IPBT500 eBeam Pen Teardown Internal Photos - FCC ID ZGB-IPBT-500

FCC ID ZGB-IPBT-500

Internal photos

eBeam Pen

by Luidia Global Co.,LTD

Document preview loads when visible.

Document Details

FCC IDZGB-IPBT-500
Document ID3539597
Document TypeInternal Photos
DescriptionInternal photos
Document Title[IPBT-500] INT Photo
ApplicantLuidia Global Co.,LTD
Equipment ClasseBeam Pen
Product CodeIPBT500
Application IDDOGUdywKSIT7nQt3Msx4Xg==
Application PurposeOriginal Equipment
Application Date2017-08-31
Frequency Range2402-2480 MHz
FRN0020763553
Test FirmDT&C; Co., Ltd.
Certified ByJin Gu Kim Manager, Luidia Global Co., LTD.
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date02/27/2018
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2017-08-31
Available2018-02-27
Created2017-08-29
Modified2017-08-29
Pages5
File TypeAdobe Acrobat PDF
File Size5396830
File SHA-256f0247978d1d74e476c4a5c7bff78551d4dba9842e91600482f4b8a449fc96b01
PDF Metadata AuthorSJM
PDF Metadata ProducerSJM Acrobat Distiller 9.5.5 (Windows)
FCC.gov SourcesFCC.gov 3539597
