FCC ID Z4T-SEEEDAIR
2.4G WiFi Module
by Seeed Technology Co., Ltd.
Grantee Code: Z4T Product Code: SEEEDAIR
Latest application date: 2016-04-15
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-04-15 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2016-04-15 | PDF 746.2 KB |
| Internal Photos | Internal Photos | 2016-04-15 | PDF 347.9 KB |
| External Photos | External Photos | 2016-04-15 | PDF 159.4 KB |
| Label | ID Label/Location Info | 2016-04-15 | PDF 142.4 KB |
| Label Location | ID Label/Location Info | 2016-04-15 | PDF 249.7 KB |
| Test Set Up Photos | Test Setup Photos | 2016-04-15 | PDF 141.4 KB |
| Test Report | Test Report | 2016-04-15 | PDF 1.5 MB |
| Authority to Act as Agent | Cover Letter(s) | 2016-04-15 | PDF 31.7 KB |
| Confidentiality | Cover Letter(s) | 2016-04-15 | PDF 35.7 KB |
| DoC Status Letter | Cover Letter(s) | 2016-04-15 | PDF 67.8 KB |
| LMA Declaration | Cover Letter(s) | 2016-04-15 | PDF 76 KB |
| Limited Modular Approval Cover Letter | Cover Letter(s) | 2016-04-15 | PDF 71.9 KB |
| Statement from Manufacturer | Cover Letter(s) | 2016-04-15 | PDF 29 KB |
| RF Exposure | RF Exposure Info | 2016-04-15 | PDF 30.7 KB |
| Block Diagram Metadata only | Block Diagram | PDF 85.3 KB | |
| Schematics Metadata only | Schematics | PDF 132.7 KB | |
| Operational Description Metadata only | Operational Description | PDF 45.2 KB |
Application Information
| Application ID | BKWtXi6rIWR5tFzpL2Nr3Q== |
|---|---|
| Final Action Date | 2016-04-15 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0021206271 |
| Model | SEEEDAIR |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | 2.4G WiFi Module |
| Responsible Party | Albert Miao, R&D; Director, albert.miao@seeed.cc  , 86 0755-33162243 |
| Test Firm | Robinson Lo, Global United Technology Service Co., Ltd, robinson.lo@gtstest.com  , 86-755-27798480 |
| TCB Email | stuart.beck@nemko.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Limited Single Modular Approval. Power output listed is conducted. This device has a 20 MHz and 40 MHz bandwidth mode. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. This device is to be used only for mobile and fixed applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other transmitter. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and End-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| BKWtXi6rIWR5tFzpL2Nr3Q== | 2016-04-15 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2412-2462 MHz | 0.0341200 | 15C |
Grants
TCB Grant - Application BKWtXi6rIWR5tFzpL2Nr3Q==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Nemko North America, INC. 303 River Road Ottawa, Ontario, K1V 1H2 Canada |
Date of Grant: 04/15/2016 Application Dated: 04/14/2016 |
| Seeed Technology Co., Ltd. |
| 9F, G3 Building, TCL International E City, |
| Zhongshanyuan Road,Nanshan District |
| Shenzhen, 518055 China |
| Attention: Albert Miao , R&D Director |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | Z4T-SEEEDAIR |
| Name of Grantee: | Seeed Technology Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | 2.4G WiFi Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.03412 |
| Limited Single Modular Approval. Power output listed is conducted. This device has a 20 MHz and 40 MHz bandwidth mode. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. This device is to be used only for mobile and fixed applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other transmitter. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and End-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
EAS Grant - Application BKWtXi6rIWR5tFzpL2Nr3Q==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Seeed Technology Co., Ltd. 9F, G3 Building, TCL International E City, Zhongshanyuan Road,Nanshan District Shenzhen, 518055 China |
Date of Grant: 04/15/2016 Application Dated: 04/14/2016 |
| Attention: Albert Miao , R&D Director |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | Z4T-SEEEDAIR |
| Name of Grantee: | Seeed Technology Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | 2.4G WiFi Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.03412 |
| Limited Single Modular Approval. Power output listed is conducted. This device has a 20 MHz and 40 MHz bandwidth mode. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. This device is to be used only for mobile and fixed applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other transmitter. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and End-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
