Wireless Handwheel System - Access Point
Document preview loads when visible.
Document Details
| FCC ID | YJKHRA550FS |
|---|---|
| Document ID | 1515806 |
| Document Type | Test Setup Photos |
| Description | Test Photos |
| Document Title | Set-up - Rev1a |
| Applicant | DR. JOHANNES HEIDENHAIN GmbH |
| Equipment Class | Wireless Handwheel System - Access Point |
| Product Code | HRA550FS |
| Application ID | ZPdChLDvrCqy9OhmkbhmUQ== |
| Application Purpose | Original Equipment |
| Application Date | 2011-08-05 |
| Frequency Range | 2405-2480 MHz |
| FRN | 0019954288 |
| Test Firm | Istituto Italiano del Marchio di Qualita' S.p.A. |
| Certified By | Dr Walter Kranitzky Director |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | Yes |
| Submitted | 2011-08-03 |
| Available | 2011-08-05 |
| Created | 2011-04-27 |
| Modified | 2011-04-27 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 89295 |
| File SHA-256 | ba0fe67ce44e3a6d4906e4347eb18495bd2e9efac80d2ed1fbc0d6272b81c024 |
| PDF Metadata Author | gilberti |
| PDF Metadata Creator | PDFCreator Version 0.9.9 |
| PDF Metadata Producer | GPL Ghostscript 8.70 |
| FCC.gov Sources | FCC.gov 1515806 |
