FCC ID ZLJTOP-S5
Wireless Module
by TOPLINKST TECHNOLOGY COMPANY LIMITED
Grantee Code: ZLJ Product Code: TOPS5
Latest application date: 2017-03-21
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Change in identification of presently authorized equipment. Original FCC ID: YWTWF55724MX Grant Date: 12/30/2015 | 2017-03-21 |
| 2412-2462 MHz | Change in identification of presently authorized equipment. Original FCC ID: YWTWF55724MX Grant Date: 12/30/2015 | 2017-03-21 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2017-03-21 | PDF 699.1 KB |
| External Photos | External Photos | 2017-03-21 | PDF 213.9 KB |
| FCC ID Label and Location | ID Label/Location Info | 2017-03-21 | PDF 104.6 KB |
| Authorization Letter from Original Grantee | Cover Letter(s) | 2017-03-21 | PDF 26.4 KB |
| Change ID Request Letter | Cover Letter(s) | 2017-03-21 | PDF 107.3 KB |
| Cover Letter_KDB594280 | Cover Letter(s) | 2017-03-21 | PDF 43.3 KB |
Application Information
| Application ID | ehzNTS0geDX4kj9GnCgkcg== |
|---|---|
| Final Action Date | 2017-03-21 |
| Application Purpose | Change in identification of presently authorized equipment. Original FCC ID: YWTWF55724MX Grant Date: 12/30/2015 |
| Applicant FRN | 0020874855 |
| Model | TOP-S5 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Wireless Module |
| Responsible Party | YanHua Zhang, Manager, zhangyh092@126.com  , 852-27935511 |
| Test Firm | Daisy Dai, BTL Inc., daisy.dai@newbtl.org.cn  , 8676983183000 |
| TCB Email | bentje.holger@phoenix-testlab.de  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Modular Approval. Output power listed is conducted. This module with its antenna(s) must be installed and used in fixed/mobile operating conditions and must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with the FCC multi-transmitter policy. Grantee shall provide installation and operating instructions for satisfying RF exposure requirements to OEM integrators and installers. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Device is operating in a 2T2R MIMO configuration as described in this filing. This device has 20 and 40 BW modes. Operation of this device is restricted to indoor use only. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| ehzNTS0geDX4kj9GnCgkcg== | 2017-03-21 | Change in identification of presently authorized equipment. Original FCC ID: YWTWF55724MX Grant Date: 12/30/2015 |
| 0d+wGXMUAvSU2B0z/qrTBA== | 2017-03-21 | Change in identification of presently authorized equipment. Original FCC ID: YWTWF55724MX Grant Date: 12/30/2015 |
Equipment Authorization
Grants
TCB Grant - Application ehzNTS0geDX4kj9GnCgkcg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
PHOENIX TESTLAB GmbH Koenigswinkel 10 32825 Blomberg, Germany |
Date of Grant: 03/21/2017 Application Dated: 03/21/2017 |
| TOPLINKST TECHNOLOGY COMPANY LIMITED |
| UNIT 04,7F,BRIGHT WAY TOWER, NO,33 MONG KOK ROAD |
| KOWLOON, Hong Kong |
| Attention: YanHua Zhang , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | ZLJTOP-S5 |
| Name of Grantee: | TOPLINKST TECHNOLOGY COMPANY LIMITED |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.012 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.012 |
| Modular Approval. Output power listed is conducted. This module with its antenna(s) must be installed and used in fixed/mobile operating conditions and must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with the FCC multi-transmitter policy. Grantee shall provide installation and operating instructions for satisfying RF exposure requirements to OEM integrators and installers. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Device is operating in a 2T2R MIMO configuration as described in this filing. This device has 20 and 40 BW modes. Operation of this device is restricted to indoor use only. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application ehzNTS0geDX4kj9GnCgkcg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
TOPLINKST TECHNOLOGY COMPANY LIMITED UNIT 04,7F,BRIGHT WAY TOWER, NO,33 MONG KOK ROAD KOWLOON, Hong Kong |
Date of Grant: 03/21/2017 Application Dated: 03/21/2017 |
| Attention: YanHua Zhang , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | ZLJTOP-S5 |
| Name of Grantee: | TOPLINKST TECHNOLOGY COMPANY LIMITED |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.012 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.012 |
| Modular Approval. Output power listed is conducted. This module with its antenna(s) must be installed and used in fixed/mobile operating conditions and must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with the FCC multi-transmitter policy. Grantee shall provide installation and operating instructions for satisfying RF exposure requirements to OEM integrators and installers. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Device is operating in a 2T2R MIMO configuration as described in this filing. This device has 20 and 40 BW modes. Operation of this device is restricted to indoor use only. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
PHOENIX TESTLAB GmbH Koenigswinkel 10 32825 Blomberg, Germany |
Date of Grant: 03/21/2017 Application Dated: 03/21/2017 |
| TOPLINKST TECHNOLOGY COMPANY LIMITED |
| UNIT 04,7F,BRIGHT WAY TOWER, NO,33 MONG KOK ROAD |
| KOWLOON, Hong Kong |
| Attention: YanHua Zhang , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | ZLJTOP-S5 |
| Name of Grantee: | TOPLINKST TECHNOLOGY COMPANY LIMITED |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.05 |
| Modular Approval. Output power listed is conducted. This module with its antenna(s) must be installed and used in fixed/mobile operating conditions and must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with the FCC multi-transmitter policy. Grantee shall provide installation and operating instructions for satisfying RF exposure requirements to OEM integrators and installers. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Device is operating in a 2T2R MIMO configuration as described in this filing. This device has 20 and 40 BW modes. Operation of this device is restricted to indoor use only. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application 0d+wGXMUAvSU2B0z/qrTBA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
TOPLINKST TECHNOLOGY COMPANY LIMITED UNIT 04,7F,BRIGHT WAY TOWER, NO,33 MONG KOK ROAD KOWLOON, Hong Kong |
Date of Grant: 03/21/2017 Application Dated: 03/21/2017 |
| Attention: YanHua Zhang , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | ZLJTOP-S5 |
| Name of Grantee: | TOPLINKST TECHNOLOGY COMPANY LIMITED |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.05 |
| Modular Approval. Output power listed is conducted. This module with its antenna(s) must be installed and used in fixed/mobile operating conditions and must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with the FCC multi-transmitter policy. Grantee shall provide installation and operating instructions for satisfying RF exposure requirements to OEM integrators and installers. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Device is operating in a 2T2R MIMO configuration as described in this filing. This device has 20 and 40 BW modes. Operation of this device is restricted to indoor use only. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: |
