FCC ID XENGD001
Wireless Keyboard Dongle
by Heng Yu Electronic Manufacturing Co. Ltd.
Grantee Code: XEN Product Code: GD001
Latest application date: 2016-02-25
Device Images
FCC ID Device Details
| FCC ID | XENGD001 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | XEN |
| Product Code | GD001 |
| Applicant Business | Heng Yu Electronic Manufacturing Co. Ltd. 🇨🇳 |
| Related Domains |  hengyu-tech.com |
| Equipment Class | Wireless Keyboard Dongle |
| Test Firm | The Hong Kong Standards and Testing Centre Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2404-2480 MHz | Original Equipment | 2016-02-25 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| user manual | Users Manual | 2016-02-25 | PDF 290.6 KB |
| Int Photos | Internal Photos | 2016-02-25 | PDF 112.6 KB |
| ext photos | External Photos | 2016-02-25 | PDF 1,011.4 KB |
| label and location | ID Label/Location Info | 2016-02-25 | PDF 67.5 KB |
| test setup photos | Test Setup Photos | 2016-02-25 | PDF 161 KB |
| Test report | Test Report | 2016-02-25 | PDF 1.8 MB |
| LTC request | Cover Letter(s) | 2016-02-25 | PDF 209.6 KB |
| letter of appointment | Cover Letter(s) | 2016-02-25 | PDF 258.4 KB |
| Block Diagram Metadata only | Block Diagram | PDF 17.9 KB | |
| schematics Metadata only | Schematics | PDF 48.1 KB | |
| operational description Metadata only | Operational Description | PDF 6.2 KB | |
| parts list Metadata only | Parts List/Tune Up Info | PDF 20 KB |
Application Information
| Application ID | D21v+91Yu5/Ab7qPbo0JGw== |
|---|---|
| Final Action Date | 2016-02-25 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0018800110 |
| Model | GD001 |
| Frequency Range | 2404-2480 MHz |
| Equipment Class | DXX - Part 15 Low Power Communication Device Transmitter |
| Device Description | Wireless Keyboard Dongle |
| Responsible Party | H.K. Chan, R&D; Manager, hk.chan@hengyu-tech.com , 00852 23951852 |
| Agent | KC KC KC, The Hong Kong Standards and Testing Centre, kc_lee@hkstc.org  , 85226661852 |
| Test Firm | Wilson Wong, The Hong Kong Standards and Testing Centre Ltd., wilson_wong@hkstc.org , 852-2666-1888 |
| TCB Email | Brandhorst.dirk@phoenix-testlab.de  |
| TCB Scope | A2: Low Power Transmitters (except Spread Spectrum) and radar detectors operating above 1 GHz |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| D21v+91Yu5/Ab7qPbo0JGw== | 2016-02-25 | Original Equipment |
Equipment Authorization
| Frequency | Rules |
|---|---|
| 2404-2480 MHz | 15C |
Grants
TCB Grant - Application D21v+91Yu5/Ab7qPbo0JGw==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
PHOENIX TESTLAB GmbH Koenigswinkel 10 32825 Blomberg, Germany |
Date of Grant: 02/25/2016 Application Dated: 02/25/2016 |
| Heng Yu Electronic Manufacturing Co. Ltd. |
| Room 1503-5, Nan Fung Commercial Centre, 19 Lam Lo |
| Hong Kong, China |
| Attention: H.K. Chan , R&D Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XENGD001 |
| Name of Grantee: | Heng Yu Electronic Manufacturing Co. Ltd. |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | Wireless Keyboard Dongle |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2404.0 - 2480.0 |
EAS Grant - Application D21v+91Yu5/Ab7qPbo0JGw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Heng Yu Electronic Manufacturing Co. Ltd. Room 1503-5, Nan Fung Commercial Centre, 19 Lam Lo P.O. Box , Hong Kong, China |
Date of Grant: 02/25/2016 Application Dated: 02/25/2016 |
| Attention: H.K. Chan , R&D Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XENGD001 |
| Name of Grantee: | Heng Yu Electronic Manufacturing Co. Ltd. |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | Wireless Keyboard Dongle |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2404.0 - 2480.0 |
| Mail To: |
