H818P Multi-band GSM/EDGE/WCDMA/LTE Phone with... - FCC ID ZNFH818P

FCC ID ZNFH818P

Internal Photographs

Multi-band GSM/EDGE/WCDMA/LTE Phone with WLAN, Bluetooth and RFID

by LG Electronics USA, Inc.

Document preview loads when visible.

Document Details

FCC IDZNFH818P
Document ID2600243
Document TypeInternal Photos
DescriptionInternal Photographs
Document TitleLG_LG-H818P RF_INTERNAL PHOTO
ApplicantLG Electronics USA, Inc.
Equipment ClassMulti-band GSM/EDGE/WCDMA/LTE Phone with WLAN, Bluetooth and RFID
Product CodeH818P
Application IDA3JVzHpXphtdcxc/JmdFxQ==
Application PurposeOriginal Equipment
Application Date2015-04-29
Frequency Range13.56 MHz
FRN0020917688
Test FirmHCT Co., LTD
Certified ByJongchul Lee
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date10/26/2015
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2015-04-29
Available2015-10-26
Created2015-04-23
Modified2015-04-23
Pages19
File TypeAdobe Acrobat PDF
File Size1252016
File SHA-25605ef604fbd7c8a3630e8eaf9731c43a5da528fb28dc7634910a28cbdd869336a
PDF Metadata Authori
PDF Metadata Produceri Acrobat Distiller 11.0 (Windows)
FCC.gov SourcesFCC.gov 2600243, FCC.gov 2600233, FCC.gov 2600222, FCC.gov 2600205, FCC.gov 2600192, FCC.gov 2600179
