GS780MIZ Bluetooth Smart Module Test Setup... - FCC ID YOPGS780MIZ
FCC ID YOPGS780MIZ
Test Photos
Bluetooth Smart Module
Document preview loads when visible.
Document Details
| FCC ID | YOPGS780MIZ |
|---|---|
| Document ID | 3191636 |
| Document Type | Test Setup Photos |
| Description | Test Photos |
| Document Title | APPENDIX A. TEST PHOTOS_FR640107 |
| Applicant | Gainspan Corporation |
| Equipment Class | Bluetooth Smart Module |
| Product Code | GS780MIZ |
| Application ID | 4gkMDJA82GvFbIYMvGD0Yw== |
| Application Purpose | Original Equipment |
| Application Date | 2016-11-10 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0020093258 |
| Test Firm | SPORTON International Inc. |
| Certified By | Leo Huang Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2016-11-09 |
| Available | 2016-11-10 |
| Created | 2016-08-03 |
| Modified | 2016-11-03 |
| Pages | 7 |
| File Type | Adobe Acrobat PDF |
| File Size | 408787 |
| File SHA-256 | 8dade02fcc38fce875c68ee587b20f5091c4836177ea19a4f177eacaaa1a3760 |
| PDF Metadata Author | WendyPan |
| PDF Metadata Producer | WendyPan Acrobat Distiller 15.0 (Windows) |
| FCC.gov Sources | FCC.gov 3191636 |
