AIVISBX0 Navigation System with Bluetooth... - FCC ID YBN-AIVISBX0

FCC ID YBN-AIVISBX0

Test report DFS

Navigation System with Bluetooth and WLAN

by Robert Bosch Car Multimedia GmbH

Document preview loads when visible.

Document Details

FCC IDYBN-AIVISBX0
Document ID4248620
Document TypeTest Report
DescriptionTest report DFS
Document TitleTest Report No.: 2-___a/__
ApplicantRobert Bosch Car Multimedia GmbH
Equipment ClassNavigation System with Bluetooth and WLAN
Product CodeAIVISBX0
Application IDJqu51EN9dorrzI11XdtMYw==
Application PurposeOriginal Equipment
Application Date2019-04-23
Frequency Range5180-5240 MHz
FRN0019732882
Test FirmCETECOM GmbH
Certified ByDirk Zamow
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2019-04-23
Available2019-04-23
Created2018-12-14
Modified2018-12-17
Pages25
File TypeAdobe Acrobat PDF
File Size1032996
File SHA-2562b30dd22bfcd6aeabfa6971dd298e13ad538e78f0e575126ea472eb7e051aa57
PDF Metadata AuthorLorenz, Christian [CETECOM] CETECOM GmbH
PDF Metadata ProducerNuance PDF Create Lorenz, Christian [CETECOM]
FCC.gov SourcesFCC.gov 4248620
