FCC ID XKB-D5000CLWIBT

FCC ID	XKB-D5000CLWIBT
Mirrors	fcc.id \| gov \| fccid.ai
Grantee Code	XKB
Product Code	D5000CLWIBT
Applicant Business	INGENICO 🇫🇷
Related Domains	ingenico.com
Equipment Class	Payment Terminal
Test Firm	LCIE Etablissement Sud-Est

Frequency Range	Application Purpose	Final Action Date
2402-2480 MHz	Original Equipment	2017-02-28
5180-5240 MHz	Original Equipment	2017-02-28
13.56 MHz	Original Equipment	2017-02-28
2412-2462 MHz	Original Equipment	2017-02-28

Document	Type	Available	File
User manual reduced.pdf	Users Manual	2017-02-28	PDF 2.1 MB
User manual.pdf	Users Manual	2017-02-28	PDF 2.1 MB
Internal Photos.pdf	Internal Photos	2017-02-28	PDF 2.7 MB
External Photos.pdf	External Photos	2017-02-28	PDF 1.6 MB
Label and Label location.pdf	ID Label/Location Info	2017-02-28	PDF 818.9 KB
Operational Description.pdf	Operational Description	2017-02-28	PDF 884 KB
Software Operational Description - Declaration of U-NII Informations.pdf	Operational Description	2017-02-28	PDF 133.2 KB
Test setup photo.pdf	Test Setup Photos	2017-02-28	PDF 728.9 KB
Test report 1 - DSS.pdf	Test Report	2017-02-28	PDF 3.4 MB
Test report 2 - DXX.pdf	Test Report	2017-02-28	PDF 2.3 MB
Test report 3 - DTS.pdf	Test Report	2017-02-28	PDF 4 MB
Test report 4 - NII.pdf	Test Report	2017-02-28	PDF 5.2 MB
Test report 5 - DFS.pdf	Test Report	2017-02-28	PDF 1.5 MB
Confidential Request.pdf	Cover Letter(s)	2017-02-28	PDF 81.2 KB
Cover letter - Agent Authorization Letter.pdf	Cover Letter(s)	2017-02-28	PDF 84.4 KB
RF exposure information - SAR report 1.pdf	RF Exposure Info	2017-02-28	PDF 1 MB
RF exposure information - SAR report 2.pdf	RF Exposure Info	2017-02-28	PDF 4.7 MB
Block Diagram.pdf Metadata only	Block Diagram		PDF 283.3 KB
Schematics 1.pdf Metadata only	Schematics		PDF 385.1 KB
Schematics 2.pdf Metadata only	Schematics		PDF 229.8 KB

Application ID	sthTNi1cfjhfOJDiwiE+IA==
Final Action Date	2017-02-28
Application Purpose	Original Equipment
Applicant FRN	0018912279
Model	D5000CLWIBT
Frequency Range	2402-2480 MHz
Equipment Class	DSS - Part 15 Spread Spectrum Transmitter
Device Description	Payment Terminal
Responsible Party	Nicolas Jacquemont, Certification Manager, nicolas.jacquemont@ingenico.com , +330475842123
Test Firm	Anthony Merlin, LCIE Etablissement Sud-Est, anthony.merlin@bureauveritas.com , 00-33-4-76-07-36-36
TCB Email	tcb@us.bureauveritas.com
TCB Scope	A4: UNII devices & low power transmitters using spread spectrum techniques
Short-Term Confidentiality	No
Long-Term Confidentiality	Yes
Grant Deferral	No
Modular Equipment	Does not apply
Composite Device	Yes
Composite Part	No
Cognitive Radio	No
Authorization Waiver	No
Authorization Waiver Approved	No
Section 5301 Certification	Yes
Related OET Knowledge DataBase Inquiry	No
Grant Comments	Output power is conducted. SAR compliance has been demonstrated as described in this filing. SAR compliance for extremity operating configuration. This device must not be collocated or operating in conjunction with any other antenna or transmitter except the collocation as described in this filing and/or in accordance with FCC multi-transmitter product guidelines. End-users must be informed of the extremity operating requirements for satisfying RF exposure compliance. The highest reported SAR values for extremity and simultaneous transmission use condition is 0.569 W/kg.

