FCC ID YVELB1DX
Communications Module
by Light Blue Optics
Grantee Code: YVE Product Code: LB1DX
Latest application date: 2016-12-15
Device Images
FCC ID Device Details
| FCC ID | YVELB1DX |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | YVE |
| Product Code | LB1DX |
| Applicant Business | Light Blue Optics 🇺🇸 |
| Related Domains |  lightblueoptics.com |
| Equipment Class | Communications Module |
| Test Firm | Bureau Veritas Hong Kong Limited |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2016-12-15 |
| 2402-2480 MHz | Change in identification of presently authorized equipment. Original FCC ID: VPYLB1DX Grant Date: 04/27/2016 | 2016-11-11 |
| 2402-2480 MHz | Change in identification of presently authorized equipment. Original FCC ID: VPYLB1DX Grant Date: 04/27/2016 | 2016-11-11 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Host External Photo | External Photos | 2016-12-15 | PDF 76.2 KB |
| External Photo | External Photos | 2016-11-11 | PDF 347.7 KB |
| External Photos | External Photos | 2016-11-11 | PDF 347.7 KB |
| Host Label | ID Label/Location Info | 2016-12-15 | PDF 1.3 MB |
| Label Exhibit | ID Label/Location Info | 2016-11-11 | PDF 58.6 KB |
| Test Set Up | Test Setup Photos | 2016-12-15 | PDF 315.7 KB |
| BT LE Rad Emissions Test Rport | Test Report | 2016-12-15 | PDF 354.8 KB |
| WLAN Rad Emissions Test Rport | Test Report | 2016-12-15 | PDF 391 KB |
| BT Basic Rate/ EDR Attestation | Attestation Statements | 2016-12-15 | PDF 68.9 KB |
| Authorisation Letter | Cover Letter(s) | 2016-12-15 | PDF 59.3 KB |
| Confidentiality Request | Cover Letter(s) | 2016-12-15 | PDF 59.4 KB |
| Permissive Change Request | Cover Letter(s) | 2016-12-15 | PDF 73.5 KB |
| Authorisation Request | Cover Letter(s) | 2016-11-11 | PDF 59.3 KB |
| Change in ID Authorisation | Cover Letter(s) | 2016-11-11 | PDF 29.3 KB |
| Request For Change in ID | Cover Letter(s) | 2016-11-11 | PDF 37.5 KB |
| Request for Change in ID | Cover Letter(s) | 2016-11-11 | PDF 37.5 KB |
| RF Exposure Evaluation | RF Exposure Info | 2016-12-15 | PDF 63.9 KB |
| Antenna Connection Details Metadata only | Operational Description | PDF 278.1 KB | |
| Antenna Specification Metadata only | Operational Description | PDF 211.2 KB |
Application Information
| Application ID | AlVbLe+ea/gOXIhwKX3/Bg== |
|---|---|
| Final Action Date | 2016-12-15 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0020257838 |
| Model | LB1DX |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Communications Module |
| Responsible Party | Nic Lawrence, C.E.O., nic@lightblueoptics.com , (530)868-6824 |
| Technical Contact | Raul Benet, Light Blue Optics, raul.benet@lightblueoptics.com , 44 1223 428500 |
| Non-Technical Contact | Nic Lawrence, Light Blue Optics, nic@lightblueoptics.com , 44 1223 428500 |
| Test Firm | Steven Tsang, Bureau Veritas Hong Kong Limited, steven.tsang@hk.bureauveritas.com  , 85223310728 |
| TCB Email | certification@ul.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Limited Modular Approval. Power listed is conducted. For professional installation only. Device shall not be sold to general public. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product guidelines. Use in portable RF exposure conditions will require additional filing for SAR compliance. Compliance of this device in all final product configurations is the responsibility of the Grantee. This module can only be used with a host antenna circuit trace layout design in strict compliance with the OEM instructions provided. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. Permissive Change for change in antenna and use in a specific host product as detailed in this filing. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| AlVbLe+ea/gOXIhwKX3/Bg== | 2016-12-15 | Class II permissive change or modification of presently authorized equipment |
| pAs/+RdDGqVw9XomE8bN9g== | 2016-11-11 | Change in identification of presently authorized equipment. Original FCC ID: VPYLB1DX Grant Date: 04/27/2016 |
| fVRF2IhqhhEpB11Oov8amQ== | 2016-11-11 | Change in identification of presently authorized equipment. Original FCC ID: VPYLB1DX Grant Date: 04/27/2016 |
Equipment Authorization
Grants
TCB Grant - Application pAs/+RdDGqVw9XomE8bN9g==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL International (UK) Ltd Unit 1 - 3 Horizon Kingsland Business Park Wade Road Basingstoke, RG24 8AH United Kingdom |
Date of Grant: 11/11/2016 Application Dated: 11/11/2016 |
| Light Blue Optics |
| 1900 S Norfolk St #350 |
| San Mateo, CA CA 94403 |
| Attention: Nic Lawrence , C.E.O. |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | YVELB1DX |
| Name of Grantee: | Light Blue Optics |
| Equipment Class: | Digital Transmission System |
| Notes: | Communications Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.007 | ||
| CC | 15C | 2412.0 - 2462.0 | 0.174 |
| Limited Modular Approval. Power listed is conducted. For professional installation only. Device shall not be sold to general public. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product guidelines. Use in portable RF exposure conditions will require additional filing for SAR compliance. Compliance of this device in all final product configurations is the responsibility of the Grantee. This module can only be used with a host antenna circuit trace layout design in strict compliance with the OEM instructions provided. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application pAs/+RdDGqVw9XomE8bN9g==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Light Blue Optics 1900 S Norfolk St #350 San Mateo, CA CA 94403 United States |
