FCC ID XYOPCDPH02F
GSM Quad band and UMTS 850/1900MHz fixed wireless phone
by Asiatelco Technologies Co.
Grantee Code: XYO Product Code: PCDPH02F
Latest application date: 2016-03-31
Device Images
FCC ID Device Details
| FCC ID | XYOPCDPH02F |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | XYO |
| Product Code | PCDPH02F |
| Applicant Business | Asiatelco Technologies Co. 🇨🇳 |
| Related Domains |  asiatelco.com |
| Equipment Class | GSM Quad band and UMTS 850/1900MHz fixed wireless phone |
| Test Firm | Global United Technology Service Co., Ltd |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-03-31 |
| 2412-2462 MHz | Original Equipment | 2016-03-31 |
| 824.2-848.8 MHz | Original Equipment | 2016-03-31 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2016-03-31 | PDF 682 KB |
| Internal photos | Internal Photos | 2016-03-31 | PDF 491.8 KB |
| External photos | External Photos | 2016-03-31 | PDF 298.2 KB |
| Label | ID Label/Location Info | 2016-03-31 | PDF 365.3 KB |
| Label location | ID Label/Location Info | 2016-03-31 | PDF 77.8 KB |
| Test setup | Test Setup Photos | 2016-03-31 | PDF 122.1 KB |
| Test setup | Test Setup Photos | 2016-03-31 | PDF 120.7 KB |
| Test report | Test Report | 2016-03-31 | PDF 2.1 MB |
| Test report | Test Report | 2016-03-31 | PDF 1.6 MB |
| Test report | Test Report | 2016-03-31 | PDF 979.9 KB |
| Cover letter | Cover Letter(s) | 2016-03-31 | PDF 209.8 KB |
| SAR report part 1 | RF Exposure Info | 2016-03-31 | PDF 3.2 MB |
| SAR report part 2 | RF Exposure Info | 2016-03-31 | PDF 498.2 KB |
| Block Diagram Metadata only | Block Diagram | PDF 108.3 KB | |
| Schematics Metadata only | Schematics | PDF 101.2 KB | |
| Operational Description Metadata only | Operational Description | PDF 258.5 KB | |
| Tune up Metadata only | Parts List/Tune Up Info | PDF 32.7 KB |
Application Information
| Application ID | WeeqeEXbdsJxLkc2Emst0g== |
|---|---|
| Final Action Date | 2016-03-31 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0019360338 |
| Model | PCDPH02F |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DSS - Part 15 Spread Spectrum Transmitter |
| Device Description | GSM Quad band and UMTS 850/1900MHz fixed wireless phone |
| Responsible Party | Ranran Zhou, Project Manager, certification@asiatelco.com , +86-21-51688806 |
| Test Firm | Robinson Lo, Global United Technology Service Co., Ltd, robinson.lo@gtstest.com  , 86-755-27798480 |
| TCB Email | stuart.beck@nemko.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | Yes |
| Grant Comments | Output power listed is conducted. End-users must be informed of the operating requirements for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| WeeqeEXbdsJxLkc2Emst0g== | 2016-03-31 | Original Equipment |
| MJrQALFY2oEZhtnGTEZoMA== | 2016-03-31 | Original Equipment |
| //aUrYoNo1U8hRMRHqAXbw== | 2016-03-31 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application WeeqeEXbdsJxLkc2Emst0g==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Nemko North America, INC. 303 River Road Ottawa, Ontario, K1V 1H2 Canada |
Date of Grant: 03/31/2016 Application Dated: 03/31/2016 |
| Asiatelco Technologies Co. |
| 289 Bisheng Road, Building 8, 3F, |
| Zhangjiang Hi-Tech Park, Pudong |
| Shanghai, 201204 China |
| Attention: Ranran Zhou , Project Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XYOPCDPH02F |
| Name of Grantee: | Asiatelco Technologies Co. |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | GSM Quad band and UMTS 850/1900MHz fixed wireless phone |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.00413 |
| Output power listed is conducted. End-users must be informed of the operating requirements for satisfying RF exposure compliance. |
EAS Grant - Application WeeqeEXbdsJxLkc2Emst0g==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Asiatelco Technologies Co. 289 Bisheng Road, Building 8, 3F, Zhangjiang Hi-Tech Park, Pudong Shanghai, 201204 China |
Date of Grant: 03/31/2016 Application Dated: 03/31/2016 |
| Attention: Ranran Zhou , Project Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XYOPCDPH02F |
| Name of Grantee: | Asiatelco Technologies Co. |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | GSM Quad band and UMTS 850/1900MHz fixed wireless phone |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.00413 |
