FCC ID XMR201609MC60
GSM/GPRS/GNSS Module
by Quectel Wireless Solutions Company Limited
Grantee Code: XMR Product Code: 201609MC60
Latest application date: 2018-05-29
Device Images
FCC ID Device Details
| FCC ID | XMR201609MC60 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | XMR |
| Product Code | 201609MC60 |
| Applicant Business | Quectel Wireless Solutions Company Limited 🇨🇳 |
| Related Domains |  quectel.com |
| Equipment Class | GSM/GPRS/GNSS Module |
| Test Firm | Element Materials Technology |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 824.2-848.8 MHz | Class II permissive change or modification of presently authorized equipment | 2018-05-29 |
| 824.2-848.8 MHz | Original Equipment | 2016-10-18 |
| 2402-2480 MHz | Original Equipment | 2016-10-18 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-10-18 | PDF 2.8 MB |
| Internal Photos | Internal Photos | 2016-10-18 | PDF 129.3 KB |
| External Photos | External Photos | 2016-10-18 | PDF 178 KB |
| Label | ID Label/Location Info | 2018-05-29 | PDF 102.2 KB |
| Label Location | ID Label/Location Info | 2018-05-29 | PDF 127.9 KB |
| Label & Label Location | ID Label/Location Info | 2016-10-18 | PDF 1,018 KB |
| Test Set-up Photos | Test Setup Photos | 2018-05-29 | PDF 248.8 KB |
| RF Test Set-Up Photos | Test Setup Photos | 2016-10-18 | PDF 157.8 KB |
| RF Test Set-up Photos | Test Setup Photos | 2016-10-18 | PDF 132.7 KB |
| SAR Test Report | Test Report | 2018-05-29 | PDF 4.4 MB |
| RF Test Report | Test Report | 2016-10-18 | PDF 1.6 MB |
| RF Test Report | Test Report | 2016-10-18 | PDF 643 KB |
| Agent Authorization | Attestation Statements | 2018-05-29 | PDF 147.9 KB |
| Class II Change Request | Cover Letter(s) | 2018-05-29 | PDF 157.5 KB |
| Confidentiality Request | Cover Letter(s) | 2018-05-29 | PDF 196.9 KB |
| Authorization Letter | Cover Letter(s) | 2016-10-18 | PDF 46 KB |
| LTC Letter | Cover Letter(s) | 2016-10-18 | PDF 47.7 KB |
| Modular Approval letter | Cover Letter(s) | 2016-10-18 | PDF 30.3 KB |
| RF Exposure Report | RF Exposure Info | 2016-10-18 | PDF 176.4 KB |
| RF Exposure report | RF Exposure Info | 2016-10-18 | PDF 176.4 KB |
| Block Diagram Metadata only | Block Diagram | PDF 215.6 KB | |
| Schematics Metadata only | Schematics | PDF 101.7 KB | |
| Operational Description Metadata only | Operational Description | PDF 137.9 KB | |
| BOM Metadata only | Parts List/Tune Up Info | PDF 40.7 KB | |
| Tune up procedure Metadata only | Parts List/Tune Up Info | PDF 139 KB |
Application Information
| Application ID | gT6AOkOcmog3dhEmKoBryg== |
|---|---|
| Final Action Date | 2018-05-29 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0018988279 |
| Model | 201609MC60 |
| Frequency Range | 824.2-848.8 MHz |
| Equipment Class | PCB - PCS Licensed Transmitter |
| Device Description | GSM/GPRS/GNSS Module |
| Responsible Party | Jean Hu, jean.hu@quectel.com , +8602150086326 |
| Test Firm | Renee Walker, Element Materials Technology, renee.walker@element.com  , 503-844-4066 |
| TCB Email | Philip.Thompson@element.com |
| TCB Scope | B1: Commercial mobile radio services equipment in the following 47 CFR Parts 20, 22 (cellular), 24,25 (below 3 GHz) & 27 |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | Yes |
| Composite Part | Yes |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power output is conducted at the antenna terminal. Single Limited Modular Approval. Class II Permissive change to add portable use with Gas Control Equipment Limited, model RS-00500C. 2.4 GHz band (BT+WiFi) of this module is disabled by software in this host device. Output power was reduced by 4 dB for 22H and 2dB for Part 24E. Antenna gain, including cable loss, must not exceed 3.50dBi at 850/1900 MHz for satisfying RF exposure compliance. Under no condition may an antenna gain be used that would exceed the 7W ERP Part 22 and the 2W EIRP Part 24 power limits. The Grantee is responsible for providing the documentation required for modular use. The responsibility for the use of this module, in all configurations utilized or contemplated, remains with the Grantee. This module can only be used with a host antenna circuit trace layout design in strict compliance with the OEM instructions provided. The highest SAR for stand-alone transmission exposure condition for 22H and 24E are 1.50 W/kg and 1.41 W/kg respectively. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| gT6AOkOcmog3dhEmKoBryg== | 2018-05-29 | Class II permissive change or modification of presently authorized equipment |
| cyahVNRLQA22Rfz7OD+ylw== | 2016-10-18 | Original Equipment |
| ASr5lEehvbR8vqraBx13/A== | 2016-10-18 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application gT6AOkOcmog3dhEmKoBryg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Element Materials Technology Warwick Ltd Rothwell Road Warwick Warwick, CV34 5JX United Kingdom |
Date of Grant: 05/29/2018 Application Dated: 05/29/2018 |
| Quectel Wireless Solutions Company Limited |
| Building 5, Shanghai Business Park PhaseIII |
| (Area B),No.1016 Tianlin Road, Minhang District |
| Shanghai, 200233 China |
| Attention: Jean Hu |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XMR201609MC60 |
| Name of Grantee: | Quectel Wireless Solutions Company Limited |
| Equipment Class: | PCS Licensed Transmitter |
| Notes: | GSM/GPRS/GNSS Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 22H | 824.2 - 848.8 | 1.374 | 0.0251 PM | 318KGXW | |
| 22H | 824.2 - 848.8 | 1.371 | 0.0251 PM | 320KG7W | |
| 24E | 1850.2 - 1909.8 | 0.74 | 0.0106 PM | 325KGXW | |
| 24E | 1850.2 - 1909.8 | 0.736 | 0.0112 PM | 32KG7W |
| Power output is conducted at the antenna terminal. Single Limited Modular Approval. Class II Permissive change to add portable use with Gas Control Equipment Limited, model RS-00500C. 2.4 GHz band (BT+WiFi) of this module is disabled by software in this host device. Output power was reduced by 4 dB for 22H and 2dB for Part 24E. Antenna gain, including cable loss, must not exceed 3.50dBi at 850/1900 MHz for satisfying RF exposure compliance. Under no condition may an antenna gain be used that would exceed the 7W ERP Part 22 and the 2W EIRP Part 24 power limits. The Grantee is responsible for providing the documentation required for modular use. The responsibility for the use of this module, in all configurations utilized or contemplated, remains with the Grantee. This module can only be used with a host antenna circuit trace layout design in strict compliance with the OEM instructions provided. The highest SAR for stand-alone transmission exposure condition for 22H and 24E are 1.50 W/kg and 1.41 W/kg respectively. |
