CADWELL1 Wireless EEG Recorder External Photos - FCC ID XFYCADWELL-1

FCC ID XFYCADWELL-1

External Angle and Assembly views

Wireless EEG Recorder

by Cadwell

Document preview loads when visible.

Document Details

FCC IDXFYCADWELL-1
Document ID1128342
Document TypeExternal Photos
DescriptionExternal Angle and Assembly views
Document TitleExternal Angle and Assembly views
ApplicantCadwell
Equipment ClassWireless EEG Recorder
Product CodeCADWELL1
Application IDHdtCB2msbzwHwhB177BKtQ==
Application PurposeOriginal Equipment
Application Date2009-10-08
Frequency Range2412-2462 MHz
FRN0018713115
Test FirmUL VS Ltd
Certified ByChris L. Bolkan QA/RA
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date11/22/2009
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2009-06-23
Available2009-10-08
Created2009-06-23
Modified2009-06-23
Pages1
File TypeAdobe Acrobat PDF
File Size2297203
File SHA-2563b00e990925cf1c26f91775620f950ef286c96cfe1d33c8a888564b9da18b29c
PDF Metadata Authorchrisb
PDF Metadata CreatorPScript5.dll Version 5.2
PDF Metadata ProducerGPL Ghostscript 8.15
FCC.gov SourcesFCC.gov 1128342
