2541EM The CC2541EM is a development tool for... - FCC ID ZAT2541EM

FCC ID ZAT2541EM

Block Diagram

The CC2541EM is a development tool for TI’s 2.4 GHz CC2541 Bluetooth® Low Energy System-on-Chip.

by Texas Instruments Inc.

Document preview loads when visible.

Document Details

FCC IDZAT2541EM
Document ID1622287
Document TypeBlock Diagram
DescriptionBlock Diagram
Document Titletmpx
ApplicantTexas Instruments Inc.
Equipment ClassThe CC2541EM is a development tool for TI’s 2.4 GHz CC2541 Bluetooth® Low Energy System-on-Chip.
Product Code2541EM
Application IDmbrUTD0VwsHs4h0EHcLHGA==
Application PurposeOriginal Equipment
Application Date2012-01-18
Frequency Range2402-2480 MHz
FRN0020623971
Test FirmNemko AS
Certified ByZarah MacIvor Project Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentLimited Single Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2012-01-17
Available2012-01-18
Created2012-01-12
Modified2012-01-12
Pages1
File TypeAdobe Acrobat PDF
File Size446285
File SHA-2568005018e1efea8ee8bf39d583ffd2f7a61ec36c76f4c6f50d90c169ca55fcd8f
PDF Metadata Authora0190631
PDF Metadata CreatorMicrosoft Word - tmp.docx
PDF Metadata ProducerScanSoft PDF Create! 5
FCC.gov SourcesFCC.gov 1622287, FCC.gov 1622286
