MD102AD 2.4GHz ZigBee Wireless Module Test... - FCC ID XNNMD102AD

FCC ID XNNMD102AD

Test setup photo

2.4GHz ZigBee Wireless Module

by JOYMAX ELECTRONICS CO., LTD.

Document preview loads when visible.

Document Details

FCC IDXNNMD102AD
Document ID1541062
Document TypeTest Setup Photos
DescriptionTest setup photo
Document TitleFR151901-01_APPENDIX A. TEST PHOTOS
ApplicantJOYMAX ELECTRONICS CO., LTD.
Equipment Class2.4GHz ZigBee Wireless Module
Product CodeMD102AD
Application IDGjiys3YjflokokKflQHaAA==
Application PurposeOriginal Equipment
Application Date2011-09-15
Frequency Range2405-2480 MHz
FRN0022478168
Test FirmSPORTON International Inc.
Certified ByLeo Huang Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2011-09-14
Available2011-09-15
Created2011-08-16
Modified2011-09-09
Pages6
File TypeAdobe Acrobat PDF
File Size564512
File SHA-256b2cc25b2aefdb878aebe715bdf5d667e5e4dc27014a61ca15f4389befed92502
PDF Metadata AuthorVickyHuang
PDF Metadata CreatorPScript5.dll Version 5.2.2
PDF Metadata ProducerAcrobat Distiller 9.0.0 (Windows)
FCC.gov SourcesFCC.gov 1541062
