FCC Part 15.247
TEST REPORT
For
ALATECH Technology Limited
39F., No. 758, Jungming S. RD. Taichung, Taiwan
FCC ID: YQOSC003
Product Type:
Report Type:
MAGNET -LESS CYCLING SPEED
/ CADENCE SENSOR
Original Report
Report Producer:
Report Number:
Kaylee Chiang
RXZ1806021-00A
Report Date:
2018-08-27
Reviewed By:
Jerry Chang
Bay Area Compliance Laboratories Corp.(Taiwan)
70, Lane 169, Sec. 2, Datong Road,
Xizhi Dist., New Taipei City 22183, Taiwan, R.O.C.
Tel: +886 (2) 2647 6898
Fax: +886 (2) 2647 6895
www.bacl.com.tw
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 1 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
Report No.: RXZ1806021-00A
REVISION HISTORY
Revision
No.
Report Number
Issue Date
Description
Author/
Revised by
1.0
RXZ1806021
RXZ1806021-00A
2018.08.27
Original Report
Kaylee
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 2 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
Report No.: RXZ1806021-00A
TABLE OF CONTENTS
GENERAL INFORMATION .............................................................................................................................. 5
1.1
PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ....................................................................... 5
1.2
OBJECTIVE ...................................................................................................................................................... 5
1.3
RELATED SUBMITTAL(S)/GRANT(S) ............................................................................................................... 5
1.4
TEST METHODOLOGY ..................................................................................................................................... 6
1.5
TEST FACILITY ............................................................................................................................................... 6
SYSTEM TEST CONFIGURATION ................................................................................................................. 7
2.1
DESCRIPTION OF TEST CONFIGURATION ......................................................................................................... 7
2.2
EQUIPMENT MODIFICATIONS .......................................................................................................................... 7
2.3
EUT EXERCISE SOFTWARE ............................................................................................................................. 7
2.4
SUPPORT EQUIPMENT LIST AND DETAILS ....................................................................................................... 7
2.5
EXTERNAL CABLE LIST AND DETAILS ............................................................................................................ 7
2.6
BLOCK DIAGRAM OF TEST SETUP ................................................................................................................... 8
2.7
DUTY CYCLE .................................................................................................................................................. 9
SUMMARY OF TEST RESULTS .................................................................................................................... 10
TEST EQUIPMENT LIST AND DETAILS .................................................................................................... 11
FCC §15.247(I), §1.1310, § 2.1091 - MAXIMUM PERMISSIBLE EXPOSURE (MPE) ............................. 12
5.1
APPLICABLE STANDARD ............................................................................................................................... 12
5.2
RF EXPOSURE EVALUATION RESULT ........................................................................................................... 12
FCC §15.203 – ANTENNA REQUIREMENTS ............................................................................................... 13
6.1
APPLICABLE STANDARD ............................................................................................................................... 13
6.2
ANTENNA LIST AND DETAILS ....................................................................................................................... 13
FCC §15.209, §15.205, §15.247(D) – SPURIOUS EMISSIONS...................................................................... 14
7.1
APPLICABLE STANDARD ............................................................................................................................... 14
7.2
MEASUREMENT UNCERTAINTY .................................................................................................................... 15
7.3
EUT SETUP................................................................................................................................................... 15
7.4
EMI TEST RECEIVER & SPECTRUM ANALYZER SETUP ................................................................................. 16
7.5
TEST PROCEDURE ......................................................................................................................................... 16
7.6
CORRECTED FACTOR & MARGIN CALCULATION .......................................................................................... 17
7.7
TEST RESULTS SUMMARY ............................................................................................................................ 17
7.8
TEST ENVIRONMENTAL CONDITIONS ............................................................................................................ 17
7.9
TEST RESULTS .............................................................................................................................................. 18
FCC §15.247(A)(2) – 6 DB EMISSION BANDWIDTH .................................................................................. 24
8.1
APPLICABLE STANDARD ............................................................................................................................... 24
8.2
TEST PROCEDURE ......................................................................................................................................... 24
8.3
TEST ENVIRONMENTAL CONDITIONS ............................................................................................................ 25
8.4
TEST RESULTS .............................................................................................................................................. 25
FCC §15.247(B)(3) – MAXIMUM OUTPUT POWER ................................................................................... 27
9.1
APPLICABLE STANDARD ............................................................................................................................... 27
9.2
TEST PROCEDURE ......................................................................................................................................... 27
9.3
TEST ENVIRONMENTAL CONDITIONS ............................................................................................................ 27
9.4
TEST RESULTS .............................................................................................................................................. 27
10
FCC §15.247(D) – 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE ........................................... 28
10.1
APPLICABLE STANDARD ............................................................................................................................... 28
10.2
TEST PROCEDURE ......................................................................................................................................... 28
10.3
TEST ENVIRONMENTAL CONDITIONS ............................................................................................................ 29
10.4
TEST RESULTS .............................................................................................................................................. 29
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 3 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
11
Report No.: RXZ1806021-00A
FCC §15.247(E) – POWER SPECTRAL DENSITY ....................................................................................... 31
11.1
APPLICABLE STANDARD ............................................................................................................................... 31
11.2
TEST PROCEDURE ......................................................................................................................................... 31
11.3
TEST ENVIRONMENTAL CONDITIONS ............................................................................................................ 32
11.4
TEST RESULTS .............................................................................................................................................. 32
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 4 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
1.1
Report No.: RXZ1806021-00A
General Information
Product Description for Equipment Under Test (EUT)
Applicant
ALATECH Technology Limited
39F., No.758,Jungming S. RD. Taichung, Taiwan
Manufacturer
ZHEJIANG ALA FITNESS TECHNOLOGY LTD.
