FCC ID XMR201603EC20
Multi-mode LTE module
by Quectel Wireless Solutions Company Limited
Grantee Code: XMR Product Code: 201603EC20
Latest application date: 2016-05-10
Device Images
FCC ID Device Details
| FCC ID | XMR201603EC20 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | XMR |
| Product Code | 201603EC20 |
| Applicant Business | Quectel Wireless Solutions Company Limited 🇨🇳 |
| Related Domains |  quectel.com |
| Equipment Class | Multi-mode LTE module |
| Test Firm | SIEMIC (Shenzhen-China) Laboratories |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 699.7-715.3 MHz | Original Equipment | 2016-05-10 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2016-05-10 | PDF 2.1 MB |
| Internal Photos | Internal Photos | 2016-05-10 | PDF 251.6 KB |
| External Photos | External Photos | 2016-05-10 | PDF 142.8 KB |
| Label & Label Location | ID Label/Location Info | 2016-05-10 | PDF 192.1 KB |
| RF Test Set-Up Photos-P22-24 | Test Setup Photos | 2016-05-10 | PDF 131.8 KB |
| RF Test Set-Up Photos-P27 | Test Setup Photos | 2016-05-10 | PDF 163.7 KB |
| RF Test Report-P22-24 | Test Report | 2016-05-10 | PDF 1 MB |
| RF Test Report-P27 | Test Report | 2016-05-10 | PDF 3.1 MB |
| Authorization Letter | Cover Letter(s) | 2016-05-10 | PDF 47 KB |
| Family Models Letter | Cover Letter(s) | 2016-05-10 | PDF 24.4 KB |
| LTC Letter | Cover Letter(s) | 2016-05-10 | PDF 47.7 KB |
| Modular Approval | Cover Letter(s) | 2016-05-10 | PDF 49.2 KB |
| MPE Report | RF Exposure Info | 2016-05-10 | PDF 490.2 KB |
| Block Diagram Metadata only | Block Diagram | PDF 194.7 KB | |
| Schematics Metadata only | Schematics | PDF 212 KB | |
| Operational Description Metadata only | Operational Description | PDF 316.8 KB | |
| BOM List Metadata only | Parts List/Tune Up Info | PDF 130.7 KB | |
| Tune-Up Procedure Metadata only | Parts List/Tune Up Info | PDF 73.9 KB |
Application Information
| Application ID | Elmb1OMuswzNm7IkhW9KMg== |
|---|---|
| Final Action Date | 2016-05-10 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0018988279 |
| Model | 201603EC20 |
| Frequency Range | 699.7-715.3 MHz |
| Equipment Class | PCB - PCS Licensed Transmitter |
| Device Description | Multi-mode LTE module |
| Responsible Party | Jean Hu, jean.hu@quectel.com , +8602150086326 |
| Test Firm | Leslie Bai, SIEMIC (Shenzhen-China) Laboratories, leslie.bai@siemic.com  , 86-0755-2601-4629 |
| TCB Email | tcb@siemic.com |
| TCB Scope | B1: Commercial mobile radio services equipment in the following 47 CFR Parts 20, 22 (cellular), 24,25 (below 3 GHz) & 27 |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Single Modular Approval. Output power is conducted. This device is to be used in mobile or fixed applications only. Antenna gain including cable loss must not exceed 10.69 dBi of frequency band 699-716MHz, 5.95 dBi of frequency band 824-849MHz, 6.5 dBi of frequency band 1710-1755MHz, 3.5 dBi of frequency band 1850-1910MHz,for the purpose of satisfying the requirements of 2.1043 and 2.1091. They operate at frequencies of 1.5 GHz or below and their effective radiated power (ERP) is 1.5 watts or more, or they operate at frequencies above 1.5 GHz and their ERP is 3 watts or more. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operated in conjunction with any antenna or transmitter not described under this FCC ID. The final product operating with this transmitter must include operating instructions and antenna installation instructions, for end-users and installers to satisfy RF exposure compliance requirements. Compliance of this device in all final product configurations is the responsibility of the Grantee. Installation of this device into specific final products may require the submission of a Class II permissive change application containing data pertinent to RF Exposure, spurious emissions, ERP/EIRP, and host/module authentication, or new application if appropriate. Installation of this device into specific final products may require the submission of a Class II permissive change application containing data pertinent to RF Exposure, spurious emissions, ERP/EIRP, and host/module authentication, or new application if appropriate. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| Elmb1OMuswzNm7IkhW9KMg== | 2016-05-10 | Original Equipment |
Equipment Authorization
| Frequency | Output | Tolerance | Emission | Rules |
|---|---|---|---|---|
| 699.7-715.3 MHz | 0.182 | 0.0064ppm | 1M34G7D | 27 |
| 699.7-715.3 MHz | 0.181 | 0.0064ppm | 10M1G7D | 27 |
