BT1 Hearing Aid with BLE Teardown Internal Photos - FCC ID YU2-BT1

FCC ID YU2-BT1

int photos

Hearing Aid with BLE

by audifon GmbH & Co KG

Document preview loads when visible.

Document Details

FCC IDYU2-BT1
Document ID4494211
Document TypeInternal Photos
Descriptionint photos
Document TitleVorlage Formblatt
Applicantaudifon GmbH & Co KG
Equipment ClassHearing Aid with BLE
Product CodeBT1
Application IDOO8igk1XVjt7+ete3XomIw==
Application PurposeOriginal Equipment
Application Date2019-10-29
Frequency Range2402-2480 MHz
FRN0020249033
Test FirmPHOENIX TESTLAB GmbH
Certified BySabrina Berghahn
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2019-10-29
Available2019-10-29
Created2019-07-02
Modified2019-07-02
Pages4
File TypeAdobe Acrobat PDF
File Size357368
File SHA-256f15f0f03289c20c68a4005942f5d0e70df2679ff26643fe2de7fa4a587c07bfd
PDF Metadata AuthorBastert, Manuel
PDF Metadata ProducerPDF-XChange Office Addin PDF-XChange Printer V6 (6.0 build 322.3) [Windows 10 Professional x64 (Build 14393)]
FCC.gov SourcesFCC.gov 4494211