NO.405 Tongxin Road, Tongxiang Economic Development Zhejiang
314500,China
Brand(Trade) Name
ALATECH
Product (Equipment)
MAGNET-LESS CYCLING SPEED / CADENCE SENSOR
Model Name
SC003
Frequency Range
2402-2480 MHz
Transmit Power
BLE Mode: -1.27 dBm
Modulation Technique
BLE Mode: GFSK
Transmit Data Rate
BLE Mode: 1 Mbps
Number of Channels
BLE Mode: 40 Channels
Antenna Specification
PCB Antenna/Gain: -1.32 dBi
Output
3Vdc from Battery
Received Date
June 20, 2018
Date of Test
July 02, 2018 ~ Aug 24, 2018
*All measurement and test data in this report was gathered from production sample serial number: 1806021
(Assigned by BACL, Taiwan)
1.2
Objective
This report is prepared on behalf of ALATECH Technology Limited in accordance with Part 2, Subpart J, Part 15,
Subparts A and C of the Federal Communication Commission’s rules.
The objective is to determine compliance with FCC Part 15.247 rules for Output Power, Antenna Requirements,
6 dB Bandwidth, Power Spectral Density, 100 kHz Bandwidth of Band Edges Measurement, Conducted and
Radiated Spurious Emissions.
1.3
Related Submittal(s)/Grant(s)
FCC Part 15.249 DXX submission with FCC ID: YQOSC003
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 5 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
1.4
Report No.: RXZ1806021-00A
Test Methodology
All measurements contained in this report were conducted with ANSI C63.10-2013, American National Standard
of Procedures for Compliance Testing of Unlicensed Wireless Devices
1.5
Test Facility
The Test site used by Bay Area Compliance Laboratories Corp. (Taiwan) to collect test data is located on
70, Lane 169, Sec. 2, Datong Road, Xizhi Dist., New Taipei City 22183, Taiwan, R.O.C.
68-3, Lane 169, Sec. 2, Datong Road, Xizhi Dist., New Taipei City 22183, Taiwan, R.O.C.
Bay Area Compliance Laboratories Corp. (Taiwan) Lab is accredited to ISO 17025 by Taiwan Accreditation
Foundation (TAF code: 3180) and the FCC designation No.TW3180 under the Mutual Recognition Agreement
(MRA) in FCC Test. The facility also complies with the radiated and AC line conducted test site criteria set forth
in ANSI C63.10.
The Federal Communications Commission has the reports on file and is listed under FCC Registration No.:
974454. The test site has been approved by the FCC for public use and is listed in the FCC Public Access Link
(PAL) database.
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 6 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
2.1
Report No.: RXZ1806021-00A
System Test Configuration
Description of Test Configuration
For BT BLE mode, there are totally 40 channels.
Channel
Frequency
(MHz)
Channel
Frequency
(MHz)
-20
2402
2404
2406
2408
-2440
21
--38
39
40
2442
--2476
2478
2480
For BLE Modes were tested with channel 1, 21 and 40
2.2
Equipment Modifications
No modification was made to the EUT
2.3
EUT Exercise Software
2.4
Support Equipment List and Details
No test software was used.
2.5
Description
Manufacturer
Model Number
FCC ID/DOC
S/N
N/A
N/A
N/A
N/A
N/A
External Cable List and Details
Cable Description
Length (m)
From
To
N/A
N/A
N/A
N/A
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 7 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
2.6
Report No.: RXZ1806021-00A
Block Diagram of Test Setup
See test photographs attached in setup photos for the actual connections between EUT and support equipment.
Radiation:
Below 1GHz:
Above 1GHz:
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 8 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
2.7
Report No.: RXZ1806021-00A
Duty Cycle
According to KDB 558074 D01 15.247 Meas Guidance v05 section 6.0:
All measurements are to be performed with the EUT transmitting at 100% duty cycle at its maximum power
control level; however, if 100% duty cycle cannot be achieved, measurements of duty cycle, x, and
maximumpower transmission duration, T, are required for each tested mode of operation.
Radio Mode
On Time
(ms)
Period
(ms)
Duty Cycle
(%)
Duty Cycle Correction Factor
(dB)
BLE
0.128
0.227
56
2.52
Note: Duty Cycle Correction Factor = 10*log(1/duty cycle)
RBW 3 MHz
*VBW 3 MHz
Ref
15 dBm
Offset
*Att
10 dB
SWT 500 µs
10.5 dB
10
1 PK * 0
CLRWR
Delta 2 [T1 ]
0.35 dB
227.564103 µs
Marker 1 [T1 ]
-2.31
136.217949
2Delta 1 [T1 ]
0.76
128.205128
dBm
µs
dB
µs
SGL
LVL
-10
-20
-30
-40
3DB
-50
-60
-70
-80
Center 2.402 GHz
Date: 2.JUL.2018
50 µs/
16:15:07
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 9 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
Report No.: RXZ1806021-00A
Summary of Test Results
FCC Rules
Description of Test
Result
§15.247(i), §1.1310, §2.1091
Maximum Permissible Exposure (MPE)
Compliance
§15.203
Antenna Requirement
Compliance
§15.207(a)
AC Line Conducted Emissions
Not applicable
§15.205, §15.209, §15.247(d)
Spurious Emissions
Compliance
§15.247(a)(2)
6 dB Emission Bandwidth
Compliance
§15.247(b)(3)
Maximum Peak Output Power
Compliance
§15.247(d)
100 kHz Bandwidth of Frequency Band Edge
Compliance
§15.247(e)
Power Spectral Density
Compliance
Not applicable: Device only supports battery.
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 10 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
Report No.: RXZ1806021-00A
Test Equipment List and Details
Description
Manufacturer
Bilog Antenna
with 6 dB
Attenuator
Horn Antenna
Horn Antenna
Preamplifier
SUNOL
SCIENCES &
MINI-CIRCUITS
EMCO
ETS-Lindgren
Sonoma
EM Electronics
Corp.
