FCC ID YHO-PXT51516
Wireless Digital Display
by Spheris Digital Ltd.
Grantee Code: YHO Product Code: PXT51516
Latest application date: 2016-09-19
Device Images
FCC ID Device Details
| FCC ID | YHO-PXT51516 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | YHO |
| Product Code | PXT51516 |
| Applicant Business | Spheris Digital Ltd. |
| Related Domains |  spheris.com.cn |
| Equipment Class | Wireless Digital Display |
| Test Firm | Shenzhen SEM.Test Technology Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-09-19 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-09-19 | PDF 936.9 KB |
| Internal Photos | Internal Photos | 2016-09-19 | PDF 5.9 MB |
| External Photos | External Photos | 2016-09-19 | PDF 387.9 KB |
| Label & Label Location | ID Label/Location Info | 2016-09-19 | PDF 48 KB |
| Test Setup Photos | Test Setup Photos | 2016-09-19 | PDF 202.1 KB |
| SAR Test Report | RF Exposure Info | 2016-09-19 | PDF 1.1 MB |
| Test Report | Test Report | 2016-09-19 | PDF 1.3 MB |
| Confidentiality Request Letter | Cover Letter(s) | 2016-09-19 | PDF 198.4 KB |
| Power of Attorney | Cover Letter(s) | 2016-09-19 | PDF 184.3 KB |
| Exhibit for the Calibration Certificate | RF Exposure Info | 2016-09-19 | PDF 1.5 MB |
| Block Diagram Metadata only | Block Diagram | PDF 219.8 KB | |
| Schematics Metadata only | Schematics | PDF 260.3 KB | |
| Operational Description Metadata only | Operational Description | PDF 172.1 KB |
Application Information
| Application ID | d03t9KVPrJ24ZPGLBwsQsA== |
|---|---|
| Final Action Date | 2016-09-19 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0019898162 |
| Model | PXT51516 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Wireless Digital Display |
| Responsible Party | Herve Robin, Managing Director, herverobin@spheris.com.cn , +86 (010) 84533988 |
| Test Firm | Jandy So, Shenzhen SEM.Test Technology Co., Ltd., jandyso@semtest.com.cn  , 086-755-33663308 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is conducted. SAR compliance for portable use conditions has been evaluated as described in this filing. The antenna(s) used for this transmitter must not transmit simultaneously with any other antenna or transmitter. The highest reported SAR value is 0.67 W/kg. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| d03t9KVPrJ24ZPGLBwsQsA== | 2016-09-19 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2412-2462 MHz | 0.0195000 | 15C |
Grants
TCB Grant - Application d03t9KVPrJ24ZPGLBwsQsA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 09/19/2016 Application Dated: 09/19/2016 |
| Spheris Digital Ltd. |
| Flat B, 18/F., Two Chinachem Plaza, |
| 68 Connaught Road, Central |
| Hong Kong, Hong Kong |
| Attention: Herve Robin , Managing Director |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | YHO-PXT51516 |
| Name of Grantee: | Spheris Digital Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless Digital Display |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.0195 |
| Power listed is conducted. SAR compliance for portable use conditions has been evaluated as described in this filing. The antenna(s) used for this transmitter must not transmit simultaneously with any other antenna or transmitter. The highest reported SAR value is 0.67 W/kg. |
EAS Grant - Application d03t9KVPrJ24ZPGLBwsQsA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Spheris Digital Ltd. Flat B, 18/F., Two Chinachem Plaza, 68 Connaught Road, Central Hong Kong, Hong Kong |
Date of Grant: 09/19/2016 Application Dated: 09/19/2016 |
| Attention: Herve Robin , Managing Director |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | YHO-PXT51516 |
| Name of Grantee: | Spheris Digital Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless Digital Display |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.0195 |
| Power listed is conducted. SAR compliance for portable use conditions has been evaluated as described in this filing. The antenna(s) used for this transmitter must not transmit simultaneously with any other antenna or transmitter. The highest reported SAR value is 0.67 W/kg. |
