WCATA009 Wi-Fi/Bluetooth Combo Module User... - FCC ID ZKJ-WCATA009
FCC ID ZKJ-WCATA009
User Manual
Wi-Fi/Bluetooth Combo Module
Document preview loads when visible.
Document Details
| FCC ID | ZKJ-WCATA009 |
|---|---|
| Document ID | 5688329 |
| Document Type | Users Manual |
| Description | User Manual |
| Document Title | 1.User's Manual_WCATA009 - 수정 |
| Applicant | Haier US Appliance Solutions, Inc. |
| Equipment Class | Wi-Fi/Bluetooth Combo Module |
| Product Code | WCATA009 |
| Application ID | OQiUI0QHBoWiOjgz37NiVw== |
| Application Purpose | Original Equipment |
| Application Date | 2022-02-18 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0025028994 |
| Test Firm | CTK Co., Ltd. |
| Certified By | Park, Hansung |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2022-02-18 |
| Available | 2022-02-18 |
| Created | 2022-02-15 |
| Modified | 2022-02-16 |
| Pages | 6 |
| File Type | Adobe Acrobat PDF |
| File Size | 183294 |
| File SHA-256 | 847bcfffadd394edc15c78d645bf14f9b419feeaa71fd8a9370d0729b5a9b6d1 |
| PDF Metadata Author | jhchoi |
| PDF Metadata Producer | Acrobat Distiller 9.3.0 (Windows) jhchoi |
| FCC.gov Sources | FCC.gov 5688329 |
