LA66V2 LA66 USB Adapater V2 Test Setup Photos - FCC ID ZHZLA66-V2
FCC ID ZHZLA66-V2
Test Setup Photos
LA66 USB Adapater V2
Document preview loads when visible.
Document Details
| FCC ID | ZHZLA66-V2 |
|---|---|
| Document ID | 7854378 |
| Document Type | Test Setup Photos |
| Description | Test Setup Photos |
| Document Title | Test Setup Photos-15.247 |
| Applicant | Dragino Technology Co., Limited. |
| Equipment Class | LA66 USB Adapater V2 |
| Product Code | LA66V2 |
| Application ID | uyLxDu6QUt1EU0GoE5/QQg== |
| Application Purpose | Original Equipment |
| Application Date | 2024-11-26 |
| Frequency Range | 904.6-923.3 MHz |
| FRN | 0020806964 |
| Test Firm | Bay Area Compliance Laboratories Corp (Shenzhen) |
| Certified By | Edwin Chen |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2024-11-26 |
| Available | 2024-11-26 |
| Created | 2024-11-06 |
| Modified | 2024-11-06 |
| Pages | 3 |
| File Type | Adobe Acrobat PDF |
| File Size | 2057769 |
| File SHA-256 | b4b0475c574d155a45b9c40c7e9d376a6cc4dca4b6d54477108bbb81a6a26b5c |
| PDF Metadata Author | winnie.xiao |
| PDF Metadata Producer | Acrobat Distiller 9.0.0 (Windows) winnie.xiao |
| FCC.gov Sources | FCC.gov 7854378, FCC.gov 7854348 |
