WISTARRE602 Emitter Teardown Internal... - FCC ID XFCWISTAR-RE602

FCC ID XFCWISTAR-RE602

Internal Photos

Emitter

by Hangzhou Wistar Mechanical & Electric Technology Co.,Ltd.

Document preview loads when visible.

Document Details

FCC IDXFCWISTAR-RE602
Document ID3258290
Document TypeInternal Photos
DescriptionInternal Photos
Document Title\\Stsserver\01-案件管理\STS1612213 WSRE602-1 威仕达\5. Photo、Data\EMC\EUT Photo\WSRE602-1_internal Photo
ApplicantHangzhou Wistar Mechanical & Electric Technology Co.,Ltd.
Equipment ClassEmitter
Product CodeWISTARRE602
Application IDZqQhQFVAPegZN9IqxJfRSQ==
Application PurposeOriginal Equipment
Application Date2017-01-14
Frequency Range433.92 MHz
FRN0018815019
Test FirmShenzhen STS Test Services Co., Ltd.
Certified ByMinghua Liu Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2017-01-13
Available2017-01-14
Created2016-12-28
Modified2016-12-28
Pages3
File TypeAdobe Acrobat PDF
File Size4996171
File SHA-256ea2c4ddddd4530507af1bf0da0ed95fa5b80b80cc0d578e5b295918d0a14034d
PDF Metadata AuthorAdministrator
PDF Metadata ProducerAdministrator Acrobat Distiller 9.0.0 (Windows)
FCC.gov SourcesFCC.gov 3258290