EM Electronics
Corporatino
Preamplifier
Model
Serial Number
Calibration
Date
Calibration
Due Date
Radiated Room (966-A)
JB6/UNAT-6+
A050115/15542
_01
2017/12/20
2018/12/19
3115
3116
310N
9311-4158
62638
130602
2018/04/20
2017/09/13
2018/07/04
2019/04/19
2018/09/12
2019/07/03
EM01G18G
060657
2017/12/14
2018/12/13
EM18G40G
060656
2018/01/15
2019/01/14
Microware
Preamplifier
EMI Test
Receiver
Spectrum
Analyzer
Rohde & Schwarz
ESR7
101419
2017/11/06
2018/11/05
Rohde & Schwarz
FSV40
101203
2018/02/12
2019/02/13
Microflex Cable
UTIFLEX
2017/10/31
2018/10/30
Microflex Cable
UTIFLEX
2017/11/10
2018/11/09
Microflex Cable
ROSNOL
2018/03/05
2019/03/04
Microflex Cable
ROSNOL
2018/01/17
2019/01/16
Turn Table
Antenna Tower
Controller
Software
NSA
VSWR
Champro
Champro
Champro
Farad
BACL
BACL
N.C.R
N.C.R
N.C.R
N.C.R
2018/07/09
2018/07/16
N.C.R
N.C.R
N.C.R
N.C.R
2019/07/08
2019/07/15
Spectrum
Analyzer
Cable
Attenuator
Power Sensor
UFB311A-Q-1440220490-006
300300
UFA210A-1-3149MFR64639
300300
226389-001
K1K50-UP0264160309-1
K1K50-450CM
K1K50-UP0264160309-2
K1K50-80CM
TT-2000
060772-T
AM-BS-4500-B
060772-A
EM1000
60772
EZ_EMC
BACL-03A1
966-A
N/A
966-A
N/A
Conducted Room
Rohde & Schwarz
FSU26
200268
2018/05/04
2019/05/03
WOKEN
MINI-CIRCUITS
KEYSIGHT
SFL402
BW-S10W5+
U2021XA
S02-160323-07
N/A
MY54080018
2018/02/12
2018/03/08
2018/03/07
2019/02/11
2019/03/07
2019/03/06
*Statement of Traceability: BACL Corp. attests that all of the calibrations on the equipment items listed above were
traceable to the SI System of Units via the R.O.C. Center for Measurement Standards of the Electronics Testing Center,
Taiwan (ETC) or to another internationally recognized National Metrology Institute (NMI), and were compliant with
the current Taiwan Accreditation Foundation (TAF) requirements
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 11 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
5.1
Report No.: RXZ1806021-00A
FCC §15.247(i), §1.1310, § 2.1091 - Maximum Permissible Exposure (MPE)
Applicable Standard
According to subpart 15.247(i)and subpart §1.1310, systems operating under the provisions of this section shall
be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of
the Commission’s guidelines.
Limits for Maximum Permissible Exposure (MPE) (§1.1310, §2.1091)
(B) Limits for General Population/Uncontrolled Exposure
Frequency Range
(MHz)
Electric Field
Strength (V/m)
Magnetic Field
Strength (A/m)
Power Density
(mW/cm2)
Averaging Time
(minutes)
0.3–1.34
614
1.63
*(100)
30
1.34–30
824/f
2.19/f
*(180/f²)
30
30–300
27.5
0.073
0.2
30
300–1500
f/1500
30
1500–100,000
1.0
30
f = frequency in MHz; * = Plane-wave equivalent power density;
According to §1.1310 and §2.1091 RF exposure is calculated.
Calculated Formulary:
Predication of MPE limit at a given distance
S = PG/4πR² = power density (in appropriate units, e.g. mW/cm2);
P = power input to the antenna (in appropriate units, e.g., mW);
G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor,
is normally numeric gain;
R = distance to the center of radiation of the antenna (appropriate units, e.g., cm);
5.2
RF Exposure Evaluation Result
MPE evaluation:
Mode
BLE
Frequency
Range
(MHz)
2402
Antenna Gain
Target Power
(dBi)
(numeric)
(dBm)
(mW)
-1.32
0.74
-1
0.79
Evaluation
Distance
(cm)
20
Power Density
(mW/cm2)
MPE Limit
(mW/cm2)
0.0001
Result: MPE evaluation meet 20 cm the requirement of standard.
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 12 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
6.1
Report No.: RXZ1806021-00A
FCC §15.203 – Antenna Requirements
Applicable Standard
According to § 15.203,
An intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible
party shall be used with the device. The use of a permanently attached antenna or of an antenna that uses a unique
coupling to the intentional radiator shall be considered sufficient to comply with the provisions of this section.
The manufacturer may design the unit so that a broken antenna can be replaced by the user, but the user of a
standard antenna jack or electrical connector is prohibited.
And according to FCC 47 CFR section 15.247 (b), if the transmitting antennas of directional gain greater than
6dBi are used, the power shall be reduced by the amount in dB that the directional gain of the antenna exceed 6
dBi.
6.2
Antenna List and Details
Manufacturer
Type
Antenna Gain
Result
Alatech Technology
Limited
PCB Antenna
-1.32 dBi
Compliance
The EUT has an internal antenna arrangement, which was permanently attached, fulfill the requirement of this
section.
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 13 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
7.1
Report No.: RXZ1806021-00A
FCC §15.209, §15.205, §15.247(d) – Spurious Emissions
Applicable Standard
As per FCC §15.35(d): Unless otherwise specified, on any frequency or frequencies above 1000 MHz, the
radiated emission limits are based on the use of measurement instrumentation employing an average detector
function. Unless otherwise specified, measurements above 1000 MHz shall be performed using a minimum
resolution bandwidth of 1 MHz.
