EDF260 True Wireless Earbuds Test Setup Photos - FCC ID Z9G-EDF260

FCC ID Z9G-EDF260

Test Setup Photo

True Wireless Earbuds

by Edifier International Limited

Document preview loads when visible.

Document Details

FCC IDZ9G-EDF260
Document ID7644868
Document TypeTest Setup Photos
DescriptionTest Setup Photo
ApplicantEdifier International Limited
Equipment ClassTrue Wireless Earbuds
Product CodeEDF260
Application ID0KF/WodiJ9xFjQQDjR6B8g==
Application PurposeOriginal Equipment
Application Date2024-09-08
Frequency Range2402-2480 MHz
FRN0021277140
Test FirmEST Technology Co., Ltd.
Certified ByGeng Chen
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2024-09-08
Available2024-09-08
Created2024-09-03
Modified2024-09-03
Pages1
File TypeAdobe Acrobat PDF
File Size235283
File SHA-25665c5a8cd2e1f2fe632411e1b1343fa3b36ab77a6e4bd36b85b8a7b08cfb48759
PDF Metadata AuthorWindows User
PDF Metadata ProducerMicrosoft® Word 2016 Microsoft® Word 2016
FCC.gov SourcesFCC.gov 7644868, FCC.gov 7644851