| 699.7-715.3 MHz | 0.146 | 0.0064ppm | 10M3W7D | 27 |
| 699.7-715.3 MHz | 0.149 | 0.0064ppm | 3M16W7D | 27 |
| 706.5-713.5 MHz | 0.176 | 0.0155ppm | 5M14G7D | 27 |
| 706.5-713.5 MHz | 0.169 | 0.0155ppm | 10M1G7D | 27 |
| 706.5-713.5 MHz | 0.148 | 0.0155ppm | 10M1W7D | 27 |
| 706.5-713.5 MHz | 0.15 | 0.0155ppm | 5M10W7D | 27 |
| 826.4-846.6 MHz | 0.209 | 0.0132ppm | 4M73F9W | 22H |
| 826.5-846.5 MHz | 0.195 | 0.0155ppm | 5M06G7D | 22H |
| 826.5-846.5 MHz | 0.19 | 0.0155ppm | 10M2G7D | 22H |
| 826.5-846.5 MHz | 0.161 | 0.0155ppm | 10M1W7D | 22H |
| 1712.4-1752.6 MHz | 0.17 | 0.0058ppm | 4M71F9W | 27 |
| 1712.5-1752.5 MHz | 0.135 | 0.0092ppm | 19M6W7D | 27 |
| 1712.5-1752.5 MHz | 0.139 | 0.0092ppm | 14M9W7D | 27 |
| 1712.5-1752.5 MHz | 0.166 | 0.0092ppm | 1M31G7D | 27 |
| 1712.5-1752.5 MHz | 0.156 | 0.0092ppm | 19M4G7D | 27 |
| 1852.4-1907.6 MHz | 0.168 | 0.0043ppm | 4M70F9W | 24E |
| 1852.5-1907.5 MHz | 0.162 | 0.0064ppm | 19M6G7D | 24E |
| 1852.5-1907.5 MHz | 0.155 | 0.0064ppm | 19M5W7D | 24E |
Grants
TCB Grant - Application Elmb1OMuswzNm7IkhW9KMg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bureau Veritas Consumer Products Services, Inc. 775 Montague Expressway Milpitas, CA 95035 |
Date of Grant: 05/10/2016 Application Dated: 05/10/2016 |
| Quectel Wireless Solutions Company Limited |
| Building 5, Shanghai Business Park PhaseIII |
| (Area B),No.1016 Tianlin Road, Minhang District |
| Shanghai, 200233 China |
| Attention: Jean Hu |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XMR201603EC20 |
| Name of Grantee: | Quectel Wireless Solutions Company Limited |
| Equipment Class: | PCS Licensed Transmitter |
| Notes: | Multi-mode LTE module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 22H | 824.2 - 848.8 | 1.714 | 0.0251 PM | 322KGXW | |
| 24E | 1850.2 - 1909.8 | 0.738 | 0.0122 PM | 323KGXW | |
| 22H | 826.4 - 846.6 | 0.209 | 0.0132 PM | 4M73F9W | |
| 27 | 1712.4 - 1752.6 | 0.17 | 0.0058 PM | 4M71F9W | |
| 24E | 1852.4 - 1907.6 | 0.168 | 0.0043 PM | 4M70F9W | |
| 24E | 1852.5 - 1907.5 | 0.162 | 0.0064 PM | 19M6G7D | |
| 24E | 1852.5 - 1907.5 | 0.155 | 0.0064 PM | 19M5W7D | |
| 27 | 1712.5 - 1752.5 | 0.166 | 0.0092 PM | 1M31G7D | |
| 27 | 1712.5 - 1752.5 | 0.156 | 0.0092 PM | 19M4G7D | |
| 27 | 1712.5 - 1752.5 | 0.135 | 0.0092 PM | 19M6W7D | |
| 27 | 1712.5 - 1752.5 | 0.139 | 0.0092 PM | 14M9W7D | |
| 22H | 826.5 - 846.5 | 0.195 | 0.0155 PM | 5M06G7D | |
| 22H | 826.5 - 846.5 | 0.19 | 0.0155 PM | 10M2G7D | |
| 22H | 826.5 - 846.5 | 0.161 | 0.0155 PM | 10M1W7D | |
| 27 | 699.7 - 715.3 | 0.182 | 0.0064 PM | 1M34G7D | |
| 27 | 699.7 - 715.3 | 0.181 | 0.0064 PM | 10M1G7D | |
| 27 | 699.7 - 715.3 | 0.146 | 0.0064 PM | 10M3W7D | |
| 27 | 699.7 - 715.3 | 0.149 | 0.0064 PM | 3M16W7D | |
| 27 | 706.5 - 713.5 | 0.176 | 0.0155 PM | 5M14G7D | |
| 27 | 706.5 - 713.5 | 0.169 | 0.0155 PM | 10M1G7D | |
| 27 | 706.5 - 713.5 | 0.148 | 0.0155 PM | 10M1W7D | |
| 27 | 706.5 - 713.5 | 0.15 | 0.0155 PM | 5M10W7D |
| Single Modular Approval. Output power is conducted. This device is to be used in mobile or fixed applications only. Antenna gain including cable loss must not exceed 10.69 dBi of frequency band 699-716MHz, 5.95 dBi of frequency band 824-849MHz, 6.5 dBi of frequency band 1710-1755MHz, 3.5 dBi of frequency band 1850-1910MHz,for the purpose of satisfying the requirements of 2.1043 and 2.1091. They operate at frequencies of 1.5 GHz or below and their effective radiated power (ERP) is 1.5 watts or more, or they operate at frequencies above 1.5 GHz and their ERP is 3 watts or more. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operated in conjunction with any antenna or transmitter not described under this FCC ID. The final product operating with this transmitter must include operating instructions and antenna installation instructions, for end-users and installers to satisfy RF exposure compliance requirements. Compliance of this device in all final product configurations is the responsibility of the Grantee. Installation of this device into specific final products may require the submission of a Class II permissive change application containing data pertinent to RF Exposure, spurious emissions, ERP/EIRP, and host/module authentication, or new application if appropriate. Installation of this device into specific final products may require the submission of a Class II permissive change application containing data pertinent to RF Exposure, spurious emissions, ERP/EIRP, and host/module authentication, or new application if appropriate. |
