00KXN024W001A Digital Transmission... - FCC ID Z3D00KXN024W001A

FCC ID Z3D00KXN024W001A

Setup Photo

Digital Transmission System

by Kyushukyohan Co., Ltd

Document preview loads when visible.

Document Details

FCC IDZ3D00KXN024W001A
Document ID1581440
Document TypeTest Setup Photos
DescriptionSetup Photo
Document Title31KE0363-SH-01-A_FCC15_247
ApplicantKyushukyohan Co., Ltd
Equipment ClassDigital Transmission System
Product Code00KXN024W001A
Application ID1VjVTezTzpATQcwOrZHQuQ==
Application PurposeOriginal Equipment
Application Date2011-11-15
Frequency Range2402-2482 MHz
FRN0021177027
Test FirmUL Japan, Inc. Shonan EMC EMC Lab.
Certified ByYoshinobu Asai Team Leader
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date12/30/2011
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2011-11-15
Available2011-12-30
Created2011-09-28
Modified2011-09-29
Pages4
File TypeAdobe Acrobat PDF
File Size214789
File SHA-2565d7ea8e4bb75b3ddc7520c87def753cdfe82e2a4fb1b65def36fc053ebfa36a3
PDF Metadata Author40787
PDF Metadata CreatorPScript5.dll Version 5.2.2
PDF Metadata ProducerAcrobat Distiller 9.3.3 (Windows)
FCC.gov SourcesFCC.gov 1581440
