FCC ID XO2BOX860
WiFi Interactive Toy
by H&D; Wireless AB
Grantee Code: XO2 Product Code: BOX860
Latest application date: 2015-12-16
Device Images
FCC ID Device Details
| FCC ID | XO2BOX860 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | XO2 |
| Product Code | BOX860 |
| Applicant Business | H&D; Wireless AB 🇸🇪 |
| Related Domains |  hd-wireless.se |
| Equipment Class | WiFi Interactive Toy |
| Test Firm | SP Technical Research Institute of Sweden |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2015-12-16 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Installation manual/ Data sheet | Users Manual | 2015-12-16 | PDF 999.1 KB |
| Internal photos | Internal Photos | 2015-12-16 | PDF 784.8 KB |
| External photos | External Photos | 2015-12-16 | PDF 566.8 KB |
| Id label | ID Label/Location Info | 2015-12-16 | PDF 470.8 KB |
| Block Diagram | Block Diagram | 2015-12-16 | PDF 376.8 KB |
| Test setup photos | Test Setup Photos | 2015-12-16 | PDF 2.1 MB |
| Test report | Test Report | 2015-12-16 | PDF 5.2 MB |
| Modular approval statement | Attestation Statements | 2015-12-16 | PDF 510.5 KB |
| Confidentiality request | Cover Letter(s) | 2015-12-16 | PDF 405.2 KB |
| BOX860 Application Note Assembly | RF Exposure Info | 2015-12-16 | PDF 602.1 KB |
| SAR Exclusion calculations | RF Exposure Info | 2015-12-16 | PDF 227.8 KB |
| Conf Schematics Metadata only | Schematics | PDF 257 KB | |
| Conf Operational Description Metadata only | Operational Description | PDF 344.2 KB | |
| Conf Parts List Metadata only | Parts List/Tune Up Info | PDF 352.8 KB |
Application Information
| Application ID | dmtwBWaHi7znNqe1wRHn7w== |
|---|---|
| Final Action Date | 2015-12-16 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0019049824 |
| Model | BOX860 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | WiFi Interactive Toy |
| Responsible Party | Paer Bergsten, CEO, par.bergsten@hd-wireless.se , +46 708 274 557 |
| Technical Contact | Ake Jernberger, H&D; Wireless AB, ake.jernberger@hd-wireless.se , +46855118467 |
| Test Firm | Magnus Winehem, SP Technical Research Institute of Sweden, magnus.winehem@sp.se  , 46-10-516-53-71 |
| TCB Email | tcb@sp.se |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Modular Approval. Power listed is conducted. This device must be installed to provide a separation distance of at least 20mm between the box edge and any body part of the user and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators and End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| dmtwBWaHi7znNqe1wRHn7w== | 2015-12-16 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2412-2462 MHz | 0.0398000 | 15C |
Grants
TCB Grant - Application dmtwBWaHi7znNqe1wRHn7w==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
RISE Research Institutes of Sweden AB Box 878 S-50115 Boraas, S-501 15 Sweden |
Date of Grant: 12/16/2015 Application Dated: 12/16/2015 |
| H&D Wireless AB |
| Faeroegatan 33 |
| Kista, 164 51 Sweden |
| Attention: Paer Bergsten , CEO |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XO2BOX860 |
| Name of Grantee: | H&D Wireless AB |
| Equipment Class: | Digital Transmission System |
| Notes: | WiFi Interactive Toy |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.0398 |
| Modular Approval. Power listed is conducted. This device must be installed to provide a separation distance of at least 20mm between the box edge and any body part of the user and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators and End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators. |
EAS Grant - Application dmtwBWaHi7znNqe1wRHn7w==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
H&D Wireless AB Faeroegatan 33 Kista, 164 51 Sweden |
Date of Grant: 12/16/2015 Application Dated: 12/16/2015 |
| Attention: Paer Bergsten , CEO |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XO2BOX860 |
| Name of Grantee: | H&D Wireless AB |
| Equipment Class: | Digital Transmission System |
| Notes: | WiFi Interactive Toy |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.0398 |
| Modular Approval. Power listed is conducted. This device must be installed to provide a separation distance of at least 20mm between the box edge and any body part of the user and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators and End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators. |
