EDF282 Studio Monitor Test Setup Photos - FCC ID Z9G-EDF282

FCC ID Z9G-EDF282

Test Setup Photos

Studio Monitor

by Edifier International Limited

Document preview loads when visible.

Document Details

FCC IDZ9G-EDF282
Document ID8168782
Document TypeTest Setup Photos
DescriptionTest Setup Photos
ApplicantEdifier International Limited
Equipment ClassStudio Monitor
Product CodeEDF282
Application IDqggFApFH+mLC8clKkX3yDQ==
Application PurposeOriginal Equipment
Application Date2025-04-02
Frequency Range2402-2480 MHz
FRN0021277140
Test FirmGuangdong Dongdian Testing Service Co., Ltd.
Certified ByGeng Chen
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date09/30/2025
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2025-04-02
Available2025-09-30
Created2025-03-28
Modified2025-03-28
Pages2
File TypeAdobe Acrobat PDF
File Size482496
File SHA-2564e5ca166f77eb8566238ff2b939734ee7660febd587d2f13015f9132ede5500c
PDF Metadata Producer迅捷PDF编辑器 7.0.324.2 PDF-XChange Core API SDK (7.0.324.2)
FCC.gov SourcesFCC.gov 8168782, FCC.gov 8168727
