Wireless 8 Channel Analog Input Sensor Node
by Parker Hannifin
Grantee Code: XJQ Product Code: MSLINK0004
Latest application date: 2017-04-11
Device Images
FCC ID Device Details
| FCC ID | XJQMSLINK0004 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | XJQ |
| Product Code | MSLINK0004 |
| Applicant Business | Parker Hannifin 🇺🇸 |
| Related Domains |  parker.com  retlif.com |
| Equipment Class | Wireless 8 Channel Analog Input Sensor Node |
| Test Firm | Retlif Testing Laboratories |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2017-04-11 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Exhibit D Users Manual per 2 1033 b3 | Users Manual | 2017-04-11 | PDF 3 MB |
| Exhibit C Internal Photographs per 2 1033 b7 | Internal Photos | 2017-04-11 | PDF 449.9 KB |
| Exhibit C External Photographs per 2 1033 b7 | External Photos | 2017-04-11 | PDF 472.3 KB |
| Exhibit A ID Label and location per 2 1033 b7 | ID Label/Location Info | 2017-04-11 | PDF 80.9 KB |
| Exhibit C RE Test Setup photographs | Test Setup Photos | 2017-04-11 | PDF 1.5 MB |
| Exhibit E Test Measurement Report per 2 1033 b6 | Test Report | 2017-04-11 | PDF 2.1 MB |
| Agent Authorization Letter | Cover Letter(s) | 2017-04-11 | PDF 158 KB |
| Cover Letter Requesting Confidentiality | Cover Letter(s) | 2017-04-11 | PDF 158.4 KB |
| Misc RF Exposure Exhibits | RF Exposure Info | 2017-04-11 | PDF 13 KB |
| Exhibit B Block Diagram per 2 1033 b5 Metadata only | Block Diagram | PDF 276.8 KB | |
| Exhibit B Schematics per 2 1033 b5 Metadata only | Schematics | PDF 1.5 MB | |
| Exhibit B Operational Description per 2 1033 b4 Metadata only | Operational Description | PDF 279.4 KB |
Application Information
| Application ID | oZzvMm24bQf6eEaQCNI7lA== |
|---|---|
| Final Action Date | 2017-04-11 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0018892414 |
| Model | MSLINK0004 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Wireless 8 Channel Analog Input Sensor Node |
| Responsible Party | Justin Bessette, Engineering Manager, Justin.Bessette@parker.com , 8028626629 |
| Agent | Todd Todd Todd, Retlif, thannemann@retlif.com , 6034974600 |
| Technical Contact | Todd Hannemann, Retlif Testing Laboratories, thannemann@retlif.com , 6034974600 |
| Non-Technical Contact | Todd Hannemann, Retlif Testing Laboratories, thannemann@retlif.com , 6034974600 |
| Test Firm | Scott Wentworth, Retlif Testing Laboratories, swentworth@retlif.com , 631-497-4600 |
| TCB Email | decrowder@elitetest.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is conducted. The antenna(s) used for this transmitter must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. Approved for used with antenna(s) as listed in this filing. |