As Per FCC §15.205(a) except as show in paragraph (d) of this section, only spurious emissions are permitted in
any of the frequency bands listed below:
MHz
MHz
0.090 – 0.110
0.495 – 0.505
2.1735 – 2.1905
4.125 – 4.128
4.17725 – 4.17775
4.20725 – 4.20775
6.215 – 6.218
6.26775 – 6.26825
6.31175 – 6.31225
8.291 – 8.294
8.362 – 8.366
8.37625 – 8.38675
8.41425 – 8.41475
12.29 – 12.293
12.51975 – 12.52025
12.57675 – 12.57725
13.36 – 13.41
16.42 – 16.423
16.69475 – 16.69525
25.5 – 25.67
37.5 – 38.25
73 – 74.6
74.8 – 75.2
108 – 121.94
123 – 138
149.9 – 150.05
156.52475 – 156.52525
156.7 – 156.9
162.0125 –167.17
167.72 – 173.2
240 – 285
322 – 335.4
399.9 – 410
608 – 614
MHz
GHz
960 – 1240
1300 – 1427
1435 – 1626.5
1645.5 – 1646.5
1660 – 1710
1718.8 – 1722.2
2200 – 2300
2310 – 2390
2483.5 – 2500
2690 – 2900
3260 – 3267
3.332 – 3.339
3 3458 – 3 358
3.600 – 4.400
4. 5 – 5. 15
5. 35 – 5. 46
7.25 – 7.75
8.025 – 8.5
9.0 – 9.2
9.3 – 9.5
10.6 – 12.7
13.25 – 13.4
14.47 – 14.5
15.35 – 16.2
17.7 – 21.4
22.01 – 23.12
23.6 – 24.0
31.2 – 31.8
36.43 – 36.5
Above 38.6
As per FCC §15.209(a): Except as provided elsewhere in this Subpart, the emissions from an intentional radiator
shall not exceed the field strength levels specified in the following table:
Frequency
(MHz)
Field Strength
(micro volts/meter)
Measurement Distance
(meters)
0.009 - 0.490
2400/F(kHz)
300
0.490 - 1.705
24000/F(kHz)
30
1.705 - 30.0
30
30
30 - 88
100**
88 - 216
150**
216 - 960
200**
Above 960
500
** Except as provided in paragraph (g), fundamental emissions from intentional radiators operating under this
Section shall not be located in the frequency bands 54-72 MHz, 76-88 MHz, 174-216 MHz or 470-806 MHz.
However, operation within these frequency bands is permitted under other sections of this Part, e.g., Sections
15.231 and 15.241.
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 14 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
Report No.: RXZ1806021-00A
As per FCC §15.247 (d) In any 100 kHz bandwidth outside the frequency band in which the spread spectrum or
digitally modulated intentional radiator is operating, the radio frequency power that is produced by the intentional
radiator shall be at least 20 dB below that in the 100 kHz bandwidth within the band that contains the highest level
of the desired power, based on either an RF conducted or a radiated measurement, provided the transmitter
demonstrates compliance with the peak conducted power limits. If the transmitter complies with the conducted
power limits based on the use of RMS averaging over a time interval, as permitted under paragraph (b)(3) of this
section, the attenuation required under this paragraph shall be 30 dB instead of 20 dB. Attenuation below the
general limits specified in §15.209(a) is not required. In addition, radiated emissions which fall in the restricted
bands, as defined in §15.205(a), must also comply with the radiated emission limits specified in §15.209(a) (see
§15.205(c).
7.2
Measurement Uncertainty
All measurements involve certain levels of uncertainties, especially in field of EMC. The factors contributing to
uncertainties are spectrum analyzer, cable loss, antenna factor calibration, antenna directivity, antenna factor
variation with height, antenna phase center variation, antenna factor frequency interpolation, measurement
distance variation, site imperfections, mismatch (average), and system repeatability.
Based on CISPR 16-4-2:2011, the expended combined standard uncertainty of radiation emissions at Bay Area
Compliance Laboratories Corp. (Taiwan) is shown in below table. And the uncertainty will not be taken into
consideration for the test data recorded in the report.
7.3
Frequency
Measurement uncertainty
30 MHz~200 MHz
3.76 dB (k=2, 95% level of confidence)
200 MHz~1 GHz
4.12 dB (k=2, 95% level of confidence)
1 GHz~6 GHz
4.84 dB (k=2, 95% level of confidence)
6 GHz~18 GHz
5.16 dB (k=2, 95% level of confidence)
18 GHz~26 GHz
4.84 dB (k=2, 95% level of confidence)
26 GHz~40 GHz
4.30 dB (k=2, 95% level of confidence)
EUT Setup
Blow 1 GHz:
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 15 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
Report No.: RXZ1806021-00A
Above 1 GHz:
Radiated emission tests were performed in the 3 meters chamber test site, using the setup accordance with the
ANSI C63.10-2013. The specification used was the FCC Part 15.209 and FCC 15.247 Limits.
7.4
EMI Test Receiver & Spectrum Analyzer Setup
The system was investigated from 30 MHz to 26.5 GHz. During the radiated emission test, the EMI test receiver
was set with the following configurations measurement method 6.3 in ANSI C63.10.
7.5
Frequency Range
RBW
VBW
Detector
30-1000 MHz
120 kHz
QP
Above 1 GHz
1 MHz
1 MHz
1 MHz
3 MHz
3 MHz
1/T
PK
RMS
PK
Duty cycle
>98%
<98%
Measurement
method
QP
PK
Ave
Ave
Test Procedure
Maximizing procedure was performed on the highest emissions to ensure that the EUT complied with all
installation combinations.
All data was recorded in the Quasi-peak detector mode from 30 MHz to 1 GHz and PK and average detector
modes for frequencies above 1 GHz.
