FCC ID YCPNFC03A1
NFC card reader board
by STMicroelectronics SAS
Grantee Code: YCP Product Code: NFC03A1
Latest application date: 2016-07-20
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 13.56 MHz | Original Equipment | 2016-07-20 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-07-20 | PDF 1.7 MB |
| Internal Photos | Internal Photos | 2016-07-20 | PDF 1.7 MB |
| External Photos | External Photos | 2016-07-20 | PDF 1.7 MB |
| Label Location | ID Label/Location Info | 2016-07-20 | PDF 563.4 KB |
| Label Sample | ID Label/Location Info | 2016-07-20 | PDF 563.4 KB |
| Block Diagram | Block Diagram | 2016-07-20 | PDF 33.2 KB |
| Schematics | Schematics | 2016-07-20 | PDF 161.2 KB |
| Operational Description | Operational Description | 2016-07-20 | PDF 14.9 KB |
| Test Setup Photos | Test Setup Photos | 2016-07-20 | PDF 208 KB |
| Test Report | Test Report | 2016-07-20 | PDF 2.1 MB |
| Cover Letter | Cover Letter(s) | 2016-07-20 | PDF 215.1 KB |
| POA | Cover Letter(s) | 2016-07-20 | PDF 84.9 KB |
| Parts List | Parts List/Tune Up Info | 2016-07-20 | PDF 32.3 KB |
Application Information
| Application ID | QWjzJHTjNMtj8OpMSZ7pnQ== |
|---|---|
| Final Action Date | 2016-07-20 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0019756717 |
| Model | NFC03A1 |
| Frequency Range | 13.56 MHz |
| Equipment Class | DXX - Part 15 Low Power Communication Device Transmitter |
| Device Description | NFC card reader board |
| Responsible Party | JOEL HULOUX, Director Lobbying & Standardization, joel.huloux@st.com  , +33442688625 |
| Test Firm | Olivier HEYER, EMITECH Montpellier, o.heyer@emitech-group.com  , 33-4-67-871102 |
| TCB Email | tei@timcoengr.com  |
| TCB Scope | A1: Low Power Transmitters below 1 GHz (except Spread Spectrum), Unintentional Radiators, EAS (Part 11) & Consumer ISM devices |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | This equipment is for use by developers for evaluation purposes only and must not be incorporated into any other device or system. This device may not be sold to the general public. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| QWjzJHTjNMtj8OpMSZ7pnQ== | 2016-07-20 | Original Equipment |
Equipment Authorization
| Frequency | Rules |
|---|---|
| 13.56 MHz | 15C |
Grants
TCB Grant - Application QWjzJHTjNMtj8OpMSZ7pnQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 07/20/2016 Application Dated: 07/20/2016 |
| STMicroelectronics SAS |
| 190 Avenue Celestin Coq |
| P.O. Box 13106, |
| Rousset, 13106 France |
| Attention: JOEL HULOUX , Director Lobbying & Standardization |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | YCPNFC03A1 |
| Name of Grantee: | STMicroelectronics SAS |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | NFC card reader board |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 13.56 - 13.56 |
| This equipment is for use by developers for evaluation purposes only and must not be incorporated into any other device or system. This device may not be sold to the general public. |
EAS Grant - Application QWjzJHTjNMtj8OpMSZ7pnQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
STMicroelectronics SAS 190 Avenue Celestin Coq P.O. Box 13106, Rousset, 13106 France |
Date of Grant: 07/20/2016 Application Dated: 07/20/2016 |
| Attention: JOEL HULOUX , Director Lobbying & Standardization |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | YCPNFC03A1 |
| Name of Grantee: | STMicroelectronics SAS |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | NFC card reader board |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 13.56 - 13.56 |
| This equipment is for use by developers for evaluation purposes only and must not be incorporated into any other device or system. This device may not be sold to the general public. |