| Output power listed is conducted. End-users must be informed of the operating requirements for satisfying RF exposure compliance. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Nemko North America, INC. 303 River Road Ottawa, Ontario, K1V 1H2 Canada |
Date of Grant: 03/31/2016 Application Dated: 03/31/2016 |
| Asiatelco Technologies Co. |
| 289 Bisheng Road, Building 8, 3F, |
| Zhangjiang Hi-Tech Park, Pudong |
| Shanghai, 201204 China |
| Attention: Ranran Zhou , Project Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XYOPCDPH02F |
| Name of Grantee: | Asiatelco Technologies Co. |
| Equipment Class: | Digital Transmission System |
| Notes: | GSM Quad band and UMTS 850/1900MHz fixed wireless phone |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.0746 | |||
| 15C | 2422.0 - 2452.0 | 0.0598 |
| Output power listed is conducted. The highest reported SAR for stand-alone and simultaneous transmission exposure conditions are < 0.10 W/kg and 1.11 W/kg, respectively. End-users must be informed of the operating requirements for satisfying RF exposure compliance. |
EAS Grant - Application MJrQALFY2oEZhtnGTEZoMA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Asiatelco Technologies Co. 289 Bisheng Road, Building 8, 3F, Zhangjiang Hi-Tech Park, Pudong Shanghai, 201204 China |
Date of Grant: 03/31/2016 Application Dated: 03/31/2016 |
| Attention: Ranran Zhou , Project Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XYOPCDPH02F |
| Name of Grantee: | Asiatelco Technologies Co. |
| Equipment Class: | Digital Transmission System |
| Notes: | GSM Quad band and UMTS 850/1900MHz fixed wireless phone |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.0746 | |||
| 15C | 2422.0 - 2452.0 | 0.0598 |
| Output power listed is conducted. The highest reported SAR for stand-alone and simultaneous transmission exposure conditions are < 0.10 W/kg and 1.11 W/kg, respectively. End-users must be informed of the operating requirements for satisfying RF exposure compliance. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Nemko North America, INC. 303 River Road Ottawa, Ontario, K1V 1H2 Canada |
Date of Grant: 03/31/2016 Application Dated: 03/30/2016 |
| Asiatelco Technologies Co. |
| 289 Bisheng Road, Building 8, 3F, |
| Zhangjiang Hi-Tech Park, Pudong |
| Shanghai, 201204 China |
| Attention: Ranran Zhou , Project Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XYOPCDPH02F |
| Name of Grantee: | Asiatelco Technologies Co. |
| Equipment Class: | PCS Licensed Transmitter |
| Notes: | GSM Quad band and UMTS 850/1900MHz fixed wireless phone |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 22H | 824.2 - 848.8 | 1.714 | 0.05 PM | 248KGXW | |
| 22H | 826.4 - 846.6 | 0.213 | 0.15 PM | 4M18F9W | |
| 24E | 1850.2 - 1909.8 | 0.774 | 0.06 PM | 254KGXW | |
| 24E | 1852.4 - 1907.6 | 0.196 | 0.04 PM | 4M18F9W |
| Power listed is ERP for Part 22 and EIRP for Part 24. The highest reported SAR for stand-alone and simultaneous transmission exposure conditions are 1.04 W/kg and 1.11 W/kg, respectively. End-users must be informed of the operating requirements for satisfying RF exposure compliance. This device contains functions that are not operational in the U.S. Territories. This filing is only applicable for U.S. operations. |
EAS Grant - Application //aUrYoNo1U8hRMRHqAXbw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Asiatelco Technologies Co. 289 Bisheng Road, Building 8, 3F, Zhangjiang Hi-Tech Park, Pudong Shanghai, 201204 China |
Date of Grant: 03/31/2016 Application Dated: 03/30/2016 |
| Attention: Ranran Zhou , Project Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XYOPCDPH02F |
| Name of Grantee: | Asiatelco Technologies Co. |
| Equipment Class: | PCS Licensed Transmitter |
| Notes: | GSM Quad band and UMTS 850/1900MHz fixed wireless phone |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 22H | 824.2 - 848.8 | 1.714 | 0.05 PM | 248KGXW | |
| 22H | 826.4 - 846.6 | 0.213 | 0.15 PM | 4M18F9W | |
| 24E | 1850.2 - 1909.8 | 0.774 | 0.06 PM | 254KGXW | |
| 24E | 1852.4 - 1907.6 | 0.196 | 0.04 PM | 4M18F9W |
| Power listed is ERP for Part 22 and EIRP for Part 24. The highest reported SAR for stand-alone and simultaneous transmission exposure conditions are 1.04 W/kg and 1.11 W/kg, respectively. End-users must be informed of the operating requirements for satisfying RF exposure compliance. This device contains functions that are not operational in the U.S. Territories. This filing is only applicable for U.S. operations. |
