MXT3DR Wireless trackball mouse Test Setup... - FCC ID YWO-M-XT3DR

FCC ID YWO-M-XT3DR

RF Test Set-up Photos

Wireless trackball mouse

by ELECOM CO., LTD.

Document preview loads when visible.

Document Details

FCC IDYWO-M-XT3DR
Document ID3173196
Document TypeTest Setup Photos
DescriptionRF Test Set-up Photos
Document TitleTest photos
ApplicantELECOM CO., LTD.
Equipment ClassWireless trackball mouse
Product CodeMXT3DR
Application IDhz1rOAVfwOAJYk0lTlhqZw==
Application PurposeOriginal Equipment
Application Date2016-10-25
Frequency Range2402-2479 MHz
FRN0020292918
Test FirmBureau Veritas Shenzhen Co., Ltd. Dongguan Branch
Certified ByAkiko Nakaminami
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartYes
Submitted2016-10-25
Available2016-10-25
Created2017-12-16
Modified2017-12-16
Pages2
File TypeAdobe Acrobat PDF
File Size289398
File SHA-256b5b4b201dbd86c2b12a770df7571834ec5c68f5cfdcba80b78cfb782afca21c0
PDF Metadata Authorglyhe
PDF Metadata ProducerGPL Ghostscript 9.18 glyhe
FCC.gov SourcesFCC.gov 3173196