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 16 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
7.6
Report No.: RXZ1806021-00A
Corrected Factor & Margin Calculation
The Correct Factor is calculated by adding the Antenna Factor and Cable Loss, and subtracting the Amplifier Gain
from the Meter Reading. The basic equation is as follows:
Correct Factor = Antenna Factor + Cable Loss - Amplifier Gain
The “Margin” column of the following data tables indicates the degree of compliance with the applicable limit.
For example, a margin of -7 dB means the emission is 7 dB below the limit. The equation for margin calculation
is as follows:
Margin = Result –Limit
7.7
Test Results Summary
According to the data in the following table, the EUT complied with the FCC §15.209 Limit. Refer to CISPR164-2:2011 and CISPR 16-4-1:2009, the measured level complies with the limit if
Lm + U(Lm) ≤ Llim + Ucispr
In BACL, U(Lm) is less than Ucispr, if Lm is less than Llim, it implies that the EUT complies with the limit.
7.8
Test Environmental Conditions
Temperature:
Relative Humidity:
ATM Pressure:
25.2° C
58 %
1010 hPa
The Radiation Spurious Emissions testing was performed by Tom Hsu on 2018-08-23 ~ 2018-08-24.
The Conducted Spurious Emissions testing was performed by Tom Hsu on 2018-08-23.
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 17 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
7.9
Report No.: RXZ1806021-00A
Test Results
Test Mode: Transmitting
BLE Mode
Horizontal (worst case is BLE mode low channel)
30MHz-1GHz:
1GHz-18GHz:
18GHz-26.5GHz:
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 18 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
Report No.: RXZ1806021-00A
Vertical (worst case is BLE mode low channel)
30MHz-1GHz:
1GHz-18GHz:
18GHz-26.5GHz:
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 19 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
Report No.: RXZ1806021-00A
Below 1GHz
Horizontal
Frequency
(MHz)
30.0000
47.4600
166.7700
460.6800
631.4000
863.2300
Reading
(dBμV)
Correct
Factor(dB/m)
Result
(dBμV/m)
Limit
(dBμV/m)
Margin
(dB)
Height
(cm)
Degree
(°)
Remark
358
77
281
254
QP
QP
QP
QP
QP
QP
Reading
(dBμV)
Correct
Factor(dB/m)
Result
(dBμV/m)
Limit
(dBμV/m)
Margin
(dB)
Height
(cm)
Degree
(°)
Remark
40.62
46.06
34.69
30.71
31.47
30.60
-3.02
-14.82
-10.96
-5.90
-4.06
-0.80
37.60
31.24
23.73
24.81
27.41
29.80
40.00
40.00
43.50
46.00
46.00
46.00
-2.40
-8.76
-19.77
-21.19
-18.59
-16.20
100
100
100
100
100
100
Vertical
Frequency
(MHz)
30.0000
42.28
-3.02
39.26
40.00
48.8200
52.92
-15.40
37.52
40.00
101.7800
52.51
-13.30
39.21
43.50
166.7700
47.26
-10.96
36.30
43.50
497.5400
30.54
-5.41
25.13
46.00
802.1200
31.28
-1.45
29.83
46.00
Result = Reading + Correct Factor
Margin = Result – Limit
Correct Factor = Antenna Factor + Cable Loss – Amplifier Gain
Spurious emissions more than 20 dB below the limit were not reported.
-0.74
-2.48
-4.29
-7.20
-20.87
-16.17
100
100
100
100
100
100
301
360
309
330
333
326
QP
QP
QP
QP
QP
QP
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 20 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
Report No.: RXZ1806021-00A
Above 1GHz
Horizontal
Frequency
(MHz)
Reading
(dBμV)
Correct
Factor(dB/m)
2390.000
2390.000
2402.000
2402.000
4804.000
4804.000
63.44
52.53
91.86
91.20
58.89
52.24
-4.81
-4.81
-4.79
-4.79
1.16
1.16
2442.000
2442.000
4884.000
4884.000
90.72
90.20
56.64
50.61
-4.68
-4.68
1.43
1.43
2480.000
2480.000
2483.500
2483.500
4960.000
4960.000
9920.000
9920.000
89.81
89.73
64.48
51.56
54.80
45.59
41.44
32.44
-4.58
-4.58
-4.57
-4.57
1.69
1.69
12.41
12.41
Frequency
(MHz)
Reading
(dBμV)
Correct
Factor(dB/m)
2390.000
2390.000
2402.000
2402.000
4804.000
4804.000
64.19
52.26
87.11
86.34
50.94
43.83
-4.81
-4.81
-4.79
-4.79
1.16
1.16
2442.000
2442.000
4884.000
4884.000
86.66
86.02
51.92
44.87
-4.68
-4.68
1.43
1.43
Result
(dBμV/m)
Limit
(dBμV/m)
Margin
(dB)
Height
(cm)
Degree
(°)
Remark
-15.37
-6.28
N/A
N/A
-13.95
-0.60
100
100
123
123
120
120
76
76
103
103
130
130
peak
AVG
peak
AVG
peak
AVG
N/A
N/A
-15.93
-1.96
135
135
123
123
96
96
337
337
peak
AVG
peak
AVG
N/A
N/A
-14.09
-7.01
-17.51
-6.72
-20.15
-9.15
271
271
100
100
100
100
100
100
106
106
283
283
293
293
131
131
peak
AVG
peak
AVG
peak
AVG
peak
AVG
Margin
(dB)
Height
(cm)
Degree
(°)
Remark
-14.62
-6.55
N/A
N/A
-21.90
-9.01
100
100
154
154
100
100
98
98
127
127
250
250
peak
AVG
peak
AVG
peak
AVG
N/A
N/A
-20.65
-7.70
100
100
100
100
120
120
191
191
peak
AVG
peak
AVG
2480.000
87.53
-4.58
N/A
2480.000
86.90
-4.58
N/A
2483.500
64.30
-4.57
-14.27
2483.500
51.52
-4.57
-7.05
4960.000
49.80
1.69
-22.51
4960.000
43.52
1.69
-8.79
Result = Reading + Correct Factor
Margin = Result – Limit
Correct Factor = Antenna Factor + Cable Loss – Amplifier Gain
Spurious emissions more than 20 dB below the limit were not reported.
