AIR7430 UHD Wireless Set-Top Box Test Setup... - FCC ID Z3WAIR7430
FCC ID Z3WAIR7430
Setup Photos
UHD Wireless Set-Top Box
Document preview loads when visible.
Document Details
| FCC ID | Z3WAIR7430 |
|---|---|
| Document ID | 4414941 |
| Document Type | Test Setup Photos |
| Description | Setup Photos |
| Applicant | AirTies Wireless Networks |
| Equipment Class | UHD Wireless Set-Top Box |
| Product Code | AIR7430 |
| Application ID | fKGcl3YT+fdwtzyc+OBLuA== |
| Application Purpose | Original Equipment |
| Application Date | 2019-10-15 |
| Frequency Range | 5180-5240 MHz |
| FRN | 0021185541 |
| Test Firm | Bay Area Compliance Laboratories Corp. (Taiwan) |
| Certified By | Mehmet Unal |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2019-08-26 |
| Available | 2019-10-15 |
| Created | 2019-08-20 |
| Modified | 2019-08-20 |
| Pages | 3 |
| File Type | Adobe Acrobat PDF |
| File Size | 578120 |
| File SHA-256 | f90c1c5bbc1661280c8bfe2a5d524a55a94c9fd5b9244d573dde594b9ef62c46 |
| PDF Metadata Author | TW211 |
| PDF Metadata Producer | TW211 Microsoft® Word 2013 |
| FCC.gov Sources | FCC.gov 4414941 |