Application ID	Date	Purpose
sthTNi1cfjhfOJDiwiE+IA==	2017-02-28	Original Equipment
fydQd2TFsZBFXzDDJS2GyQ==	2017-02-28	Original Equipment
bt4b3rBLQnxzXneqMTEJuw==	2017-02-28	Original Equipment
Fk/J35ZCVxZ5y7xyEd9xBQ==	2017-02-28	Original Equipment

Frequency	Output	Rules	Grant Notes
13.56 MHz		15C	28, CC
2402-2480 MHz	0.0013868	15C	28, CC
2412-2462 MHz	0.0132430	15C	20, 28, CC
5180-5240 MHz	0.011066	15E	20, 28, 38, CC
5260-5320 MHz	0.013804	15E	20, 28, 38, CC, ND
5500-5700 MHz	0.030199	15E	20, 28, 38, CC, ND

TCB	GRANT OF EQUIPMENT AUTHORIZATION	TCB
Certification
Issued Under the Authority of the
Federal Communications Commission
By:

Bureau Veritas Consumer Products Services, Inc.
One Distribution Center Circle Suite #1
Littleton, MA 01460

Date of Grant: 02/28/2017

Application Dated: 02/28/2017

INGENICO

9 Avenue de la gare - Rovaltain TGV

P.O. Box BP25156,

Valence Cedex 9, 26958
France

Attention: Nicolas Jacquemont , Certification Manager

NOT TRANSFERABLE

EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:	XKB-D5000CLWIBT

Name of Grantee:	INGENICO

Equipment Class:	Part 15 Spread Spectrum Transmitter
Notes:	Payment Terminal

Grant Notes	FCC Rule Parts	Frequency Range (MHZ)	Output Watts	Frequency Tolerance	Emission Designator
28 CC	15C	2402.0 - 2480.0	0.0013868

Output power is conducted. SAR compliance has been demonstrated as described in this filing. SAR compliance for extremity operating configuration. This device must not be collocated or operating in conjunction with any other antenna or transmitter except the collocation as described in this filing and/or in accordance with FCC multi-transmitter product guidelines. End-users must be informed of the extremity operating requirements for satisfying RF exposure compliance. The highest reported SAR values for extremity and simultaneous transmission use condition is 0.569 W/kg.

28:	An AC adapter incorporating a ferrite core at the connector end of its DC line must be provided with every unit sold.
CC:	This device is certified pursuant to two different Part 15 rules sections.

COPY	FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION	COPY
Certification

INGENICO
9 Avenue de la gare - Rovaltain TGV P.O. Box BP25156,
Valence Cedex 9, 26958
France

Date of Grant: 02/28/2017

Application Dated: 02/28/2017

Attention: Nicolas Jacquemont , Certification Manager

NOT TRANSFERABLE

EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:	XKB-D5000CLWIBT

Name of Grantee:	INGENICO

Equipment Class:	Part 15 Spread Spectrum Transmitter
Notes:	Payment Terminal
Modular Type:	Does not apply

Grant Notes	FCC Rule Parts	Frequency Range (MHZ)	Output Watts	Frequency Tolerance	Emission Designator
28 CC	15C	2402.0 - 2480.0	0.0013868

Output power is conducted. SAR compliance has been demonstrated as described in this filing. SAR compliance for extremity operating configuration. This device must not be collocated or operating in conjunction with any other antenna or transmitter except the collocation as described in this filing and/or in accordance with FCC multi-transmitter product guidelines. End-users must be informed of the extremity operating requirements for satisfying RF exposure compliance. The highest reported SAR values for extremity and simultaneous transmission use condition is 0.569 W/kg.

28:	An AC adapter incorporating a ferrite core at the connector end of its DC line must be provided with every unit sold.
CC:	This device is certified pursuant to two different Part 15 rules sections.

TCB Grant - Application fydQd2TFsZBFXzDDJS2GyQ==

Mail To:

TCB	GRANT OF EQUIPMENT AUTHORIZATION	TCB
Certification
Issued Under the Authority of the
Federal Communications Commission
By:

Bureau Veritas Consumer Products Services, Inc.
One Distribution Center Circle Suite #1
Littleton, MA 01460

Date of Grant: 02/28/2017

Application Dated: 02/28/2017

INGENICO

9 Avenue de la gare - Rovaltain TGV

P.O. Box BP25156,

Valence Cedex 9, 26958
France

Attention: Nicolas Jacquemont , Certification Manager

NOT TRANSFERABLE

EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:	XKB-D5000CLWIBT

Name of Grantee:	INGENICO

Equipment Class:	Unlicensed National Information Infrastructure TX
Notes:	Payment Terminal

Grant Notes	FCC Rule Parts	Frequency Range (MHZ)	Output Watts	Frequency Tolerance	Emission Designator
20 28 38 CC	15E	5180.0 - 5240.0	0.011066
20 28 38 CC ND	15E	5260.0 - 5320.0	0.013804
20 28 38 CC ND	15E	5500.0 - 5700.0	0.030199

Output power is conducted. SAR compliance has been demonstrated as described in this filing. SAR compliance for extremity operating configuration. This device must not be collocated or operating in conjunction with any other antenna or transmitter except the collocation as described in this filing and/or in accordance with FCC multi-transmitter product guidelines. End-users must be informed of the extremity operating requirements for satisfying RF exposure compliance. The highest reported SAR values for extremity and simultaneous transmission use condition are 0.569 W/kg and 0.569 W/kg. This device has 20MHz and 40MHz bandwidth modes. This device is restricted for indoor use only.

