1180DB868 The CC1180DB is a development... - FCC ID ZAT1180DB868

FCC ID ZAT1180DB868

block diagram

The CC1180DB is a development tool for TIs sub 1 GHz CC1180 chip.

by Texas Instruments Inc.

Document preview loads when visible.

Document Details

FCC IDZAT1180DB868
Document ID1908993
Document TypeBlock Diagram
Descriptionblock diagram
Document TitleVisio-CC1180DB_Block_Diagram.vsd
ApplicantTexas Instruments Inc.
Equipment ClassThe CC1180DB is a development tool for TIs sub 1 GHz CC1180 chip.
Product Code1180DB868
Application ID+6fmnGJdGMvK7vOpleRBgQ==
Application PurposeOriginal Equipment
Application Date2013-02-28
Frequency Range903.5-926.5 MHz
FRN0020623971
Test FirmNemko AS
Certified ByZarah MacIvor Project Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2013-02-28
Available2013-02-28
Created2012-10-25
Modified2012-10-25
Pages1
File TypeAdobe Acrobat PDF
File Size18228
File SHA-2562a6ff7686165d2420105ed2f49839b115a6284e664f1233951df09effee7e0c5
PDF Metadata Authora0132607
PDF Metadata CreatorPScript5.dll Version 5.2.2
PDF Metadata ProducerAcrobat Distiller 6.0 (Windows)
FCC.gov SourcesFCC.gov 1908993