124
124
100
100
100
100
122
122
138
138
196
196
peak
AVG
peak
AVG
peak
AVG
Low channel
58.63
74.00
47.72
54.00
87.07
N/A
86.41
N/A
60.05
74.00
53.40
54.00
Middle channel
86.04
N/A
85.52
N/A
58.07
74.00
52.04
54.00
High channel
85.23
N/A
85.15
N/A
59.91
74.00
46.99
54.00
56.49
74.00
47.28
54.00
53.85
74.00
44.85
54.00
Vertical
Result
(dBμV/m)
Limit
(dBμV/m)
Low channel
59.38
74.00
47.45
54.00
82.32
N/A
81.55
N/A
52.10
74.00
44.99
54.00
Middle channel
81.98
N/A
81.34
N/A
53.35
74.00
46.30
54.00
High channel
82.95
N/A
82.32
N/A
59.73
74.00
46.95
54.00
51.49
74.00
45.21
54.00
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 21 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
Report No.: RXZ1806021-00A
Conducted Spurious Emissions:
Channel
Frequency
(MHz)
Delta Peak to
Band Emission
(dBc)
Limit
(dBc)
RESULT
Low
Mid
High
2402
2442
2480
39.63
40.31
40.93
≥ 20
≥ 20
≥ 20
PASS
PASS
PASS
Low Channel
*RBW 100 kHz
*VBW 300 kHz
Ref
10 dBm
10 Offset
1 PK
MAXH
*Att
30 dB
SWT 2.7 s
Delta 1 [T1 ]
-39.63 dB
24.052067308 GHz
Marker 1 [T1 ]
-3.95 dBm
2.405512821 GHz
10.5 dB
-10
LVL
-20
D1 -23.95 dBm
-30
-40
3DB
-50
-60
-70
-80
-90
Start 30 MHz
Date: 23.AUG.2018
2.647 GHz/
Stop 26.5 GHz
14:13:40
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 22 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
Report No.: RXZ1806021-00A
Middle Channel
*RBW 100 kHz
*VBW 300 kHz
Ref
10 dBm
10 Offset
1 PK
MAXH
*Att
30 dB
SWT 2.7 s
Delta 1 [T1 ]
-40.31 dB
22.694631410 GHz
Marker 1 [T1 ]
-4.51 dBm
2.405512821 GHz
10.5 dB
-10
LVL
-20
D1 -24.51 dBm
-30
-40
3DB
-50
-60
-70
-80
-90
Start 30 MHz
Date: 23.AUG.2018
2.647 GHz/
Stop 26.5 GHz
14:17:52
High Channel
*RBW 100 kHz
*VBW 300 kHz
Ref
10 dBm
10 Offset
1 PK
MAXH
*Att
30 dB
SWT 2.7 s
Delta 1 [T1 ]
-40.93 dB
24.009647436 GHz
Marker 1 [T1 ]
-3.85 dBm
2.447932692 GHz
10.5 dB
-10
LVL
-20
D1 -23.85 dBm
-30
-40
3DB
-50
-60
-70
-80
-90
Start 30 MHz
Date: 23.AUG.2018
2.647 GHz/
Stop 26.5 GHz
14:21:26
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 23 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
8.1
Report No.: RXZ1806021-00A
FCC §15.247(a)(2) – 6 dB Emission Bandwidth
Applicable Standard
According to FCC §15.247(a) (2).
Systems using digital modulation techniques may operate in the 902–928 MHz, 2400–2483.5 MHz, and 5725–
5850 MHz bands. The minimum 6 dB bandwidth shall be at least 500 kHz.
8.2
Test Procedure
The steps for the first option are as follows:
a) Set RBW = 100 kHz.
b) Set the VBW ≥ [3 × RBW].
c) Detector = peak.
d) Trace mode = max hold.
e) Sweep = auto couple.
f) Allow the trace to stabilize.
g) Measure the maximum width of the emission that is constrained by the frequencies associated with the two
outermost amplitude points (upper and lower frequencies) that are attenuated by 6 dB relative to the maximum
level measured in the fundamental emission.
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 24 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
8.3
Report No.: RXZ1806021-00A
Test Environmental Conditions
Temperature:
26° C
Relative Humidity:
58 %
1010 hPa
ATM Pressure:
The testing was performed by Tom Hsu on 2018-08-23.
8.4
Test Results
Channel
Frequency
(MHz)
6 dB OBW
(kHz)
Limit
(kHz)
Result
Low
2402
596
> 500
Compliance
Middle
2442
653
> 500
Compliance
High
2480
629
> 500
Compliance
Please refer to the following plots
Low Channel
*RBW 100 kHz
*VBW 300 kHz
Ref
10 dBm
10 Offset
*Att
30 dB
1 PK
MAXH
SWT 2.5 ms
10.5 dB
D1 -7.66 dBm
-10
Delta 1 [T1 ]
0.37 dB
596.153846127 kHz
Marker 1 [T1 ]
-8.01
2.401644231
Marker 2 [T1 ]
-1.66
2.401975962
dBm
GHz
dBm
GHz
LVL
-20
-30
-40
3DB
-50
-60
-70
-80
-90
Center 2.402 GHz
Date: 23.AUG.2018
300 kHz/
Span 3 MHz
14:11:47
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 25 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
Report No.: RXZ1806021-00A
Middle Channel
*RBW 100 kHz
*VBW 300 kHz
Ref
10 dBm
10 Offset
*Att
30 dB
10.5 dB
1 PK
MAXH
SWT 2.5 ms
D1 -8.02 dBm
-10
Delta 1 [T1 ]
0.11 dB
653.846153816 kHz
Marker 1 [T1 ]
-8.39
2.441653846
Marker 2 [T1 ]
-2.02
2.441980769
dBm
GHz
dBm
GHz
LVL
-20
-30
-40
3DB
-50
-60
-70
-80
-90
Center 2.442 GHz
Date: 23.AUG.2018
300 kHz/
Span 3 MHz
14:17:07
High Channel
*RBW 100 kHz
*VBW 300 kHz
Ref
10 dBm
10 Offset
*Att
30 dB
10.5 dB
1 PK
MAXH
SWT 2.5 ms
-10
D1 -8.38 dBm
Delta 1 [T1 ]
-0.51 dB
629.807692279 kHz
Marker 1 [T1 ]
-8.03
2.479668269
Marker 2 [T1 ]
-2.38
2.479990385
dBm
GHz
dBm
GHz
LVL
-20
-30
-40
3DB
-50
-60
-70
-80
-90
Center 2.48 GHz
Date: 23.AUG.2018
300 kHz/
Span 3 MHz
14:20:22
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 26 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
Report No.: RXZ1806021-00A
FCC §15.247(b)(3) – Maximum Output Power
9.1
Applicable Standard
According to FCC §15.247(b) (3).
