WUP01 Data Hub External Photos - FCC ID XNAWUP01
FCC ID XNAWUP01
External Photos
Data Hub
by Withings
Document preview loads when visible.
Document Details
| FCC ID | XNAWUP01 |
|---|---|
| Document ID | 5385567 |
| Document Type | External Photos |
| Description | External Photos |
| Applicant | Withings |
| Equipment Class | Data Hub |
| Product Code | WUP01 |
| Application ID | 5MAStzA7xjUrhDOLNRGLQA== |
| Application Purpose | Class II Permissive Change |
| Application Date | 2021-08-15 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0018997460 |
| Test Firm | International Certification Corp. |
| Certified By | Gary Chang Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 02/08/2022 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2021-08-11 |
| Available | 2022-02-08 |
| Created | 2021-07-26 |
| Modified | 2021-07-26 |
| Pages | 6 |
| File Type | Adobe Acrobat PDF |
| File Size | 986157 |
| File SHA-256 | bb959c150620331a7bd3d7c2741fe9f5027b4d21e6e9ce4cf00c14effbe5ee4c |
| PDF Metadata Producer | Microsoft® Word 2013 Microsoft® Word 2013 |
| FCC.gov Sources | FCC.gov 5385567, FCC.gov 5385549 |
