LRS51010 Radar Level Sensor Label Diagram - FCC ID YQ7-LRS-510-10

FCC ID YQ7-LRS-510-10

Label

Radar Level Sensor

by Hans Turck GmbH & Co. KG

Document preview loads when visible.

Document Details

FCC IDYQ7-LRS-510-10
Document ID5254008
Document TypeID Label/Location Info
DescriptionLabel
Document Title100012722_FCC_ZUL.ai
ApplicantHans Turck GmbH & Co. KG
Equipment ClassRadar Level Sensor
Product CodeLRS51010
Application IDIL0BPLE/+dMVfhCjtejbhQ==
Application PurposeOriginal Equipment
Application Date2021-05-19
Frequency Range122000-123000 MHz
FRN0020167318
Test FirmCTC advanced GmbH
Certified ByMatthias Linde
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2021-05-19
Available2021-05-19
Created2021-04-15
Modified2021-04-15
Pages1
File TypeAdobe Acrobat PDF
File Size281569
File SHA-256daee34a3b030f92dbec802d93c49352bc1a75f78be780b8a210b881a0d4807ae
PDF Metadata Authornseelig
PDF Metadata ProducerMicrosoft: Print To PDF
FCC.gov SourcesFCC.gov 5254008
