FCC ID XS7WRE5500
Five-Band Bi-Directional Direct Connect Cellular Amplifier
by Clear RF, LLC
Grantee Code: XS7 Product Code: WRE5500
Latest application date: 2017-03-02
Device Images
FCC ID Device Details
| FCC ID | XS7WRE5500 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | XS7 |
| Product Code | WRE5500 |
| Applicant Business | Clear RF, LLC 🇺🇸 |
| Related Domains |  servatron.com |
| Equipment Class | Five-Band Bi-Directional Direct Connect Cellular Amplifier |
| Test Firm | Compliance Testing, LLC |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 698-716 MHz | Original Equipment | 2017-03-02 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Manual | Users Manual | 2017-03-02 | PDF 540.5 KB |
| Internal Photos | Internal Photos | 2017-03-02 | PDF 472.9 KB |
| External Photos | External Photos | 2017-03-02 | PDF 465 KB |
| Label_Label Location | ID Label/Location Info | 2017-03-02 | PDF 468.5 KB |
| Test Setup Photos | Test Setup Photos | 2017-03-02 | PDF 450.7 KB |
| Annex A_Part 20 | Test Report | 2017-03-02 | PDF 596.5 KB |
| Annex B_Part 20 | Test Report | 2017-03-02 | PDF 609.4 KB |
| Annex C_Part 20 | Test Report | 2017-03-02 | PDF 2.6 MB |
| Annex D_Part 20 | Test Report | 2017-03-02 | PDF 1.4 MB |
| Annex E_Part 20 | Test Report | 2017-03-02 | PDF 571.4 KB |
| Annex F_Part 20 | Test Report | 2017-03-02 | PDF 339 KB |
| Annex G_Part 20 | Test Report | 2017-03-02 | PDF 2.7 MB |
| Annex H_Part 20 | Test Report | 2017-03-02 | PDF 238.8 KB |
| FCC Part 1.1310 Test Report | RF Exposure Info | 2017-03-02 | PDF 414.8 KB |
| FCC Part 20 Test Report | Test Report | 2017-03-02 | PDF 568 KB |
| Part 20 Attestation | Attestation Statements | 2017-03-02 | PDF 43.7 KB |
| 4G Elbow Mount Antenna | Cover Letter(s) | 2017-03-02 | PDF 51.6 KB |
| Agent Authorization | Cover Letter(s) | 2017-03-02 | PDF 35.3 KB |
| Confidentiality Request | Cover Letter(s) | 2017-03-02 | PDF 45.3 KB |
| L33 Mag Mount Antenna | Cover Letter(s) | 2017-03-02 | PDF 110.2 KB |
| MSE-5721-001 Datasheet | Cover Letter(s) | 2017-03-02 | PDF 24.7 KB |
| BOM Metadata only | Block Diagram | PDF 175.5 KB | |
| Schematics Metadata only | Schematics | PDF 265.3 KB | |
| Theory of Operation Metadata only | Operational Description | PDF 493 KB | |
| Tune-Up Procedure Metadata only | Parts List/Tune Up Info | PDF 31.2 KB |
Application Information
| Application ID | xd3hwF+Pm5Go7JfeQ1/jCw== |
|---|---|
| Final Action Date | 2017-03-02 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0020041091 |
| Model | WRE5500 |
| Frequency Range | 698-716 MHz |
| Equipment Class | B2W - Part 20 Wideband Consumer Booster (CMRS) |
| Device Description | Five-Band Bi-Directional Direct Connect Cellular Amplifier |
| Responsible Party | SHAWN TAYLOR, Chief Operating Officer, shawn.taylor@servatron.com , 509-321-9520 |
| Agent | Amanda Amanda Amanda, Compliance Testing, LLC, 480-926-3100 |
| Test Firm | Michael Schafer, Compliance Testing, LLC, michaels@compliancetesting.com  , 480-926-3100 |
| TCB Email | amandar@compliancetesting.com |
| TCB Scope | B1: Commercial mobile radio services equipment in the following 47 CFR Parts 20, 22 (cellular), 24,25 (below 3 GHz) & 27 |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is conducted at antenna terminals. The antennas used with this signal booster must be installed to provide a separation distance of at least 20 cm from all persons. Users and installers must be provided with the antenna kitting and installation instructions and operating conditions for satisfying RF exposure compliance. This device is a Wideband Direct Connect Consumer Signal Booster authorized only for operation by and marketing to members of the general public for their personal use in accordance with the requirements of 47 CFR 20.21(a) and 20.21(g). The installation height of the antenna for AWS band (1700/2100 MHz) operations is limited to 10 meters above ground for compliance with Section 27.50 |
