FCC ID Z8H89FT0009
3GHz PMP 450 SM
by Cambium Networks Inc.
Grantee Code: Z8H Product Code: 89FT0009
Latest application date: 2019-07-10
Device Images
FCC ID Device Details
| FCC ID | Z8H89FT0009 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | Z8H |
| Product Code | 89FT0009 |
| Applicant Business | Cambium Networks Inc. 🇺🇸 |
| Related Domains |  cambiumnetworks.com |
| Equipment Class | 3GHz PMP 450 SM |
| Test Firm | Sporton International Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 3555-3695 MHz | Original Equipment | 2019-07-10 |
| 3652.5-3697.5 MHz | Class II permissive change or modification of presently authorized equipment | 2017-03-10 |
| 3652.5-3697.5 MHz | Original Equipment | 2014-03-20 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| manual cbrs | Users Manual | 2020-01-06 | PDF 4.7 MB |
| Exhibit D Users Manual per 2 1033 c3 | Users Manual | 2017-03-10 | PDF 3.5 MB |
| Exhibit D Users Manual per 2 1033 c3 | Users Manual | 2014-03-20 | PDF 2.7 MB |
| Internal Photographs of EUT_EP891811 | Internal Photos | 2020-01-06 | PDF 3.6 MB |
| Exhibit C Internal Photographs per 2 1033 c12 | Internal Photos | 2014-03-20 | PDF 427.5 KB |
| External Photographs of EUT_EP891811 | External Photos | 2020-01-06 | PDF 3.6 MB |
| Exhibit C External Photographs per 2 1033 c12 | External Photos | 2014-03-20 | PDF 374 KB |
| Label_C035045XxxxA | ID Label/Location Info | 2019-07-10 | PDF 74.2 KB |
| label location | ID Label/Location Info | 2019-07-10 | PDF 27.7 KB |
| Exhibit A ID Label and location per 2 1033 c2 and c11 | ID Label/Location Info | 2014-03-20 | PDF 65.5 KB |
| RF Test Photo_Part 96_20.40MHz Metadata only | Test Setup Photos | 2020-01-06 | PDF 252.2 KB |
| SAS Test Photo | Test Setup Photos | 2020-01-06 | PDF 105.5 KB |
| Test Photo_Part 96_10MHz | Test Setup Photos | 2020-01-06 | PDF 238.7 KB |
| Test Photo_Part 96_20.40MHz | Test Setup Photos | 2020-01-06 | PDF 251.9 KB |
| Exhibit C RE Test Setup photographs | Test Setup Photos | 2014-03-20 | PDF 1.4 MB |
| RF Test Report_Part 96_20.40MHz Metadata only | Test Report | 2019-07-10 | PDF 4.4 MB |
| SAS Protocol Test Report | Test Report | 2019-07-10 | PDF 2.5 MB |
| Test Report_Part 96_10MHz | Test Report | 2019-07-10 | PDF 2.6 MB |
| Test Report_Part 96_20.40MHz | Test Report | 2019-07-10 | PDF 4.4 MB |
| Exhibit E Test Measurement Report per 2 1033 c14 | Test Report | 2017-03-10 | PDF 2.4 MB |
| Exhibit E Test Measurement Report per 2 1033 c14 | Test Report | 2014-03-20 | PDF 5.2 MB |
| Professional installer attestation statement | Attestation Statements | 2019-07-10 | PDF 38.6 KB |
| Confidential Letter | Cover Letter(s) | 2019-07-10 | PDF 88.3 KB |
| POA | Cover Letter(s) | 2019-07-10 | PDF 18.4 KB |
| Cover Letter Requesting Class II Permissive Change | Cover Letter(s) | 2017-03-10 | PDF 223.4 KB |
| Cover Letter Requesting Confidentiality | Cover Letter(s) | 2014-03-20 | PDF 25.2 KB |
| RF Exposure | RF Exposure Info | 2019-07-10 | PDF 72.9 KB |
| Misc RF Exposure Exhibits | RF Exposure Info | 2014-03-20 | PDF 118.2 KB |
| Exhibit B Schematics per 2 1033 c10 Metadata only | Schematics | PDF 389 KB | |
| P036000_p3_sht1 Metadata only | Schematics | PDF 280.4 KB | |
| P036000_p3_sht2 Metadata only | Schematics | PDF 109.2 KB | |
| P036000_p3_sht3 Metadata only | Schematics | PDF 158.4 KB | |
| P036000_p3_sht4 Metadata only | Schematics | PDF 78.1 KB | |
| Exhibit B Operational Description per 2 1033 c 4 5 6 7 8 9 13 Metadata only | Operational Description | PDF 83 KB | |
| Operational Description_Antennas Metadata only | Operational Description | PDF 177.5 KB | |
| Theory of Op Metadata only | Operational Description | PDF 83 KB | |
| KDB 940660 Requirments Metadata only | SDR Software/Security Inf | PDF 56 KB | |
| Security Requirements Metadata only | SDR Software/Security Inf | PDF 84 KB | |
| Misc Tune Up Procedure Exhibits Metadata only | Parts List/Tune Up Info | PDF 203.2 KB | |
