FCC ID Y7J-PR500R
Internal EUT Photo
Wireless Presenter
Document preview loads when visible.
Document Details
| FCC ID | Y7J-PR500R |
|---|---|
| Document ID | 3235654 |
| Document Type | Internal Photos |
| Description | Internal EUT Photo |
| Document Title | PR500-RC 2.4G FCC ID Report |
| Applicant | Canon Electronic Business Machines (H.K.) Co., Ltd. |
| Equipment Class | Wireless Presenter |
| Product Code | PR500R |
| Application ID | l2LAxKfS6eoA7LJygG81Jg== |
| Application Purpose | Original Equipment |
| Application Date | 2016-12-21 |
| Frequency Range | 2402-2477 MHz |
| FRN | 0020532453 |
| Test Firm | Dongguan Yaxu (AiT) Technology Limited |
| Certified By | Chi Tat Leung Director R&D; Division |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2016-12-21 |
| Available | 2016-12-21 |
| Created | 2016-12-05 |
| Modified | 2016-12-05 |
| Pages | 4 |
| File Type | Adobe Acrobat PDF |
| File Size | 484119 |
| File SHA-256 | 4bcf9cca045c086b99f74ddc82e88765d85f5f7e8fd46d23ffb23cfc3fec8a1a |
| PDF Metadata Author | Administrator |
| PDF Metadata Producer | Acrobat Distiller 8.1.0 (Windows) Administrator |
| FCC.gov Sources | FCC.gov 3235654 |