Date of Grant: 11/11/2016 Application Dated: 11/11/2016 |
| Attention: Nic Lawrence , C.E.O. |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | YVELB1DX |
| Name of Grantee: | Light Blue Optics |
| Equipment Class: | Digital Transmission System |
| Notes: | Communications Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.007 | ||
| CC | 15C | 2412.0 - 2462.0 | 0.174 |
| Limited Modular Approval. Power listed is conducted. For professional installation only. Device shall not be sold to general public. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product guidelines. Use in portable RF exposure conditions will require additional filing for SAR compliance. Compliance of this device in all final product configurations is the responsibility of the Grantee. This module can only be used with a host antenna circuit trace layout design in strict compliance with the OEM instructions provided. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL International (UK) Ltd Unit 1 - 3 Horizon Kingsland Business Park Wade Road Basingstoke, RG24 8AH United Kingdom |
Date of Grant: 11/11/2016 Application Dated: 11/11/2016 |
| Light Blue Optics |
| 1900 S Norfolk St #350 |
| San Mateo, CA CA 94403 |
| Attention: Nic Lawrence , C.E.O. |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | YVELB1DX |
| Name of Grantee: | Light Blue Optics |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Communications Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.009 |
| Limited Modular Approval. Power listed is conducted. For professional installation only. Device shall not be sold to general public. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product guidelines. Use in portable RF exposure conditions will require additional filing for SAR compliance. Compliance of this device in all final product configurations is the responsibility of the Grantee. This module can only be used with a host antenna circuit trace layout design in strict compliance with the OEM instructions provided. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application fVRF2IhqhhEpB11Oov8amQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Light Blue Optics 1900 S Norfolk St #350 San Mateo, CA CA 94403 United States |
Date of Grant: 11/11/2016 Application Dated: 11/11/2016 |
| Attention: Nic Lawrence , C.E.O. |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | YVELB1DX |
| Name of Grantee: | Light Blue Optics |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Communications Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.009 |
| Limited Modular Approval. Power listed is conducted. For professional installation only. Device shall not be sold to general public. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product guidelines. Use in portable RF exposure conditions will require additional filing for SAR compliance. Compliance of this device in all final product configurations is the responsibility of the Grantee. This module can only be used with a host antenna circuit trace layout design in strict compliance with the OEM instructions provided. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL International (UK) Ltd Unit 1 - 3 Horizon Kingsland Business Park Wade Road Basingstoke, RG24 8AH United Kingdom |
Date of Grant: 12/15/2016 Application Dated: 12/15/2016 |
| Light Blue Optics |
| 1900 S Norfolk St #350 |
| San Mateo, CA CA 94403 |
| Attention: Nic Lawrence , C.E.O. |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | YVELB1DX |
| Name of Grantee: | Light Blue Optics |
| Equipment Class: | Digital Transmission System |
| Notes: | Communications Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.007 | |||
| 15C | 2412.0 - 2462.0 | 0.174 |
| Limited Modular Approval. Power listed is conducted. For professional installation only. Device shall not be sold to general public. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product guidelines. Use in portable RF exposure conditions will require additional filing for SAR compliance. Compliance of this device in all final product configurations is the responsibility of the Grantee. This module can only be used with a host antenna circuit trace layout design in strict compliance with the OEM instructions provided. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. Permissive Change for change in antenna and use in a specific host product as detailed in this filing. |
EAS Grant - Application AlVbLe+ea/gOXIhwKX3/Bg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Light Blue Optics 1900 S Norfolk St #350 San Mateo, CA CA 94403 United States |
Date of Grant: 12/15/2016 Application Dated: 12/15/2016 |
| Attention: Nic Lawrence , C.E.O. |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | YVELB1DX |
| Name of Grantee: | Light Blue Optics |
| Equipment Class: | Digital Transmission System |
| Notes: | Communications Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.007 | |||
| 15C | 2412.0 - 2462.0 | 0.174 |
| Limited Modular Approval. Power listed is conducted. For professional installation only. Device shall not be sold to general public. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product guidelines. Use in portable RF exposure conditions will require additional filing for SAR compliance. Compliance of this device in all final product configurations is the responsibility of the Grantee. This module can only be used with a host antenna circuit trace layout design in strict compliance with the OEM instructions provided. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. Permissive Change for change in antenna and use in a specific host product as detailed in this filing. |
| Mail To: |
