FCC ID XPF-REG09-UTT
ACCESS POINT
by SHANGHAI UTT TECHNOLOGIES CO., LTD.
Grantee Code: XPF Product Code: REG09UTT
Latest application date: 2016-07-18
Device Images
FCC ID Device Details
| FCC ID | XPF-REG09-UTT |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | XPF |
| Product Code | REG09UTT |
| Applicant Business | SHANGHAI UTT TECHNOLOGIES CO., LTD. 🇨🇳 |
| Related Domains |  utt.com.cn |
| Equipment Class | ACCESS POINT |
| Test Firm | Compliance Certification Services (Shenzhen) Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-07-18 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| 10 user manual | Users Manual | 2016-07-18 | PDF 3.3 MB |
| 03 internal photos | Internal Photos | 2016-07-18 | PDF 1 MB |
| 02 external photos | External Photos | 2016-07-18 | PDF 804.8 KB |
| 04 label and label location | ID Label/Location Info | 2016-07-18 | PDF 1.4 MB |
| 09 test setup photos | Test Setup Photos | 2016-07-18 | PDF 713.5 KB |
| 08 test report 2.4gwlan part 1 | Test Report | 2016-07-18 | PDF 4.6 MB |
| 08 test report 2.4gwlan part 2 | Test Report | 2016-07-18 | PDF 5.2 MB |
| 12 declaration letter of not use channel 12 and 13 | Cover Letter(s) | 2016-07-18 | PDF 77.9 KB |
| confidentiality request letter(permanent) v2.0 | Cover Letter(s) | 2016-07-18 | PDF 76.6 KB |
| 07 mpe report | RF Exposure Info | 2016-07-18 | PDF 1.6 MB |
| 01 block diagram Metadata only | Block Diagram | PDF 158.2 KB | |
| 06 schematic Metadata only | Schematics | PDF 237.1 KB | |
| 05 operation description Metadata only | Operational Description | PDF 113.4 KB |
Application Information
| Application ID | /soU2XpfGAOe5EAx0lgAhw== |
|---|---|
| Final Action Date | 2016-07-18 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0019058197 |
| Model | REG09-UTT |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | ACCESS POINT |
| Responsible Party | Wangcheng Fan, Product manager, fan.wangcheng@utt.com.cn , +86-21-67766500 |
| Test Firm | Harry Li, Compliance Certification Services (Shenzhen) Inc., service@ccssz.com  , 0755280550008601 |
| TCB Email | TCB@cetecom.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is peak conducted. Output Power listed is the maximum combined conducted output power as indicated in the filing. This device supports 802.11b, 802.11g and 802.11n with a 20 MHz and 40 MHz bandwidth mode. Device operates with specific antennas in 2x2 MIMO configurations as described in this filing. RF exposure compliance is addressed for 1.1310 and 2.1091 MPE limits. End Users must be provided with transmitter operation conditions for satisfying RF exposure compliance |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| /soU2XpfGAOe5EAx0lgAhw== | 2016-07-18 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2412-2462 MHz | 0.2120000 | 15C |
Grants
TCB Grant - Application /soU2XpfGAOe5EAx0lgAhw==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
CTC advanced GmbH Untertuerkheimer Strasse 6-10 66117 Saarbruecken, Germany |
Date of Grant: 07/18/2016 Application Dated: 07/18/2016 |
| SHANGHAI UTT TECHNOLOGIES CO., LTD. |
| Room 301, No.9 Building, No.518, |
| Xinzhuan Rd., Songjiang District |
| Shanghai, China |
| Attention: Wangcheng Fan , Product manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XPF-REG09-UTT |
| Name of Grantee: | SHANGHAI UTT TECHNOLOGIES CO., LTD. |
| Equipment Class: | Digital Transmission System |
| Notes: | ACCESS POINT |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.212 |
| Output power listed is peak conducted. Output Power listed is the maximum combined conducted output power as indicated in the filing. This device supports 802.11b, 802.11g and 802.11n with a 20 MHz and 40 MHz bandwidth mode. Device operates with specific antennas in 2x2 MIMO configurations as described in this filing. RF exposure compliance is addressed for 1.1310 and 2.1091 MPE limits. End Users must be provided with transmitter operation conditions for satisfying RF exposure compliance |
EAS Grant - Application /soU2XpfGAOe5EAx0lgAhw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
SHANGHAI UTT TECHNOLOGIES CO., LTD. Room 301, No.9 Building, No.518, Xinzhuan Rd., Songjiang District Shanghai, China |
Date of Grant: 07/18/2016 Application Dated: 07/18/2016 |
| Attention: Wangcheng Fan , Product manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XPF-REG09-UTT |
| Name of Grantee: | SHANGHAI UTT TECHNOLOGIES CO., LTD. |
| Equipment Class: | Digital Transmission System |
| Notes: | ACCESS POINT |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.212 |
| Output power listed is peak conducted. Output Power listed is the maximum combined conducted output power as indicated in the filing. This device supports 802.11b, 802.11g and 802.11n with a 20 MHz and 40 MHz bandwidth mode. Device operates with specific antennas in 2x2 MIMO configurations as described in this filing. RF exposure compliance is addressed for 1.1310 and 2.1091 MPE limits. End Users must be provided with transmitter operation conditions for satisfying RF exposure compliance |
| Mail To: |
