FCC ID XGS-OGI100
Mobile Satellite Earth Station Modem
by ORBCOMM License Corp.
Grantee Code: XGS Product Code: OGI100
Latest application date: 2016-03-03
Device Images
FCC ID Device Details
| FCC ID | XGS-OGI100 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | XGS |
| Product Code | OGI100 |
| Applicant Business | ORBCOMM License Corp. 🇺🇸 |
| Related Domains |  orbcomm.com |
| Equipment Class | Mobile Satellite Earth Station Modem |
| Test Firm | Nemko Canada Inc. (Ottawa) |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 1626.501-1660.499 MHz | Original Equipment | 2016-03-03 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-03-03 | PDF 1.8 MB |
| Internal Photos | Internal Photos | 2016-03-03 | PDF 526.8 KB |
| External Photos | External Photos | 2016-03-03 | PDF 736.8 KB |
| Label and Label Location | ID Label/Location Info | 2016-03-03 | PDF 132.2 KB |
| Test Setup Photos | Test Setup Photos | 2016-03-03 | PDF 973.8 KB |
| Test Report | Test Report | 2016-03-03 | PDF 1.9 MB |
| Testy Report | Test Report | 2016-03-03 | PDF 1.9 MB |
| Cover Letters | Cover Letter(s) | 2016-03-03 | PDF 302.7 KB |
| RF Exposure info | RF Exposure Info | 2016-03-03 | PDF 84.7 KB |
| Tuen up info | Parts List/Tune Up Info | 2016-03-03 | PDF 101.6 KB |
| Block Diagram Metadata only | Block Diagram | PDF 24.9 KB | |
| Schematics Metadata only | Schematics | PDF 1.2 MB | |
| Operational Description Metadata only | Operational Description | PDF 324.4 KB |
Application Information
| Application ID | 4trd4j1GuGtAAi75XJOlbA== |
|---|---|
| Final Action Date | 2016-03-03 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0004379202 |
| Model | OGI100 |
| Frequency Range | 1626.501-1660.499 MHz |
| Equipment Class | TNB - Licensed Non-Broadcast Station Transmitter |
| Device Description | Mobile Satellite Earth Station Modem |
| Responsible Party | Walter Sonnenfeldt, Vice President, Regulatory Affairs, sonnenfeldt.walter@orbcomm.com , (585) 461-3018 |
| Test Firm | Charles Neal, Nemko Canada Inc. (Ottawa), charles.neal@nemko.com  , 613-737-9680 |
| TCB Email | Stuart.Beck@nemko.com |
| TCB Scope | B1: Commercial mobile radio services equipment in the following 47 CFR Parts 20, 22 (cellular), 24,25 (below 3 GHz) & 27 |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Modular approval. Output power listed is EIRP. RF exposure compliance may need to be addressed at the time of licensing, as required by the responsible FCC Bureau(s), including antenna co-location requirements of 1.1307(b)(3). Users and installers must be provided with antenna installation and transmitter operating conditions for satisfying RF exposure compliance |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| 4trd4j1GuGtAAi75XJOlbA== | 2016-03-03 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application 4trd4j1GuGtAAi75XJOlbA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Nemko North America, INC. 303 River Road Ottawa, Ontario, K1V 1H2 Canada |
Date of Grant: 03/03/2016 Application Dated: 03/03/2016 |
| ORBCOMM License Corp. |
| 395 West Passaic Street |
| Suite 325 |
| Rochelle Park, NJ 07662 |
| Attention: Walter Sonnenfeldt , Vice President, Regulatory Affairs |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XGS-OGI100 |
| Name of Grantee: | ORBCOMM License Corp. |
| Equipment Class: | Licensed Non-Broadcast Station Transmitter |
| Notes: | Mobile Satellite Earth Station Modem |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 25 | 1626.501 - 1660.499 | 5.26 | 0.27517142 PM | 1K96G1D |
| Modular approval. Output power listed is EIRP. RF exposure compliance may need to be addressed at the time of licensing, as required by the responsible FCC Bureau(s), including antenna co-location requirements of 1.1307(b)(3). Users and installers must be provided with antenna installation and transmitter operating conditions for satisfying RF exposure compliance |
EAS Grant - Application 4trd4j1GuGtAAi75XJOlbA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
ORBCOMM License Corp. 395 West Passaic Street Suite 325 Rochelle Park, NJ 07662 United States |
Date of Grant: 03/03/2016 Application Dated: 03/03/2016 |
| Attention: Walter Sonnenfeldt , Vice President, Regulatory Affairs |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XGS-OGI100 |
| Name of Grantee: | ORBCOMM License Corp. |
| Equipment Class: | Licensed Non-Broadcast Station Transmitter |
| Notes: | Mobile Satellite Earth Station Modem |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 25 | 1626.501 - 1660.499 | 5.26 | 0.27517142 PM | 1K96G1D |
| Modular approval. Output power listed is EIRP. RF exposure compliance may need to be addressed at the time of licensing, as required by the responsible FCC Bureau(s), including antenna co-location requirements of 1.1307(b)(3). Users and installers must be provided with antenna installation and transmitter operating conditions for satisfying RF exposure compliance |
