WLINK wireless module Test Report - FCC ID ZLZ-WLINK

FCC ID ZLZ-WLINK

Test Report

wireless module

by Shenzhen Mindray BIO-Medical electronics Co.,LTD.

Document preview loads when visible.

Document Details

FCC IDZLZ-WLINK
Document ID6450384
Document TypeTest Report
DescriptionTest Report
Document TitleWTD22D04074056W001 FCC 15.247&15.407 test report
ApplicantShenzhen Mindray BIO-Medical electronics Co.,LTD.
Equipment Classwireless module
Product CodeWLINK
Application IDwY4Swte6s0pIDDmNczBhDQ==
Application PurposeClass II Permissive Change
Application Date2023-03-30
Frequency Range5180-5240 MHz
FRN0020888061
Test FirmWALTEK TESTING GROUP CO., LTD.
Certified ByPhilo zhong
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceYes
Composite PartNo
Submitted2023-03-30
Available2023-03-30
Created2023-03-27
Modified2023-03-27
Pages52
File TypeAdobe Acrobat PDF
File Size450955
File SHA-256e11c3b438fac6ef548eaddc57eec2749b04195eabc64fc25ba445f3d8cbde7c0
PDF Metadata AuthorAdministrator
PDF Metadata ProducerAdministrator Acrobat Distiller 11.0 (Windows)
FCC.gov SourcesFCC.gov 6450384, FCC.gov 6450310
