ITALCOMXYN Mobile Phone Schematics - FCC ID YPVITALCOMXYN

FCC ID YPVITALCOMXYN

Schematics

Mobile Phone

by ITALCOM GROUP

Document preview loads when visible.

Document Details

FCC IDYPVITALCOMXYN
Document ID1520967
Document TypeSchematics
DescriptionSchematics
Document Titleb100
ApplicantITALCOM GROUP
Equipment ClassMobile Phone
Product CodeITALCOMXYN
Application ID5ELmXVI32SLbCm/YmZ2ocA==
Application PurposeOriginal Equipment
Application Date2011-08-11
Frequency Range1850.2-1909.8 MHz
FRN0020115382
Test FirmBay Area Compliance Laboratory Corp. (Shenzhen)
Certified ByJB LEE
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2011-08-11
Available2011-08-11
Created2011-08-02
Modified2011-08-09
Pages7
File TypeAdobe Acrobat PDF
File Size149429
File SHA-2562f9b867e8ffb6d4d0eb190e75f9f749ec9ed4ec013b5eb6bbfd839b55515e87d
PDF Metadata AuthorAdministrator
PDF Metadata CreatorPScript5.dll Version 5.2
PDF Metadata ProducerAcrobat Distiller 7.0 (Windows)
FCC.gov SourcesFCC.gov 1520967, FCC.gov 1520944
