H80400 hFon Smart Phone Block Diagram - FCC ID YF9H80400

FCC ID YF9H80400

Block Diagram

hFon Smart Phone

by HMM Heidelberger-Medical-Marketing GmbH

Document preview loads when visible.

Document Details

FCC IDYF9H80400
Document ID1364585
Document TypeBlock Diagram
DescriptionBlock Diagram
Document TitleSCHEMATIC1 : 01_Info
ApplicantHMM Heidelberger-Medical-Marketing GmbH
Equipment ClasshFon Smart Phone
Product CodeH80400
Application IDhoeihKUaEEslhVBGlMZ5Ug==
Application PurposeOriginal Equipment
Application Date2010-10-22
Frequency Range1850.2-1909.8 MHz
FRN0019864479
Test FirmBay Area Compliance Laboratory Corp. (Shenzhen)
Certified ByMaher Khoury
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2010-10-22
Available2010-10-22
Created2010-09-29
Modified2010-10-13
Pages1
File TypeAdobe Acrobat PDF
File Size21861
File SHA-2560ce6822b6f97ed2ab3bbb3e0fdcaf837ba12cf6a9d62371efe9358983b7eb0c1
PDF Metadata AuthorAdministrator
PDF Metadata CreatorPScript5.dll Version 5.2
PDF Metadata ProducerAcrobat Distiller 7.0.5 (Windows)
FCC.gov SourcesFCC.gov 1364585, FCC.gov 1364576, FCC.gov 1364567, FCC.gov 1364557
