J10006 Bluetooth Touch Pen Test Setup Photos - FCC ID ZCC-J10006

FCC ID ZCC-J10006

Setup Photo

Bluetooth Touch Pen

by Adonit Co., Ltd.

Document preview loads when visible.

Document Details

FCC IDZCC-J10006
Document ID2525161
Document TypeTest Setup Photos
DescriptionSetup Photo
Document TitleTest Setup-10050022_Adonit_050 JS _FCC IC NCC
ApplicantAdonit Co., Ltd.
Equipment ClassBluetooth Touch Pen
Product CodeJ10006
Application ID3JvlgewhdNP8ru/P/OGAjA==
Application PurposeOriginal Equipment
Application Date2015-02-06
Frequency Range2402-2480 MHz
FRN0020668364
Test FirmTUV Rheinland Taiwan Ltd
Certified ByZachary Zeliff CTO
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2015-02-05
Available2015-02-06
Created2015-02-05
Modified2015-02-05
Pages3
File TypeAdobe Acrobat PDF
File Size591144
File SHA-256f0b0a53fe9cf72aed68828786e2cab9985bcec96d05e06fbfe0cd505bd7993f5
PDF Metadata Authorchartonr
PDF Metadata ProducerAFPL Ghostscript 8.53 FreePDF 4.02 - http://shbox.de
FCC.gov SourcesFCC.gov 2525161