20:	All electrical and mechanical devices employed for spurious radiation suppression, including any modifications made during certification testing, must be incorporated in each unit marketed.
28:	An AC adapter incorporating a ferrite core at the connector end of its DC line must be provided with every unit sold.
38:	This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline.
CC:	This device is certified pursuant to two different Part 15 rules sections.
ND:	This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h).

COPY	FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION	COPY
Certification

INGENICO
9 Avenue de la gare - Rovaltain TGV P.O. Box BP25156,
Valence Cedex 9, 26958
France

Date of Grant: 02/28/2017

Application Dated: 02/28/2017

Attention: Nicolas Jacquemont , Certification Manager

NOT TRANSFERABLE

EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:	XKB-D5000CLWIBT

Name of Grantee:	INGENICO

Equipment Class:	Unlicensed National Information Infrastructure TX
Notes:	Payment Terminal
Modular Type:	Does not apply

Grant Notes	FCC Rule Parts	Frequency Range (MHZ)	Output Watts	Frequency Tolerance	Emission Designator
20 28 38 CC	15E	5180.0 - 5240.0	0.011066
20 28 38 CC ND	15E	5260.0 - 5320.0	0.013804
20 28 38 CC ND	15E	5500.0 - 5700.0	0.030199

Output power is conducted. SAR compliance has been demonstrated as described in this filing. SAR compliance for extremity operating configuration. This device must not be collocated or operating in conjunction with any other antenna or transmitter except the collocation as described in this filing and/or in accordance with FCC multi-transmitter product guidelines. End-users must be informed of the extremity operating requirements for satisfying RF exposure compliance. The highest reported SAR values for extremity and simultaneous transmission use condition are 0.569 W/kg and 0.569 W/kg. This device has 20MHz and 40MHz bandwidth modes. This device is restricted for indoor use only.

20:	All electrical and mechanical devices employed for spurious radiation suppression, including any modifications made during certification testing, must be incorporated in each unit marketed.
28:	An AC adapter incorporating a ferrite core at the connector end of its DC line must be provided with every unit sold.
38:	This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline.
CC:	This device is certified pursuant to two different Part 15 rules sections.
ND:	This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h).

TCB Grant - Application Fk/J35ZCVxZ5y7xyEd9xBQ==

Mail To:

TCB	GRANT OF EQUIPMENT AUTHORIZATION	TCB
Certification
Issued Under the Authority of the
Federal Communications Commission
By:

Bureau Veritas Consumer Products Services, Inc.
One Distribution Center Circle Suite #1
Littleton, MA 01460

Date of Grant: 02/28/2017

Application Dated: 02/28/2017

INGENICO

9 Avenue de la gare - Rovaltain TGV

P.O. Box BP25156,

Valence Cedex 9, 26958
France

Attention: Nicolas Jacquemont , Certification Manager

NOT TRANSFERABLE

EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:	XKB-D5000CLWIBT

Name of Grantee:	INGENICO

Equipment Class:	Digital Transmission System
Notes:	Payment Terminal

Grant Notes	FCC Rule Parts	Frequency Range (MHZ)	Output Watts	Frequency Tolerance	Emission Designator
20 28 CC	15C	2412.0 - 2462.0	0.013243

Output power is conducted. SAR compliance has been demonstrated as described in this filing. SAR compliance for extremity operating configuration. This device must not be collocated or operating in conjunction with any other antenna or transmitter except the collocation as described in this filing and/or in accordance with FCC multi-transmitter product guidelines. End-users must be informed of the extremity operating requirements for satisfying RF exposure compliance. The highest reported SAR values for extremity and simultaneous transmission use condition are 0.045 W/kg and 0.569 W/kg. This device has 20MHz and 40MHz bandwidth modes.

20:	All electrical and mechanical devices employed for spurious radiation suppression, including any modifications made during certification testing, must be incorporated in each unit marketed.
28:	An AC adapter incorporating a ferrite core at the connector end of its DC line must be provided with every unit sold.
CC:	This device is certified pursuant to two different Part 15 rules sections.

