FCC ID Z8H89FT0010
3GHz PMP 450 AP
by Cambium Networks Inc.
Grantee Code: Z8H Product Code: 89FT0010
Latest application date: 2019-07-02
Device Images
FCC ID Device Details
| FCC ID | Z8H89FT0010 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | Z8H |
| Product Code | 89FT0010 |
| Applicant Business | Cambium Networks Inc. 🇺🇸 |
| Related Domains |  cambiumnetworks.com |
| Equipment Class | 3GHz PMP 450 AP |
| Test Firm | Sporton International Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 3555-3695 MHz | Original Equipment | 2019-07-02 |
| 3652.5-3697.5 MHz | Class II permissive change or modification of presently authorized equipment | 2017-03-10 |
| 3652.5-3697.5 MHz | Original Equipment | 2014-03-20 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2019-12-29 | PDF 3.2 MB |
| Exhibit D Users Manual per 2 1033 c3 | Users Manual | 2017-03-10 | PDF 3.5 MB |
| Exhibit D Users Manual per 2 1033 c3 | Users Manual | 2014-03-20 | PDF 2.8 MB |
| Internal Photo | Internal Photos | 2019-12-29 | PDF 969.8 KB |
| Exhibit C Internal Photographs per 2 1033 c12 | Internal Photos | 2014-03-20 | PDF 402.9 KB |
| External Photo | External Photos | 2019-07-02 | PDF 309.6 KB |
| Exhibit C External Photographs per 2 1033 c12 | External Photos | 2014-03-20 | PDF 116.1 KB |
| Label Location | ID Label/Location Info | 2019-07-02 | PDF 36.6 KB |
| Exhibit A ID Label and location per 2 1033 c2 and c11 | ID Label/Location Info | 2014-03-20 | PDF 60.2 KB |
| Test Photo_Part 96 10M | Test Setup Photos | 2019-07-02 | PDF 200.6 KB |
| Test Photo_Part 96 20.40M | Test Setup Photos | 2019-07-02 | PDF 251.4 KB |
| Test Photo_SAS | Test Setup Photos | 2019-07-02 | PDF 111.5 KB |
| Exhibit E Test Measurement Report per 2 1033 c14 | Test Setup Photos | 2014-03-20 | PDF 739 KB |
| SAS Protocol Test Report | Test Report | 2019-07-02 | PDF 2.4 MB |
| Test Report_Part 96 10M | Test Report | 2019-07-02 | PDF 2.6 MB |
| Test Report_Part 96 20.40M Metadata only | Test Report | 2019-07-02 | PDF 5 MB |
| Test Report_Part 96 20.40M_part1 | Test Report | 2019-07-02 | PDF 3.5 MB |
| Test Report_Part 96 20.40M_part2 | Test Report | 2019-07-02 | PDF 1.6 MB |
| Exhibit E Test Measurement Report per 2 1033 c14 | Test Report | 2017-03-10 | PDF 2.4 MB |
| Exhibit E Test Measurement Report per 2 1033 c14 | Test Report | 2014-03-20 | PDF 3.7 MB |
| Confidential Letter | Cover Letter(s) | 2019-07-02 | PDF 101.7 KB |
| POA | Cover Letter(s) | 2019-07-02 | PDF 67.7 KB |
| Professional Installation Declaration | Cover Letter(s) | 2019-07-02 | PDF 70.4 KB |
| Cover Letter Requesting Class II Permissive Change | Cover Letter(s) | 2017-03-10 | PDF 223.3 KB |
| Cover Letter Requesting Confidentiality | Cover Letter(s) | 2014-03-20 | PDF 24.5 KB |
| MPE report | RF Exposure Info | 2019-07-02 | PDF 96.6 KB |
| Misc RF Exposure Exhibits | RF Exposure Info | 2014-03-20 | PDF 89 KB |
| Block Diagram Metadata only | Block Diagram | PDF 53.6 KB | |
| Exhibit B Block Diagram per 2 1033 b5 Metadata only | Block Diagram | PDF 83.1 KB | |
| Exhibit B Schematics per 2 1033 c10 Metadata only | Schematics | PDF 597 KB | |
| Schematics Metadata only | Schematics | PDF 483.5 KB | |
| Exhibit B Operational Description per 2 1033 c 4 5 6 7 8 9 13 Metadata only | Operational Description | PDF 83 KB | |
| Operational Description Metadata only | Operational Description | PDF 83.2 KB | |
| Operational Description_Antennas Metadata only | Operational Description | PDF 177.5 KB | |
| Security Requirements_part 96 Metadata only | SDR Software/Security Inf | PDF 57 KB | |
| BOM Metadata only | Parts List/Tune Up Info | PDF 293.2 KB | |
| Misc Tune Up Procedure Exhibits Metadata only | Parts List/Tune Up Info | PDF 203.2 KB | |
| Tune up procedure CBRS Metadata only | Parts List/Tune Up Info | PDF 230.9 KB |
Application Information
| Application ID | lqbGNMYMz8zgMN6xCQQ0BQ== |
|---|---|
| Final Action Date | 2019-07-02 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0016216152 |
| Model | 89FT0010 |
| Frequency Range | 3555-3695 MHz |
| Equipment Class | CBD - Citizens Band Category A and B Devices |
| Device Description | 3GHz PMP 450 AP |
| Responsible Party | Steven M. Payne, R.F. Principle Staff Engineer, steve.payne@cambiumnetworks.com , 224-392-5930 |
| Test Firm | Alex Chen, Sporton International Inc., alex@sporton.com.tw  , 88633273456 |
| TCB Email | tei@timcoengr.com  |
| TCB Scope | B2: General Mobile Radio And Broadcast Services equipment in the following 47 CFR Parts 22 (non-cellular) 73, 74, 90, 95, 97, & 101 (all below 3 GHz) |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 12/29/2019 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | Yes |
| Grant Comments | Output Power is EIRP. Professional installation required. This transmitter must be installed to provide a separation distance of at least 100 cm from all persons, and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. This device supports LTE of 10, 20, and 40 MHz bandwidth modes for TDD LTE Band 48. Installers and end-users must be provided with antenna installation instructions and transmitter operating conditions and instructions for satisfying RF exposure compliance. This device is limited to outdoor operations. Software Defined Radio. Citizens Band Category B Device. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| lqbGNMYMz8zgMN6xCQQ0BQ== | 2019-07-02 | Original Equipment |
| SWn77BCv6kfPD3WJ9ff2aA== | 2017-03-10 | Class II permissive change or modification of presently authorized equipment |
| mCW1EMo/GHyR1iS6IAIT6Q== | 2014-03-20 | Original Equipment |
Equipment Authorization
| Frequency | Output | Tolerance | Emission | Rules | Grant Notes |
|---|---|---|---|---|---|
| 3555-3695 MHz | 32.359 | 2ppm | 10M0X1D | 96 | EP, MO |
| 3560-3690 MHz | 85.31 | 2ppm | 20M0X1D | 96 | EP, MO |
| 3570-3680 MHz | 26.242 | 2ppm | 40M0X1D | 96 | EP, MO |
| 3652.5-3697.5 MHz | 4.85 | 2ppm | 5M00X1D | 9 | MO, UR |
| 3655-3695 MHz | 9.2 | 2ppm | 10M0X1D | 9 | MO, UR |
| 3660-3690 MHz | 18.32 | 2ppm | 20M0X1D | 9 | MO, UR |
| 3670-3680 MHz | 8.375 | 2ppm | 40M0X1D | 9 | MO, UR |
