NACEUR3 Multimedia System Test Setup Photos - FCC ID ZFW-NACEUR3

FCC ID ZFW-NACEUR3

Test Photos

Multimedia System

by CONTINENTAL AUTOMOTIVE RAMBOUILLET FRANCE SAS

Document preview loads when visible.

Document Details

FCC IDZFW-NACEUR3
Document ID3678466
Document TypeTest Setup Photos
DescriptionTest Photos
Document Title1790307R-RFUSP01V00-A Report-DEKRA(SPA)(NAC EUR wave 3)-Version (V1.0)(BT 2.0)
ApplicantCONTINENTAL AUTOMOTIVE RAMBOUILLET FRANCE SAS
Equipment ClassMultimedia System
Product CodeNACEUR3
Application IDo+/3icFXm1tLPazMGYYYxw==
Application PurposeOriginal Equipment
Application Date2017-12-15
Frequency Range2402-2480 MHz
FRN0020634630
Test FirmDEKRA TESTING AND CERTIFICATION Hsin Chu Lab.
Certified ByAlaine Sauve Quality Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date06/13/2018
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2017-12-14
Available2018-06-13
Created2017-11-29
Modified2017-12-01
Pages22
File TypeAdobe Acrobat PDF
File Size3480696
File SHA-256fce9754e942eb95688271ee4844583d666f92af02a9a29c0b4a4d9e7e4fa521b
PDF Metadata AuthorA316121
PDF Metadata ProducerA316121 Acrobat Distiller 9.0.0 (Windows)
FCC.gov SourcesFCC.gov 3678466
