20211005 Transmitter Teardown Internal Photos - FCC ID XLF-2021-1005

FCC ID XLF-2021-1005

Internal Photos

Transmitter

by BSD RACING TECHNOLOGIES CO., LTD.

Document preview loads when visible.

Document Details

FCC IDXLF-2021-1005
Document ID7091576
Document TypeInternal Photos
DescriptionInternal Photos
ApplicantBSD RACING TECHNOLOGIES CO., LTD.
Equipment ClassTransmitter
Product Code20211005
Application IDjy5sopHMo7shCJqJwX5PMw==
Application PurposeOriginal Equipment
Application Date2024-01-31
Frequency Range2406-2472 MHz
FRN0018932525
Test FirmShenzhen CTL Testing Technology Co., Ltd.
Certified ByJack Jiang
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date07/29/2024
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2024-01-31
Available2024-01-31
Created2024-01-25
Modified2024-01-25
Pages3
File TypeAdobe Acrobat PDF
File Size1177584
File SHA-256a2b3653ca1bb28b5492df64f0ba94564368215221ed9d86b9d46eba3f4bbe87f
PDF Metadata AuthorWindows 用户
PDF Metadata ProducerMicrosoft® Office Word 2007 Microsoft® Office Word 2007
FCC.gov SourcesFCC.gov 7091576
