2531USB The CC2531Dongle is a development... - FCC ID ZAT2531USB

FCC ID ZAT2531USB

Schematics

The CC2531Dongle is a development tool for Texas Instruments 2.4 GHz CC2531 IEEE 802.15.4 System-on-Chip with USB

by Texas Instruments Inc.

Document preview loads when visible.

Document Details

FCC IDZAT2531USB
Document ID1939532
Document TypeSchematics
DescriptionSchematics
Document TitleNone
ApplicantTexas Instruments Inc.
Equipment ClassThe CC2531Dongle is a development tool for Texas Instruments 2.4 GHz CC2531 IEEE 802.15.4 System-on-Chip with USB
Product Code2531USB
Application ID/0IQa29BX9bwE7fPO6Si7w==
Application PurposeOriginal Equipment
Application Date2013-04-15
Frequency Range2425-2475 MHz
FRN0020623971
Test FirmNemko AS
Certified ByZarah MacIvor Project Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2013-04-15
Available2013-04-15
Created2010-01-26
Modified2010-01-26
Pages4
File TypeAdobe Acrobat PDF
File Size164397
File SHA-25612d0f5cfbc109b6f85c7a8fa4ae26bf1f94178ef85f4b4edcfe18c0de45af889
PDF Metadata AuthorNone
PDF Metadata CreatorNone
PDF Metadata ProducerNone
FCC.gov SourcesFCC.gov 1939532
