG , Director |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XBTNGW-230 |
| Name of Grantee: | United Integrated Services CO., LTD. |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless Gateway |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.057544 | |||
| 15C | 2422.0 - 2452.0 | 0.01349 | |||
| 15C | 2405.0 - 2480.0 | 0.05902 |
| Output power is conducted. The antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. End users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
EAS Grant - Application I5BQ3txenGQALrxU5o+1Yg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
United Integrated Services CO., LTD. 5F No 3 Lane 7 Paokao Road Hsintien District New Taipei City, 23144 Taiwan |
Date of Grant: 07/15/2016 Application Dated: 07/15/2016 |
| Attention: CHUNHSIUNG WANG , Director |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XBTNGW-230 |
| Name of Grantee: | United Integrated Services CO., LTD. |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless Gateway |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.057544 | |||
| 15C | 2422.0 - 2452.0 | 0.01349 | |||
| 15C | 2405.0 - 2480.0 | 0.05902 |
| Output power is conducted. The antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. End users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