Systems using digital modulation in the 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz bands: 1 Watt.
As an alternative to a peak power measurement, compliance with the one Watt limit can be based on a
measurement of the maximum conducted output power. Maximum Conducted Output Power is defined as the
total transmit power delivered to all antennas and antenna elements averaged across all symbols in the signaling
alphabet when the transmitter is operating at its maximum power control level. Power must be summed across
all antennas and antenna elements. The average must not include any time intervals during which the transmitter
is off or is transmitting at a reduced power level. If multiple modes of operation are possible (e.g., alternative
modulation methods), the maximum conducted output power is the highest total transmit power occurring in any
mode.
9.2
Test Procedure
1. Place the EUT on a bench and set it in transmitting mode.
2. Remove the antenna from the EUT and then connect a low loss RF cable from the antenna port to measuring
equipment.
9.3
Test Environmental Conditions
Temperature:
26° C
Relative Humidity:
58 %
ATM Pressure:
1010 hPa
The testing was performed by Tom Hsu on 2018-08-23.
9.4
Test Results
Channel
Frequency
(MHz)
Low
Middle
High
2402
2442
2480
Maximum peak
Conducted Output Power
(dBm)
BLE Mode
-1.27
-1.61
-1.98
Limit
(W)
(W)
0.0007
0.0007
0.0006
Result
PASS
PASS
PASS
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 27 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
Report No.: RXZ1806021-00A
10 FCC §15.247(d) – 100 kHz Bandwidth of Frequency Band Edge
10.1 Applicable Standard
According to FCC §15.247(d).
In any 100 kHz bandwidth outside the frequency band in which the spread spectrum or digitally modulated
intentional radiator is operating, the radio frequency power that is produced by the intentional radiator shall be at
least 20 dB below that in the 100 kHz bandwidth within the band that contains the highest level of the desired
power, based on either an RF conducted or a radiated measurement, provided the transmitter demonstrates
compliance with the peak conducted power limits. If the transmitter complies with the conducted power limits
based on the use of RMS averaging over a time interval, as permitted under paragraph (b)(3) of this section, the
attenuation required under this paragraph shall be 30 dB instead of 20 dB. Attenuation below the general limits
specified in §15.209(a) is not required. In addition, radiated emissions which fall in the restricted bands, as
defined in §15.205(a), must also comply with the radiated emission limits specified in §15.209(a) (see
§15.205(c)).
10.2 Test Procedure
1. Check the calibration of the measuring instrument using either an internal calibrator or a known signal from
an external generator.
2. Position the EUT without connection to measurement instrument. Turn on the EUT and connect its antenna
terminal to measurement instrument via a low loss cable. Then set it to any one measured frequency within its
operating range, and make sure the instrument is operated in its linear range.
3. Set RBW to 100 kHz and VBW of spectrum analyzer to 300 kHz with a convenient frequency span including
100 kHz bandwidth from band edge.
4. Measure the highest amplitude appearing on spectral display and set it as a reference level. Plot the graph
with marking the highest point and edge frequency.
5. Repeat above procedures until all measured frequencies were complete.
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 28 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
Report No.: RXZ1806021-00A
10.3 Test Environmental Conditions
Temperature:
26° C
Relative Humidity:
58 %
ATM Pressure:
1010 hPa
The testing was performed by Tom Hsu on 2018-08-23.
10.4 Test Results
Channel
Frequency
(MHz)
Delta Peak to
Band Emission
(dBc)
Limit
(dBc)
RESULT
Low
High
2402
2480
37.84
45.00
≥ 20
≥ 20
PASS
PASS
Please refer to the following plots
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 29 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
Report No.: RXZ1806021-00A
Band Edge, Left Side
*RBW 100 kHz
Delta 2 [T1 ]
-37.84 dB
-2.067307692 MHz
*VBW 300 kHz
Ref
10 dBm
10 Offset
*Att
30 dB
SWT 5 ms
10.5 dB
1 PK
MAXH
Marker 1 [T1 ]
-1.69 dBm
2.401987179 GHz
-10
LVL
-20
-30
-40
3DB
-50
-60
-70
-80
F1
-90
Center 2.4 GHz
Date: 23.AUG.2018
1 MHz/
Span 10 MHz
14:13:22
Band Edge, Right Side
*RBW 100 kHz
*VBW 300 kHz
Ref
10 dBm
10 Offset
1 PK
MAXH
*Att
30 dB
SWT 5 ms
Delta 2 [T1 ]
-45.00 dB
3.573717949 MHz
Marker 1 [T1 ]
-2.38 dBm
2.479990385 GHz
10.5 dB
-10
LVL
-20
-30
-40
3DB
-50
-60
-70
-80
F1
-90
Center 2.4835 GHz
Date: 23.AUG.2018
1 MHz/
Span 10 MHz
14:21:08
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 30 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
Report No.: RXZ1806021-00A
11 FCC §15.247(e) – Power Spectral Density
11.1 Applicable Standard
According to FCC §15.247(e).