COPY	FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION	COPY
Certification

INGENICO
9 Avenue de la gare - Rovaltain TGV P.O. Box BP25156,
Valence Cedex 9, 26958
France

Date of Grant: 02/28/2017

Application Dated: 02/28/2017

Attention: Nicolas Jacquemont , Certification Manager

NOT TRANSFERABLE

EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:	XKB-D5000CLWIBT

Name of Grantee:	INGENICO

Equipment Class:	Digital Transmission System
Notes:	Payment Terminal
Modular Type:	Does not apply

Grant Notes	FCC Rule Parts	Frequency Range (MHZ)	Output Watts	Frequency Tolerance	Emission Designator
20 28 CC	15C	2412.0 - 2462.0	0.013243

Output power is conducted. SAR compliance has been demonstrated as described in this filing. SAR compliance for extremity operating configuration. This device must not be collocated or operating in conjunction with any other antenna or transmitter except the collocation as described in this filing and/or in accordance with FCC multi-transmitter product guidelines. End-users must be informed of the extremity operating requirements for satisfying RF exposure compliance. The highest reported SAR values for extremity and simultaneous transmission use condition are 0.045 W/kg and 0.569 W/kg. This device has 20MHz and 40MHz bandwidth modes.

20:	All electrical and mechanical devices employed for spurious radiation suppression, including any modifications made during certification testing, must be incorporated in each unit marketed.
28:	An AC adapter incorporating a ferrite core at the connector end of its DC line must be provided with every unit sold.
CC:	This device is certified pursuant to two different Part 15 rules sections.

TCB Grant - Application bt4b3rBLQnxzXneqMTEJuw==

Mail To:

TCB	GRANT OF EQUIPMENT AUTHORIZATION	TCB
Certification
Issued Under the Authority of the
Federal Communications Commission
By:

Bureau Veritas Consumer Products Services, Inc.
One Distribution Center Circle Suite #1
Littleton, MA 01460

Date of Grant: 02/28/2017

Application Dated: 02/28/2017

INGENICO

9 Avenue de la gare - Rovaltain TGV

P.O. Box BP25156,

Valence Cedex 9, 26958
France

Attention: Nicolas Jacquemont , Certification Manager

NOT TRANSFERABLE

EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:	XKB-D5000CLWIBT

Name of Grantee:	INGENICO

Equipment Class:	Part 15 Low Power Communication Device Transmitter
Notes:	Payment Terminal

Grant Notes	FCC Rule Parts	Frequency Range (MHZ)	Output Watts	Frequency Tolerance	Emission Designator
28 CC	15C	13.56 - 13.56

This device must not be collocated or operating in conjunction with any other antenna or transmitter except the collocation as described in this filing and/or in accordance with FCC multi-transmitter product guidelines. End-users must be informed of the extremity operating requirements for satisfying RF exposure compliance.

28:	An AC adapter incorporating a ferrite core at the connector end of its DC line must be provided with every unit sold.
CC:	This device is certified pursuant to two different Part 15 rules sections.

COPY	FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION	COPY
Certification

INGENICO
9 Avenue de la gare - Rovaltain TGV P.O. Box BP25156,
Valence Cedex 9, 26958
France

Date of Grant: 02/28/2017

Application Dated: 02/28/2017

Attention: Nicolas Jacquemont , Certification Manager

NOT TRANSFERABLE

EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:	XKB-D5000CLWIBT

Name of Grantee:	INGENICO

Equipment Class:	Part 15 Low Power Communication Device Transmitter
Notes:	Payment Terminal
Modular Type:	Does not apply

Grant Notes	FCC Rule Parts	Frequency Range (MHZ)	Output Watts	Frequency Tolerance	Emission Designator
28 CC	15C	13.56 - 13.56

This device must not be collocated or operating in conjunction with any other antenna or transmitter except the collocation as described in this filing and/or in accordance with FCC multi-transmitter product guidelines. End-users must be informed of the extremity operating requirements for satisfying RF exposure compliance.

28:	An AC adapter incorporating a ferrite core at the connector end of its DC line must be provided with every unit sold.
CC:	This device is certified pursuant to two different Part 15 rules sections.

Mail To:

Payment Terminal

by INGENICO

Grantee Code: XKB Product Code: D5000CLWIBT

Latest application date: 2017-02-28

Device Images

FCC ID Device Details

Operating Frequencies

Exhibits

Application Information

Applications

Equipment Authorization

Grants

TCB Grant - Application sthTNi1cfjhfOJDiwiE+IA==

EAS Grant - Application sthTNi1cfjhfOJDiwiE+IA==

TCB Grant - Application fydQd2TFsZBFXzDDJS2GyQ==

EAS Grant - Application fydQd2TFsZBFXzDDJS2GyQ==

TCB Grant - Application Fk/J35ZCVxZ5y7xyEd9xBQ==

EAS Grant - Application Fk/J35ZCVxZ5y7xyEd9xBQ==

TCB Grant - Application bt4b3rBLQnxzXneqMTEJuw==

EAS Grant - Application bt4b3rBLQnxzXneqMTEJuw==
