8092991 Bluetooth Audio Speaker External Photos - FCC ID ZHW-8092991

FCC ID ZHW-8092991

External Photos

Bluetooth Audio Speaker

by The Source (Bell) Electronics Inc.

Document preview loads when visible.

Document Details

FCC IDZHW-8092991
Document ID5323542
Document TypeExternal Photos
DescriptionExternal Photos
Document TitleExternal Photos
ApplicantThe Source (Bell) Electronics Inc.
Equipment ClassBluetooth Audio Speaker
Product Code8092991
Application IDdw7r+8W1DUaCM8MvrbFzSA==
Application PurposeOriginal Equipment
Application Date2021-07-02
Frequency Range2402-2480 MHz
FRN0020800041
Test FirmBay Area Compliance Laboratories Corp. (Shenzhen)
Certified ByRaymond McLaren
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2021-07-02
Available2021-07-02
Created2021-06-25
Modified2021-06-25
Pages4
File TypeAdobe Acrobat PDF
File Size943996
File SHA-25629f14f5e5b370d4bf2616df63a4da3dc6b73de27435617a2fbcc904ea0e6770b
PDF Metadata Authorsusan.huang
PDF Metadata ProducerAcrobat Distiller 9.0.0 (Windows) susan.huang
FCC.gov SourcesFCC.gov 5323542