For digitally modulated systems, the power spectral density conducted from the intentional radiator to the
antenna shall not be greater than 8 dBm in any 3 kHz band during any time interval of continuous transmission.
This power spectral density shall be determined in accordance with the provisions of paragraph (b) of this
section. The same method of determining the conducted output power shall be used to determine the power
spectral density.
11.2 Test Procedure
According to ANSI C63.10-2013
a) Set analyzer center frequency to DTS channel center frequency.
b) Set the span to 1.5 times the DTS bandwidth.
c) Set the RBW to 3 kHz ≤ RBW ≤ 100 kHz.
d) Set the VBW ≥ [3 × RBW].
e) Detector = peak.
f) Sweep time = auto couple.
g) Trace mode = max hold.
h) Allow trace to fully stabilize.
i) Use the peak marker function to determine the maximum amplitude level within the RBW.
j) If measured value exceeds requirement, then reduce RBW (but no less than 3 kHz) and repeat
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 31 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
Report No.: RXZ1806021-00A
11.3 Test Environmental Conditions
Temperature:
26° C
Relative Humidity:
58 %
1010 hPa
ATM Pressure:
The testing was performed by Tom Hsu on 2018-08-23.
11.4 Test Results
Channel
Frequency
(MHz)
Power Spectral Density
(dBm/3 kHz)
Limit
(dBm/3 kHz)
Result
Low
2402
-14.38
Compliance
Middle
2442
-13.67
Compliance
High
2480
-14.07
Compliance
Please refer to the following plots
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 32 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
Report No.: RXZ1806021-00A
Low Channel
*RBW 3 kHz
*VBW 10 kHz
Ref
10 dBm
10 Offset
*Att
30 dB
SWT 100 ms
Marker 1 [T1 ]
-14.38 dBm
2.401972772 GHz
10.5 dB
1 PK
MAXH
-10
LVL
-20
-30
-40
3DB
-50
-60
-70
-80
-90
Center 2.402 GHz
Date: 23.AUG.2018
89.42307692 kHz/
Span 894.2307692 kHz
14:11:57
Middle Channel
*RBW 3 kHz
*VBW 10 kHz
Ref
10 dBm
10 Offset
*Att
30 dB
SWT 110 ms
Marker 1 [T1 ]
-13.67 dBm
2.441966993 GHz
10.5 dB
1 PK
MAXH
-10
LVL
-20
-30
-40
3DB
-50
-60
-70
-80
-90
Center 2.442 GHz
Date: 23.AUG.2018
98.07692307 kHz/
Span 980.7692307 kHz
14:17:17
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 33 of 34
Bay Area Compliance Laboratories Corp. (Taiwan)
Report No.: RXZ1806021-00A
High Channel
*RBW 3 kHz
*VBW 10 kHz
Ref
10 dBm
10 Offset
*Att
30 dB
SWT 105 ms
Marker 1 [T1 ]
-14.07 dBm
2.479969721 GHz
10.5 dB
1 PK
MAXH
-10
LVL
-20
-30
-40
3DB
-50
-60
-70
-80
-90
Center 2.48 GHz
Date: 23.AUG.2018
94.47115384 kHz/
Span 944.7115384 kHz
14:20:32
----- END OF REPORT -----
Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in
part without prior written consent from Bay Area Compliance Laboratories Corp. (Taiwan)
Page 34 of 34
Download: SC003 MAGNET-LESS CYCLING SPEED/CADENCE SENSOR Test Report  ALATECH Technology Limited
Mirror Download [FCC.gov]SC003 MAGNET-LESS CYCLING SPEED/CADENCE SENSOR Test Report  ALATECH Technology Limited
Document ID3986690
Application IDefHK6NwHPu+p1pV4veK9YQ==
Document DescriptionTest Report
Short Term ConfidentialNo
Permanent ConfidentialNo
SupercedeNo
Document TypeTest Report
Display FormatAdobe Acrobat PDF - pdf
Filesize52.21kB (652655 bits)
Date Submitted2018-08-31 00:00:00
Date Available2018-08-31 00:00:00
Creation Date2018-08-31 17:36:03
Producing SoftwareAdobe PDF Library 11.0
Document Lastmod2018-08-31 11:38:03
Document TitleTest Report
Document CreatorAcrobat PDFMaker 11 Word 版
Document Author: Simon Ma

Source Exif Data [exif.tools]:
File Type                       : PDF
File Type Extension             : pdf
MIME Type                       : application/pdf
PDF Version                     : 1.6
Linearized                      : No
Author                          : Simon Ma
Comments                        :
Company                         : Microsoft
Create Date                     : 2018:08:31 17:36:03+08:00
Modify Date                     : 2018:08:31 11:38:03-07:00
Source Modified                 : D:20180831093552
Subject                         :
Tagged PDF                      : Yes
XMP Toolkit                     : Adobe XMP Core 5.2-c001 63.139439, 2010/09/27-13:37:26
Metadata Date                   : 2018:08:31 11:38:03-07:00
Creator Tool                    : Acrobat PDFMaker 11 Word 版
Document ID                     : uuid:14a4773a-24b1-41c9-981d-c175785fffcb
Instance ID                     : uuid:df8c440c-eed3-435e-ac25-d6f10d8f0874
Format                          : application/pdf
Title                           :
Description                     :
Creator                         : Simon Ma
Producer                        : Adobe PDF Library 11.0
Keywords                        :
Page Layout                     : OneColumn
Page Count                      : 34