| Tune up procedure Metadata only | Parts List/Tune Up Info | PDF 242.1 KB |
Application Information
| Application ID | sMWP505/RnZy52c3gl0LPg== |
|---|---|
| Final Action Date | 2019-07-10 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0016216152 |
| Model | 89FT0009 |
| Frequency Range | 3555-3695 MHz |
| Equipment Class | CBD - Citizens Band Category A and B Devices |
| Device Description | 3GHz PMP 450 SM |
| Responsible Party | Steven M. Payne, R.F. Principle Staff Engineer, steve.payne@cambiumnetworks.com , 224-392-5930 |
| Test Firm | Alex Chen, Sporton International Inc., alex@sporton.com.tw  , 88633273456 |
| TCB Email | tei@timcoengr.com  |
| TCB Scope | B2: General Mobile Radio And Broadcast Services equipment in the following 47 CFR Parts 22 (non-cellular) 73, 74, 90, 95, 97, & 101 (all below 3 GHz) |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 01/06/2020 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | Yes |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | Yes |
| Grant Comments | Output Power is EIRP. Professional installation required. This transmitter must be installed to provide a separation distance of at least 100 cm from all persons, and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. This device supports LTE of 10, 20, and 40 MHz bandwidth modes for TDD LTE Band 48. Installers and end-users must be provided with antenna installation instructions and transmitter operating conditions and instructions for satisfying RF exposure compliance. This device is limited to outdoor operations. Software Defined Radio. Citizens Band Category B Device. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| sMWP505/RnZy52c3gl0LPg== | 2019-07-10 | Original Equipment |
| ClVJs+boIP01hwSpQUQKpA== | 2017-03-10 | Class II permissive change or modification of presently authorized equipment |
| lVK+Tv8TeJuHjmiXnDti8w== | 2014-03-20 | Original Equipment |
Equipment Authorization
| Frequency | Output | Tolerance | Emission | Rules | Grant Notes |
|---|---|---|---|---|---|
| 3555-3695 MHz | 34.674 | 2ppm | 10M0X1D | 96 | EP, MO |
| 3560-3690 MHz | 32.137 | 2ppm | 20M0X1D | 96 | EP, MO |
| 3570-3680 MHz | 47.643 | 2ppm | 40M0X1D | 96 | EP, MO |
| 3652.5-3697.5 MHz | 4.95 | 2ppm | 5M00X1D | 9 | MO, UR |
| 3655-3695 MHz | 9.91 | 2ppm | 10M0X1D | 9 | MO, UR |
| 3660-3690 MHz | 18.9 | 2ppm | 20M0X1D | 9 | MO, UR |
| 3670-3680 MHz | 13.52 | 2ppm | 40M0X1D | 9 | MO, UR |
Grants
TCB Grant - Application sMWP505/RnZy52c3gl0LPg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 07/10/2019 Application Dated: 03/11/2019 |
| Cambium Networks Inc. |
| 3800 Golf Road |
| Suite 360 |
| Rolling Meadows, IL 60008 |
| Attention: Steven Payne , R.F. Principle Staff Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | Z8H89FT0009 |
| Name of Grantee: | Cambium Networks Inc. |
| Equipment Class: | Citizens Band Category A and B Devices |
| Notes: | 3GHz PMP 450 SM |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| EP MO | 96 | 3555.0 - 3695.0 | 34.674 | 2.0 PM | 10M0X1D |
| EP MO | 96 | 3560.0 - 3690.0 | 32.137 | 2.0 PM | 20M0X1D |
| EP MO | 96 | 3570.0 - 3680.0 | 47.643 | 2.0 PM | 40M0X1D |
| Output Power is EIRP. Professional installation required. This transmitter must be installed to provide a separation distance of at least 100 cm from all persons, and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. This device supports LTE of 10, 20, and 40 MHz bandwidth modes for TDD LTE Band 48. Installers and end-users must be provided with antenna installation instructions and transmitter operating conditions and instructions for satisfying RF exposure compliance. This device is limited to outdoor operations. Software Defined Radio. Citizens Band Category B Device. |
| EP: | Output power is Effective Isotropic Radiated Power (EIRP) |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
