2023SC200EGL Smart Module Label Diagram - FCC ID XMR2023SC200EGL

FCC ID XMR2023SC200EGL

Label

Smart Module

by Quectel Wireless Solutions Company Limited

Barcode information

Validated product identifiers extracted from the generated document image; label documents may also include identifiers from available document text.

QR Code ]Q1

Barcode typeQR Code ]Q1
Decoded value8611080300XXXXX;E186719750XXXXX;34873D109DF4;;8611080300XXXXX;34873D109DF4;

Document preview loads when visible.

Document Details

FCC IDXMR2023SC200EGL
Document ID6917827
Document TypeID Label/Location Info
DescriptionLabel
ApplicantQuectel Wireless Solutions Company Limited
Equipment ClassSmart Module
Product Code2023SC200EGL
Application IDpxRHnT1kOgy4Uf1fyci5qQ==
Application PurposeOriginal Equipment
Application Date2023-11-14
Frequency Range1712.4-1752.6 MHz
FRN0018988279
Test FirmSGS-CSTC Standards Technical Services (Suzhou) Co.
Certified ByParlam Zhan Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date05/12/2024
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceYes
Composite PartNo
Submitted2023-11-14
Available2023-11-14
Created2023-10-30
Modified2023-11-06
Pages1
File TypeAdobe Acrobat PDF
File Size124356
File SHA-256f3be30d4d66ce5173e380e52f159fad5b38b1e90bc81cf88e7fca2eca876f642
PDF Metadata AuthorShen, Nature (Suzhou)
PDF Metadata ProducerMicrosoft® Word for Microsoft 365 Shen, Nature (Suzhou)
FCC.gov SourcesFCC.gov 6917827, FCC.gov 6917425, FCC.gov 6917336, FCC.gov 6917242
