3347TX Recon Air Chat Communicator Wireless... - FCC ID XGB-3347TX
FCC ID XGB-3347TX
Test Setup Photos
Recon Air Chat Communicator Wireless
Document preview loads when visible.
Document Details
| FCC ID | XGB-3347TX |
|---|---|
| Document ID | 5915086 |
| Document Type | Test Setup Photos |
| Description | Test Setup Photos |
| Applicant | Voyetra Turtle Beach, Inc. |
| Equipment Class | Recon Air Chat Communicator Wireless |
| Product Code | 3347TX |
| Application ID | GECbwV5c2CgBzwCn4Lkd3g== |
| Application Purpose | Original Equipment |
| Application Date | 2022-06-08 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0018834572 |
| Test Firm | TUV Rheinland Taiwan Ltd. Taipei Testing Lab. |
| Certified By | Joe Stachula |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2022-06-02 |
| Available | 2022-06-08 |
| Created | 2022-05-09 |
| Modified | 2022-05-17 |
| Pages | 5 |
| File Type | Adobe Acrobat PDF |
| File Size | 566109 |
| File SHA-256 | ef8e2766e46a99d2ca9af9d600b905ead302a9a2a214bf7b8e0203ea3bd20269 |
| PDF Metadata Author | TUV Rheinland Group |
| PDF Metadata Producer | Microsoft® Word 2016 Microsoft® Word 2016; modified using iText 4.2.2 by 1T3XT, AuthentiDate |
| FCC.gov Sources | FCC.gov 5915086 |
